- Page 1 Operation and Maintenance Manual GLACIER TALL BASE CS5-16-VD-TB CS5-18-VD-TB2 120V/60HZ...
-
Page 3: Table Of Contents
New evaporative cooling media Operation & Maintenance Manual contains a harmless odor; similar to Table of Contents: new carpet or paint. The media 1.0 Introduction should be ushed with water to 2.0 Unpacking your COOL- SPACE ® remove the construction odor. A 3.0 Set-up of COOL-SPACE ®... -
Page 4: Introduction
MAY result in property damage. 1.0 Introduction COOL-SPACE ® is a patented and registered Trade Mark of Advanced Radiant Systems, Inc. and manufactured in Indiana. The COOL-SPACE ® unit is a compact, self-contained, high-efficiency portable evaporative cooler. -
Page 5: Connecting The Electrical Supply
3.2 Connecting the electrical supply The COOL-SPACE unit should be plugged into a fused or circuit breaker protected 15 amp, ® 120 volt, and 60 Hz circuit. All models utilize standard 120-volt power supply. The unit should be plugged into a fused or circuit breaker protected 15 amp, 120 volt, 60 Hz circuit. -
Page 6: Operating Procedures
4.0 Operating procedures There are 3 factors to consider when determining where to place the COOL-SPACE unit. ® 1. Fresh air supply: The inlet side of the unit (pad side) requires a constant, uninterrupted supply of fresh air for maximum performance. A distance of 3 feet clear space to any obstructions at the rear or inlet side of the unit is recommended. -
Page 7: Starting The Pump And Adjusting The Water Flow
4.3 Starting the pump and adjusting the water flow DO NOT flood the pads with water, keep them moist. New pads will take a few days before they become completely saturated. It is normal to have several dry streaks on the face of the pads about 1 to 2 inches wide. -
Page 8: Daily Maintenance
5.2 Daily maintenance When shutting down the COOL-SPACE unit at the end of each use, the pump should be ® turned off approximately 15 minutes before the fan is turned off. This will allow the pads to drain and dry out. To avoid disfiguring the housing the unit should be drained after every use. -
Page 9: Troubleshooting/Repair
6.0 Troubleshooting/Repair 6.1 Troubleshooting ELECTRICAL SHOCK HAZARD Disconnect the power supply before performing any service or maintenance on the unit. Failure to do so may result in serious injury or death. The COOL-SPACE ® unit consists of three systems: the fan, water distribution and pump. It is important to determine which system of the COOL-SPACE ®... - Page 10 6.1 Troubleshooting (continued) Fan System Please use caution when troubleshooting or repairing all electrical components. Be certain that all power is disconnected from the COOL-SPACE unit before the cooling pads or fan ® guard are removed to gain access to the fan. Direct Drive Models Problem Check...
- Page 11 6.1 Troubleshooting (continued) Water System The water distribution system consists of two (2) assemblies: o The Water Inlet Assembly Brass bulkhead fitting Float valve assembly o The Hose and Valve Assembly Spray Bar Assembly Valve Assembly Connection Hose ...
- Page 12 6.1 Troubleshooting (continued) Pump Problem Check Solution Pump motor will not run when Turn fan on to check for power. If fan doesn’t start; check switch is turned on. Is water level high enough to breaker and cord plug-in. If make the low- water cut-off fan does start;...
-
Page 13: Repair Procedures
Disconnect the power supply before performing any service or maintenance on the unit. Failure to do so may result in serious injury or death. GLACIER (CS5-16-VD-TB) Fan Motor Replacement 1. Remove cooling pads (see section 5.1 for pad removal instructions) 2. -
Page 14: Warranty
Fan Motor CS-F16-VD GLACIER Variable Speed Switches CS-E110 On/Off Pump CS-E188-VD Variable Speed Pump CS-E163-2 GLACIER Pump 8” Pads CS-H610 CS5-16-VD-TB Pads for GLACIER (2 required) Float Assembly CS-P142 Water Control Valve For exploded view drawings please go to www.cool-space.com... - Page 16 315 N Madison Street Fortville, IN 46040 1-800-557-5716 sales@cool-space.com www.COOL-SPACE.com CS-MAN-18-TB@V60H 06272017al...
