- Page 1 MODEL N° 90204 OWNER’S MANUAL Keep this Product ID Number and use when contacting Customer Service:...
- Page 2 REGISTER YOUR PRODUCT ONLINE AT WWW.LIFETIME.COM At Lifetime, we are committed to providing innovative and quality products. While registering, you will have the opportunity to give us your feedback. Your input is valuable to us. Lifetime’s Promise to You: REGISTER today! Save this owner’s manual for future reference and in the event that...
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN SERIOUS INJURY OR PROPERTY DAMAGE AND WILL VOID WARRANTY. Most injuries are caused by misuse and/or not following instructions. Use caution when using this product. BEFORE BEGINNING ASSEMBLY... - Page 4 TOOLS AND PARTS REQUIRED FOR THIS ASSEMBLY 1/2” Wrench 7/16” Wrench Phillips Screwdriver 3/8” Socket Wrench Pliers Adjustable Wrench Rubber Mallet Funnel Scrap Wood Water Hose Sand 3/16” Allen Wrench *Two adults required to complete assembly* Only adults should set up the product. Do not allow children in the setup area until assembly is complete.
- Page 5 ASSEMBLY GUIDES Refer to the following areas throughout the instructions to assist in the assembly process: This area is located at the top, TOOLS AND HARDWARE REQUIRED FOR THIS PAGE left-hand corner of the page and indicates which tools and hardware are needed to complete the assembly steps on a page.
-
Page 6: Parts List
PARTS LIST Item Description HARDWARE LIST Item Description Pole Assembly Hardware Pole to Base Assembly Hardware Backboard to Pole Assembly Hardware... -
Page 7: Parts Identifier
PARTS IDENTIFIER Parts shown at 10% of Actual Size *Do not remove Top Pole from Middle Pole until instructed *Warning Sticker applied to side not shown 7” 15 ”... - Page 8 PARTS IDENTIFIER Part shown at 25% of Actual Size Parts shown at Actual Size Parts shown at 5% of Actual Size...
-
Page 9: Hardware Identifier
HARDWARE IDENTIFIER POLE ASSEMBLY HARDWARE Hardware shown at Actual Size POLE TO BASE ASSEMBLY HARDWARE Hardware shown at Actual Size BACKBOARD TO POLE ASSEMBLY HARDWARE Hardware shown at Actual Size... - Page 10 HARDWARE IDENTIFIER BACKBOARD TO POLE ASSEMBLY HARDWARE (CONTINUED) Hardware shown at Actual Size...
-
Page 11: Hardware Required
POLE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size PARTS REQUIRED Parts shown at 10% of Actual Size *Do not remove Top Pole from Middle Pole until instructed *Warning Sticker applied to side not shown Part shown at 25% of Actual Size Part shown at Actual Size TOOLS REQUIRED Phillips Screwdriver... - Page 12 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE NO TOOLS OR HARDWARE REQUIRED FOR THIS PAGE Top Pole (ALH) Middle Pole (ALF) Warning Sticker Note: Make sure the crimped side of the Top Pole is on the same side as the Warning Sticker (AMT) on the Middle Pole.
- Page 13 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” Top Pole (ALH) Middle Pole (ALF) WARNING...
- Page 14 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Middle Pole (ALF) Bottom Pole (ALE) 1/4” x 3/4” Screw (ADS) Domed Countersink Washer (CIH) Note: The 1/4” x 3/4” Screw should be fl ush with the Pole, but will spin freely once installed. Do not jam the Poles together until instructed.
- Page 15 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Scrap Wood NO HARDWARE REQUIRED FOR THIS PAGE ATTENTION: THIS STEP CANNOT BE REVERSED! Bottom Pole (ALE) Middle Pole (ALF) DO NOT COMPLETE ASSEMBLY. WARNING The Poles must be seated together! Even if the Poles cover the slots before seating, they must be struck on a hard surface fi...
- Page 16 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE NO TOOLS REQUIRED FOR THIS PAGE 5/16” Hex Nut (AYT) 5/16” Hex Knob (AYU) 5/16” x 3 1/4” Carriage Bolt (AOL) Top Pole (ALH) Middle Pole (ALF)
- Page 17 POLE TO BASE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size PARTS REQUIRED Part shown at 5% of Actual Size Part shown at 25% of Actual Size Parts shown at 10% of Actual Size 7” 15 ” TOOLS REQUIRED 1/2" Wrench 3/16”...
- Page 18 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE NO TOOLS REQUIRED FOR THIS PAGE Pole Brace (ALI) Base (AJM) Note: Repeat this step to install the other Pole Brace to the other side of the Base. 1/2” x 15 3/4” Axle (AJC) Wheels (AMU) Bottom Pole (ALE) 1/2”...
