Summary of Contents for icombi AH20
- Page 1 Bluetooth Stereo Headset icombi AH20 User’ s Manual...
-
Page 2: Table Of Contents
13. Features and specification 14. Warranty ▶ Caution !! ◀ Before using icombi™ headset, please check up the comments below for safety. Do not impact or make a hole with sharpened pins on the product. Do not leave in high temperatures or heating. -
Page 3: Product Introduction
(AP11 / AP21) iPod Audio Dongle : audio transmitter for Apple iPod • icombi™ (AG12) General Audio Dongle : audio transmitter for all audio devices with a 3.5 mm audio jack • icombi™ (AU13) USB Stereo Dongle : audio transmitter for PC’ s or laptop’ s with USB port... -
Page 4: What Is Included In Icombi™ Ah20 Package
2. What is included in icombi™ AH20 package? AP11 or AP21 (iPod Audio Dongle) AC Adapter AH20 Stereo headset AG12 (General Audio Dongle) User’ s Manual USB power cable AU13 (USB Stereo Dongle) One of the transmitters is available in the package. -
Page 5: Headset Features
3. Headset Features Power Button (Slide) Talk Button Button for LED Light ejecting battery Microphone Battery Power Button USB or Adapter (Slide) Charging port Volume Up / Down Button Button for ejecting battery Play / Pause & Track Up/Down < Left > <... -
Page 6: Battery Charging
4. Battery charging ■ Before connecting the power adapter ■ How to check up the battery status? to the wall outlet, please ensure the power voltage is suitable for power adapter. >> Press the Volume up and Volume down buttons at the same time… … When fully charged LED flash in blue for 2 seconds. -
Page 7: Headset Pairing And On/Off
5. Headset pairing and ON/OFF ■ Headset pairing ■ Headset ON ■ Headset OFF Power Button When the headset is powered off, When the headset is powered off, When the headset is powered (Slide) & please slide on the power while please slide on the power. -
Page 8: Connecting To A Bluetooth Phone
(*) Headset should be on and in pairing mode. After choosing ‘ icombi AH20’ , please enter “0000” when asked for a pin code or a password or such like. When connection is successfully made, the headset LED blinks in blue at an interval of 3 seconds. -
Page 9: Connecting To An Ipod
RE-CONNECTING : Do not go through the INITIAL PAIRING again. Simply slide on the headset in order to re-connect with the AP11 / AP21 plugged into the iPod. Re-connection will be made automatically to the AP11 / AP21, that was paired with a icombi AH20 headset, after a short period time. -
Page 10: Connecting To An Audio Device
8. Connecting to an audio device ■ Connect to all audio devices with a 3.5 mm audio jack using AG12 INITIAL PAIRING : Connecting icombi™ AH20 to icombi AG12 for the first time Ear jack of Audio device Indicator of AG12... -
Page 11: Connecting To A Pc
AU13 plugged into a PC. Re-connection will be made automatically to the AU13, that was paired with a icombi AH20 headset, after a short period time. [note] AU13 is not compatible with Mac O/S PC. - Page 12 INITIAL PAIRING : Connect to the Bluetooth phone first and then to an audio device Registering Searching icombi Pin Code device(*) AH20 “0000” Connecting Set up headset for Connect to a Bluetooth phone according to Chapter 6. pairing mode After the connection is made...
- Page 13 11. Making and answering calls through icombi AH20 ■ How to make and answer calls through icombi AH20 after the connection is made according to Chapter 6.? ■ Making calls ■ Answering calls Enter a phone number and press the send button...
-
Page 14: Connecting To Both A Bluetooth Phone And An Audio Device
12. Making and answering calls while listening to music ■ Making and answering calls while listening to music through icombi™ headset Track Volume Function Play selecting control Button (+) , (-) : Pause (+) Volume (One Push) Previous Selecting track... -
Page 15: Features And Specification
13. Features and specification Diameter: 30mm Frequency Response: 20Hz ~ 20KHz • Bluetooth Standard Bluetooth 1.2 compliant SPL (Sound Pressure Level): 120±3dB @ 1KHz • Speaker THD (Total Harmonic Distortion): ± 5% Impedance: 32Ω± 15% @ 1V, 1KHz • General Radio 2.402 ~ 2.480 GHz Power Rating: 10mW (Maximum) Bluetooth Class II... -
Page 16: Warranty
14. Warranty Product Bluetooth stereo headset Model AH20 Date of purchase Serial No. Place of purchase Purchasing amount Subject to the conditions of this Limited Warranty, the Producer warrants this product to be free from defects in material and workmanship at the time of its original purchase by a consumer, and for a subsequent period of one (1) year. - Page 17 - CONDITIONS - 1.The warranty is valid only if the original receipt issued to the original purchaser by the dealer, specifying the date of purchase, is presented with the Product to be repaired or replaced. The Producer reserves the right to refuse warranty service if this information has been removed or changed after the original purchase of the Product from the dealer.
- Page 18 - Additional Page - Caution Modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Compliance Information This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received.
