MX15 Series
AC and DC Power Source
Installation Manual
Contact Information
Telephone: 800 733 5427 (toll free in North America)
858 450 0085 (direct)
Fax: 858 458 0267
Email:
Domestic Sales: domorders.sd@ametek.com
International Sales: intlorders.sd@ametek.com
Customer Service: service.ppd@ametek.com
Web:
www.programmablepower.com
March 2011
Document No. 7005-954 Rev. C
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Metek MX15
Summary of Contents for Metek MX15
- Page 1 MX15 Series AC and DC Power Source Installation Manual Contact Information Telephone: 800 733 5427 (toll free in North America) 858 450 0085 (direct) Fax: 858 458 0267 Email: Domestic Sales: domorders.sd@ametek.com International Sales: intlorders.sd@ametek.com Customer Service: service.ppd@ametek.com Web: www.programmablepower.com March 2011 Document No.
- Page 4 Installation Manual AC Power Source California Instruments Models: MX15-1 MX15-1Pi MX30/2-1Pi MX30/2-1Pi-MB MX45/3-1Pi MX45/3-1Pi-MB Rev C, March 2011.
- Page 5 Other trademarks, registered trademarks, and product names are the property of their respective owners and are used herein for identification purposes only. Notice of Copyright MX15 Series, AC and DC Power Source, Installation Manual © 2010 AMETEK Programmable Power, Inc. All rights reserved.
- Page 6 This page intentionally left blank.
-
Page 7: Important Safety Instructions
Important Safety Instructions Before applying power to the system, verify that your product is configured properly for your particular application. Hazardous voltages may be present when covers are removed. Qualified personnel must use extreme caution when servicing this equipment. Circuit boards, test points, and output voltages also may be floating above WARNING (below) chassis ground. - Page 8 Product Family: MX15 Series Warranty Period: One Year WARRANTY TERMS AMETEK Programmable Power, Inc. (“AMETEK”), provides this written warranty covering the Product stated above, and if the Buyer discovers and notifies AMETEK in writing of any defect in material or workmanship within the applicable warranty period stated above, then AMETEK may, at its option: repair or replace the Product;...
-
Page 9: Table Of Contents
Figure 2-8: Two MX15's in Clock and Lock mode Output Wiring ................ 17 Figure 2-9: MX45/3 or MX45/3-MB Output Wiring....................18 Figure 2-10: Three MX15's in Clock and Lock mode - Output Wiring ..............19 Figure 2-11: Ship kit Terminal Block dimensions ....................20 Figure 2-12: Multi-Cabinet DIP Switch Location and Setting ................ -
Page 10: Introduction
Available voltage ranges are 150 Vac, 300 Vac and 400 Vac in AC mode and 200 Vdc and 400 Vdc in DC mode. All MX15 units have a single-phase output. -
Page 11: Unpacking And Installation
(option -400), 440 V (option -480). Figure 2-1: The MX15 Power Source CAUTION: Do not connect 400, 440, or 480V into a unit set for 208 or 230V unit, the result could be a severely damaged unit. Always check the input rating on the model number tag before connecting AC input power. -
Page 12: Mechanical Installation
AC input connections are to be made directly to the input fuse block. The input fuse block is located on the lower right hand corner of the rear of the MX15 chassis. To access the input fuse connection block, the protective rear cover needs to be removed first. -
Page 13: Figure 2-2: Location Of Ac Input Fuse Block, Chassis Ground Connection, And Output Terminal Block
The front cover must be re- installed prior to use and the strain relief provisions located at the rear bottom of the unit must be used to maintain protection against hazardous conditions. MX15 Series... -
Page 14: Figure 2-3: Mx15 Ac Input Connection Diagram
Installation Manual Figure 2-3: MX15 AC Input Connection Diagram MX15 Series... -
Page 15: Ac On/Off Circuit Breaker On Mx15 Front Panel
LV Power supply of the MX15 chassis only. The LV Power supply provides DC bias power to the entire MX15 system. The AC input power is routed through a set of three AC line fuses (F1-A, F1-B and F1-C) located in the lower right bottom corner of the MX15 (Looking from the rear). -
