Summary of Contents for D&R Studio Remote
- Page 1 Operational & Service Manual Studio Remote 1.04 USERS MANUAL Version 1.04 Studio Remote Studio Remote/Mic Breakout and Headphones amplifier AXUM | AIRMAX | AIRLAB | AIRENCE | AIRLITE Studio Remote, D&R Phone +31 294 418014, email: info@d-r.nl Page 1...
- Page 2 We are confident that you will be using the Studio Remote for many years to come, and wish you a lot of success.
- Page 3 The unit can be connected directly to the D&R AXUM / AIRLAB / AIRENCE / AIRLITE. The only difference is another back panel PCB. STUDIO REMOTE Studio Remote, D&R Phone +31 294 418014, email: info@d-r.nl Page 3...
- Page 4 Wiring for the D&R AXUM The Audio-input RJ45 of the Studio remote Unit needs to be wired to the Axum or AirMax. The cat5 cable can be connected directly to the CRM card of the AXUM. In this way both CRM and Studio signal is available and can be selected with the toggle switch in-between the Pushbuttons underneath the front panel.
- Page 5 When in doubt ask your local D&R dealer or a qualified technician. Do not connect a wrong or damaged power-supply to the Studio remote-Unit to prevent you from electric shocks. Always use a Class II power supply (without earth pin, double isolated).
- Page 6 When in doubt ask your local D&R dealer or a qualified technician. Do not connect a wrong or damaged power-supply to the Studio remote-Unit to prevent you from electric shocks. Always use a Class II power supply (without earth pin, double isolated).
- Page 7 Power Jack (back side) 9V DC 100mA Class II power (without earth pin) Centre pin 9 to 12 V DC Ring The Power Jack is protect against reverse polarity connection. Studio Remote, D&R Phone +31 294 418014, email: info@d-r.nl Page 7...
- Page 8 2 mm thick Cut out to at least a depth of 50 mm 71 mm 110 mm 20 mm Scale 1:1 Print on A4 scale to 100% r= 4 mm Studio Remote, D&R Phone +31 294 418014, email: info@d-r.nl Page 8...
- Page 9 Which refers to this declaration, is in accordance with the following standards or standardized documents: EMC Directive 89/336/EEG, norm EN55103-1 (E2) EN55103-2 (E2) Low Voltage Directive 73/23/EEG, norm EN60065 Duco de Rijk D&R Electronica B.V. January 2014 Weesp Studio Remote, D&R Phone +31 294 418014, email: info@d-r.nl Page 9...
- Page 10 Parties") from and against any and all liability incurred by or made against the Indemnified Parties in connection with any claim arising from or related to your use. Duco de Rijk president Studio Remote, D&R Phone +31 294 418014, email: info@d-r.nl Page 10...
