NewHeights™ Series 4 XT
Elegante 3-Leg Workstation
Assembly/Operation Instructions
Failure to comply with or observe all assembly, safety, and operation
instructions and warnings regarding the use of this product may result
in serious property damage or bodily injury.
Make sure no obstacles are in the desk's path and all cords are of appropriate
length for the desk. Always maintain a 1" clearance around the table to prevent
pinching.
Never assemble (or disassemble) the table or components with the table plugged
into a power outlet. This product is for use on a nominal 120-volt circuit and has
a grounding plug. Make sure that the product is connected to an outlet having the
same configuration as the plug. No adapter should be used with this product.
Duty Cycle: 2 minutes ON/18 minutes OFF
Workstation can continuously operate for a maximum duration of two minutes.
After two minutes of non-stop operation, the workstation will automatically stop
and require eighteen minutes of cool down.
Instruction # 53210
Read all the instructions before beginning.
Hardware Pack # 53209
K&A Manufacturing
6703 Zinser Street
Schofield, WI 54476
Phone: 800.298.4351
Fax: 866.882.9475
www.raproducts.com
Version Dated 8/4/16
Page1 OF 9
Advertisement
Summary of Contents for RIGHT ANGLE NEWHEIGHTS Series 4 XT
- Page 1 NewHeights™ Series 4 XT K&A Manufacturing 6703 Zinser Street Elegante 3-Leg Workstation Schofield, WI 54476 Phone: 800.298.4351 Fax: 866.882.9475 www.raproducts.com Assembly/Operation Instructions Version Dated 8/4/16 Failure to comply with or observe all assembly, safety, and operation instructions and warnings regarding the use of this product may result in serious property damage or bodily injury.
- Page 2 K&A Manufacturing 6703 Zinser Street Schofield, WI 54476 Phone: 800.298.4351 Fax: 866.882.9475 www.raproducts.com Your workstation will have either (2) left legs (Leg A) and (1) right leg (Leg B) or (2) right legs (Leg B) and (1) left leg (Leg A). The drawing below shows how to distinguish the left leg A from the right leg B.
- Page 3 Tools Required for Assembly: Power Driver W/Adjustable Torque #2 Phillips Head Driver Bit K&A Manufacturing #2 Square Head Driver Bit 6703 Zinser Street Schofield, WI 54476 Phone: 800.298.4351 3/16" Hex Head Driver Bit or Fax: 866.882.9475 www.raproducts.com Allen Wrench Level 51708 53638 53176...
- Page 4 51708 M5 x 18mm (7/8") Sq/Ph/Wshr Head Wood Screw Motor Box Varies NewHeights Series 4 XT Leg Assembly Varies NewHeights Series 4 XT Wire Management Channel 53638 5/16-18 x 3/8 Button Head Socket Screw 53176 .25x.696x.58 Flat Washer 53174 1/4-20x1/2 Phillips Pan Head Machine Screw...
- Page 5 Step 3: Your workstation may have two different sizes of wire management channel 5 . Determine the correct locations of the channels according to K&A Manufacturing the length and width of the worksurface(s). Slide 6703 Zinser Street Schofield, WI 54476 apart the channel until the holes near the ends of Phone: 800.298.4351 Fax: 866.882.9475...
- Page 6 Step 4: Attach the other wire management channel 5 to the third leg 4 on the return side of the table. See K&A Manufacturing Detail B on Page 5. Fully tighten all of the screws. 6703 Zinser Street Schofield, WI 54476 Fully tighten the(6) wood screws 3 attaching the third Phone: 800.298.4351 Fax: 866.882.9475...
- Page 7 Step 6: Align the holes in the control box 11 with the pilot holes in the worksurface 1 . Attach it with (2) 6703 Zinser Street Schofield, WI 54476 recex screws 10 . Align the holes in the switch 9 with Phone: 800.298.4351 Fax: 866.882.9475 the pilot holes in the worksurface.
- Page 8 Step 8: Run the wires as shown in the wire runs diagram below. Run the wires in the wire management channels 5. Plug the wire from the switch into the receptacle K&A Manufacturing labeled HS on the control box 11 . Plug the motor wires 6703 Zinser Street Schofield, WI 54476 into the cables and plug the other ends of the cables into Phone: 800.298.4351...
- Page 9 K&A Manufacturing 6703 Zinser Street Schofield, WI 54476 Phone: 800.298.4351 Fax: 866.882.9475 www.raproducts.com Operation and Reset Procedure Plug the power cord into a standard 110v receptacle. A power surge protector is recommended. Press the down arrow button until the worksurface reaches its lowest position and clicks.
