Instructions for use with
the Universal Room
Sealing Kits
ROOMSEALKIT / ROOMSEALKIT90
SEALBOXKIT
for the Burley range of
Wood Burning Stoves
Applicable Appliances:
Springdale (9103), Debdale (9104), Hollywell (9105),
Brampton (9108) and Wakerley (9112)
Owston (9303), Launde (9304), Bradgate (9305),
Swithland (9308) and Bosworth (9312)
Advertisement
Table of Contents
Summary of Contents for Burley ROOMSEALKIT
- Page 1 Instructions for use with the Universal Room Sealing Kits ROOMSEALKIT / ROOMSEALKIT90 SEALBOXKIT for the Burley range of Wood Burning Stoves Applicable Appliances: Springdale (9103), Debdale (9104), Hollywell (9105), Brampton (9108) and Wakerley (9112) Owston (9303), Launde (9304), Bradgate (9305), Swithland (9308) and Bosworth (9312) ...
- Page 2 Air supply All hydrocarbon burning appliances require an oxygen/air supply. If the stove is to be fitted on an external wall the air supply can be taken straight from the outside. A 100mm diameter hole needs to be drilled in the correct place (138mm above the hearth) to take the 86mm external (80mm internal) duct as supplied. This will allow for easy connection, any gap can be filled in with cement or mastic. A proprietary grille is supplied with the kit. If the room sealing kit is not used, an air brick or non‐closing vent should be fitted to ensure the air supply is not blocked in any way. Ventilation is not required on the 3kW & 4kW models. A side vent option to the room sealing kit is available. Room Sealing Kit The room sealing method of supplying air is always to be preferred as heat loss from the room will be greatly reduced therefore increasing the efficiency of the appliance. If the stove is not on an outside wall or the direct air supply method cannot be used, an air vent must be supplied in the room in which the stove is fitted. The sizes of the vents required are: 3kW ‐ No vent required (Using the room sealing kit will increase efficiency) 4kW ‐ No vent required ...
- Page 3 Room Sealing Kit Contents: 1 X PLENUM BOX 2 X M8 NUTS 2 X M8 WASHERS * Not included with * Not included SEALBOXKIT with SEALBOXKIT 1 X 80MM DIAMETER DUCT 1000MM LENGTH 1 X VENT COVER 1 X SLIDING BAFFLE...
- Page 4 Fitting Instructions UNDO AND REMOVE THE NUT AND TWO WASHERS. REMOVE THE AIR CONTROL PLATE.
- Page 5 INSERT SLIDING BAFFLE INTO THE PLENUM BOX WITH THE SLOTTED EDGE CLOSEST TO THE PLENUM BOX FLANGE INSERT THE AIR CONTROL PLATE ( REMOVED FROM THE STOVE IN SECTION 1) THROUGH THE SLOT IN THE SLIDING BAFFLE.
- Page 6 INSERT THE END OF THE AIR CONTROL PLATE INTO THE AIR CONTROL ARM. ATTACH THE AIR CONTROL PLATE AND NUT WITH SUFFICIENT TENSION TO ENABLE THE SMOOTH OPERATION OF THE MECHANISM.
- Page 7 MOUNT THE PLENUM BOX ONTO THE FIXING STUDS AND SECURE WITH THE 2 X M8 NUTS AND WASHERS. CUT THE DUCT TO THE LENGH REQUIRED AND LOCATE ONTO THE SPIGOT ON THE PLENUM BOX. USE THE LOCKING SCREW TO SECURE THE DUCT.
- Page 8 Made in the UK Burley Appliances Ltd Lands End Way Oakham Rutland LE15 6RB United Kingdom Email: sales@burley.co.uk Phone: 01572 756956 Fax: 01572 724390 Updated October 2016 ...