- Page 19 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE NO TOOLS OR HARDWARE REQUIRED FOR THIS PAGE Top Pole (ALH) 1/2” x 15 3/4” Axle (AJC) Base (AJM) 1/2” x 7” Axle (AJE)
- Page 20 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2" 3/16" Pole Braces (ALI) Bottom Pole (ALE) tighten all Pole to Base assembly hardware Note: Tip the system forward so the Pole rests on the ground. Do not stand the system up until it is fi lled with either sand or water later in the assembly.
- Page 21 BACKBOARD TO POLE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size...
- Page 22 BACKBOARD TO POLE ASSEMBLY PARTS REQUIRED Parts shown at 10% of Actual Size Part shown at 5% of Actual Size Part shown at 25% of Actual Size TOOLS REQUIRED 1/2” Wrench 3/8” Socket Wrench...
- Page 23 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” 3 1/2” U-Bolt (APK) Left and Right Backboard Brackets (AJJ & AJK) Notch Left and Right Backboard Brackets (AJJ & AJK) Top Pole (ALH)
- Page 24 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” Rim (ALX) Backboard (AJI) Rim Support Channel (AOX) 3 1/2” U-Bolt (APK) 5/16” Washers (ABD) 5/16” Nylock Flange Nuts (ABK) 5/16” x 3 1/4” Hex Bolts (AAC) 5/16” Washers (ABD) 5/16” Nylock Flange Nuts (ABK). AAC AAC...
- Page 25 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 3/8” Left and Right Backboard Brackets (AJJ & AJK) Backboard (AJI)
- Page 26 FINAL ASSEMBLY HARDWARE REQUIRED NO HARDWARE REQUIRED FOR THIS SECTION PARTS REQUIRED Part shown at 10% of Actual Size Part shown at Actual Size TOOLS REQUIRED Sand Water Hose Funnel...
- Page 27 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE NO HARDWARE REQUIRED FOR THIS PAGE Two adults are required to complete assembly. To prevent serious injuries, the Pole should be held down by one adult at all times while the Base is being fi lled. OPTION A: FILLING WITH SAND Base Plug (AEF) Base (AJM)
- Page 28 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE NO HARDWARE REQUIRED FOR THIS PAGE Two adults are required to complete assembly. To prevent serious injuries, the Pole should be held down by one adult at all times while the Base is being fi lled. OPTION B: FILLING WITH WATER Base Plug (AEF) Base (AJM)
- Page 29 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE NO TOOLS OR HARDWARE REQUIRED FOR THIS PAGE Net (AKZ) Rim (ALX) Note: If a replacement Net is needed, please call our Customer Service Department. Our Nets are shorter than average to reduce the risk of entanglement.
-
Page 30: Moving The System
OPERATION OF HEIGHT ADJUSTMENT SYSTEM To Raise or Lower the Hoop: MOVING THE SYSTEM WARNING: CAUTION:... - Page 31 POLE CARE AND SYSTEM MAINTENANCE IF RUST HAS PENETRATED THROUGH THE POLE ANYWHERE, REPLACE IT IMMEDIATELY!
- Page 32 NOTES...
- Page 33 NOTES...
- Page 34 ® ENHANCE YOUR LIFETIME PURCHASE BY ADDING ACCESSORIES OR OTHER GREAT PRODUCTS: To purchase accessories or other Lifetime Products, visit us at: www.lifetime.com Or call: 1-800-424-3865...
- Page 35 ADVERTENCIA AVERTISSEMENT SI NO SE OBEDECEN ESTAS ADVERTENCIAS PUEDEN PRODUCIRSE GRAVES LESIONES Y/O FAUTE DE NE PAS SUIVRE CES AVERTISSEMENTS, VOUS RISQUEZ DE CAUSER DES BLES- DAÑOS A LA PROPIEDAD. SURES GRAVES ET/OU DES DOMMAGES À L’ÉQUIPEMENT. www.lifetime.com #FS16400 10/12/2004...
-
Page 36: Warranty Information
THE MANUFACTURER RESERVES THE RIGHT TO MAKE SUBSTITUTIONS TO WARRANTY CLAIMS IF PARTS ARE UNAVAILABLE OR OBSOLETE. ALL WARRANTY CLAIMS MUST BE ACCOMPANIED BY A SALES RECEIPT. REPORT PRODUCT DEFECTS IN WRITING TO: To register the product, visit our Web site at www.lifetime.com www.lifetime.com...
