Feiss Krona 4 Installation Instructions

Installation Instructions for
Kona 4, 6, and 9 Light Chandelier
Chandelier
G ENERAL RODUCT NFORMATION P
These fixtures are intended to be installed utilizing
junction boxes.
This product is safety listed for damp locations.
1A
SHADE TOOL
LAMP
COLLAR NUT
SHADE
1 Install the fixture arms by screwing them to the swivels, then secure them to the hub using the washers and couplers.
2 Place the shade onto the shade base and secure it in place with the collar nut using the shade tool. Repeat for remaining
shades.
Screw the lamps into the sockets. Refer to the label on the lamp socket for Max Wattage information.
3
Place the hub cover and washer onto the hub nipple and secure them in place with the hex nut. Place the spacer onto the
4
hub nipple.
Follow enclosed supplement installation instructions for electrical and fixture installation onto house outlet box.
5
I :
NEC compliant
SPACER
WASHER
COUPLER
& WASHER
3 FIXTURE
ARM
2
SOCKET
SWIVEL
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
5
STEM
HEX NUT
HUB COVER
HUB NIPPLE
HUB
1
SHADE
BASE
1
F3125-4-F3126-6-F3128-9
F3125/4, F3126/6, F3128/9
CAUTION RISK OF FIRE -
1.0
