Summary of Contents for Selecta Power LBA-113
- Page 1 Operator’s Manual Selecta Power Pump Units MANLBA-100 Rev E 3/10/07 6.5 HP Fire Pump 1 stage 6.5 HP Fire Pump 2 stage 6.5 HP Transfer Pump 2” 6.5 HP Transfer Pump 3”...
- Page 2 No liability can be accepted for any inaccuracies or omissions in this publication, although due care has been taken to make it as complete and accurate as possible. The information, illustrations and technical data were considered to be correct at the time of preparation. In accordance with our policy of continuous development Silvan reserves the right to make changes at any time without notice.
-
Page 3: Table Of Contents
Silvan product is an investment in quality. This manual covers the Selecta Power 6.5HP Fire Fighting Pumps and, 2” & 3” Water Transfer Pumps. To ensure continued efficient performance and safe operation of your pump, you need to read this manual thoroughly and fully familiarise yourself with all aspects of the pump’s operation, maintenance... -
Page 4: Specifications
3 inch BSP (75 mm) Pump Direct coupled centrifugal impeller type Operating speed 3600 rpm Overall Dimensions (mm, kg) Model LBA-113 Fire Pump, 1stage Length Width Height Weight Max Output -Open flow 380 l/min LBA-113 Max Pressure-No Flow 5 Bar (72psi) 50m LBA-100 Suction lift height 3.0 metres... -
Page 5: Warranty
Warranty The Silvan Warranty This warranty is the only warranty applicable to Silvan new products ('Products') and, to the maximum extent permitted by law, is expressly in lieu of any other conditions or warranties expressed or implied in relation to the Products. Subject only to legislative obligations to the contrary, Silvan shall not be liable for incidental or consequential damage resulting from ownership or use of a Product. -
Page 6: Safety Information
Safety Information Before operating the pump read the following safety instructions. Failure to comply with these warnings may result in serious injury or death. Whilst your Pump has been designed and manufactured to incorporate all necessary safety features it is essential that any person who operates or works on the machine is aware of the safety precautions that should be exercised. -
Page 7: Operation
Operation Fuel Filler Cap Air Cleaner Pump Priming Pump Priming Muffler Water Filler Water Filler Throttle Lever Three Choke Pump Lever Outlets Fuel Valve Pump Lever Inlet Sediment Pump Inlet Pump Oil Filler Recoil Starter Outlet Dipstick Pump Water Pull Grip Drain Plug Drain Engine Oil... - Page 8 Operation 2. Fuel Level Stop the engine before filling the fuel tank. Remove the fuel filler cap and fill the tank with Ignition Switch standard grade, unleaded petrol to the bottom of the filler neck. To avoid spillage, do not fill the neck of the tank.
-
Page 9: Lubrication And Maintenance
Lubrication and Maintenance Maintenance Schedule Regular maintenance is necessary to ensure optimum performance and extend the service life of the unit. The table below shows the items that require regular maintenance and the frequency at which each should be serviced. Ensure that the engine is stopped before you begin any maintenance or repairs. - Page 10 Lubrication and Maintenance Air Cleaner Service A dirty filter will restrict air flow to the carburettor and reduce engine power. Operating without the Fuel Valve air cleaner fitted or with a damaged filter will allow dirt to enter the engine causing rapid wear, which will not be covered under warranty.
-
Page 11: Trouble Shooting
Lubrication and Maintenance Preparation for Storage Flush the water pump with clean water to remove any sediment. Remove the pump drain plug and Throttle Stop drain the pump thoroughly then refit the drain plug. Screw If storing with petrol in the fuel tank it is important to choose a well ventilated area to reduce the hazard of petrol vaporisation. - Page 12 SILVAN AUSTRALIA PTY. LTD. ABN 48 099 851 144 Melbourne Australia Telephone: +61 (03) 9887 2788 Facsimile: +61 (03) 9887 1035 www.silvan.com.au SILVAN NEW ZEALAND PTY.LTD. Hamilton New Zealand Telephone: +64 (07) 8496030 Fax: +64 (07) 8496070 www.silvannz.co.nz...
