Summary of Contents for SDM T3DPS-FM
- Page 1 USER MANUAL T3DPS-FM T3DPS-FM FM 3CH DIGITAL PROPORTIONALR/C SYSTEM FOR MODEL AIRPLANES Made In China T 3DP -R adio F M 27 MHz.pmd P AG E 1 2005-11-12...
- Page 2 For your safety using, please read this manual thoroughly. TECHNICAL SPECIFICATIONS: Type:----------------------------------------------------- T3DPS-FM27 Channel:------------------------------------------------- 3CH Modulation:---------------------------------------------- FM Frequency:---------------------------------------------- 27MHz Working Voltage:-------------------------------------- 12V Working Current:---------------------------------------120mA WARNING AND PRECAUTIONS * Read user manual carefully before putting the R/C into use. * Do not oprate the system in open crowd. * Do not oprate this system when models of the same frequency are in use.
- Page 3 For your safety using, please read this SYSTEM CONTENTS: manual thoroughly. Piece Items Unit Transmitter T3DPS-FM27 Receiver FM27-3CH Servo S-17(standard) Servo Horn Parts Servo Horn Retention Screw Servo Retention Screws Check if you have the above items, otherwise, please contact your local distributor for assistance.
- Page 4 BATTERIES INSTALLATION * Remove battery cover at the back of transmitter. * Check carefully the polarity markings before inserting the 8 AA alkali or rechargeable battery(not provided). * Put back the battery cover. Battery Cover 2.RECEIVER OUTPUT CONNECTOR Receiver FM27-3CH BATT.
- Page 5 ASSEMBLY 1.Servo/Receiver Installation Diagram Connect to a Speed Controller or servo Receiver FM27-3CH CH.3 CH.2 X'TAL CH.1 BATT. Power Supply (Input 4.8V-6V) 2.Servo Horn Installation * After connecting servo to receiver, turn on the power switch of the transmitter and receiver. * Ensure the trims on transmitter are at neutral position.
- Page 6 "Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment." NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