Page 16: Figure 2-4: Rear Panel
Installation Manual CAUTION: The AC input fuses can only be checked if the MX15 is completely de-energized and disconnected from any AC power input. Note: Under no circumstances should AC input power be applied if one or more of the AC input line fuses have failed and opened up. -
Page 17: Output Connections
If the EUT changes frequently, you may want to consider using some quick disconnect scheme external to the MX15 so it will not be necessary to power down the MX15 and remove the front covers. This can take the form of a panel-mounted socket of sufficient current and voltage rating. -
Page 18: Table 2-2: Suggested Output Wiring Sizes
REMOVING THE REAR PANEL. The correct standard size Allen wrench for connecting output wiring to TB1 is supplied with each MX15 in the ship kit. Look for a brown envelope. If the correct tools cannot be found, contact California Instruments customer service at support@calinst.com... -
Page 19: Figure 2-6: Mx45-1 Output Wiring
MX15-1 and MX15-1Pi Output Wiring Diagram Figure 2-6 shows the required output connections for a MX15-1 or MX15-1Pi. Always disconnect all input power from the MX15 before removing the rear panel cover that provides access to the input and output terminal connections. -
Page 20: Figure 2-7: Mx30/2 Or Mx30/2-Mb Output Wiring
MX30/2 and MX45/3 systems are shipped with external output terminal blocks that enable the output wiring from two or three chassis to be combined, providing a single point of connection to the EUT. These blocks are not enclosed however. Figure 2-7: MX30/2 or MX30/2-MB Output Wiring MX15 Series... -
Page 21: Figure 2-8: Two Mx15'S In Clock And Lock Mode Output Wiring
Installation Manual - Rev C California Instruments Figure 2-8: Two MX15's in Clock and Lock mode Output Wiring MX15 Series... -
Page 22: Figure 2-9: Mx45/3 Or Mx45/3-Mb Output Wiring
EUT. These blocks are not enclosed however. Figure 2-9: MX45/3 or MX45/3-MB Output Wiring MX15 Series... -
Page 23: Figure 2-10: Three Mx15'S In Clock And Lock Mode - Output Wiring
Installation Manual - Rev C California Instruments Figure 2-10: Three MX15's in Clock and Lock mode - Output Wiring MX15 Series... -
Page 24: Figure 2-11: Ship Kit Terminal Block Dimensions
2.6.4 Multi-Chassis Output Connections If two or more MX15 chassis are used to form a single power system, the outputs of all chassis need to be combined (paralleled). This can be done directly at the EUT if convenient or using the provided heavy-duty terminal block. -
Page 25: Connectors - Rear Panel
A set of two identical System Interface connectors, P8 and P9 is located on the rear panel of each MX15 chassis. The system interface is used to connect the multiple MX15 power sources in a Master/Auxiliary configuration to create MX30/2 and MX45/3 models. In these configurations, only the Master MX15 power source has a built-in controller and front panel. -
Page 26: Table 2-4: Analog Interface Connector
INPUT: Remote Inhibit. (Contact closure). INPUT: return. 2.7.3 BNC Connectors BNC connectors. Functions are called out on rear panel decal. Table shows connections from left to right when standing at the rear of the MX cabinet. Table 2-5: BNC Connectors MX15 Series... -
Page 27: Table 2-6: External Sense Connector
Function Strobe (TTL output) (Same signal connection as Trigger Output) Clock (TTL output on Master / TTL input on Auxiliary) Lock (TTL output on Master / TTL input on Auxiliary) 2.7.4 External Sense Connector Table 2-6: External Sense Connector Description Phase A sense Neutral sense MX15 Series... -
Page 28: Multiple Cabinet System Configurations
Master units each have their own controller but can be configured as auxiliary units by disconnecting the ribbon cable marked J17 between the controller and the system interface board (P/N 7005-701-1). This disables the controller and allows the MX15 to operate as an Auxiliary unit. (Requires removal of the top cover) When used as a multi-cabinet system for higher power applications, the controllers in the unit(s) acting as the auxiliary to the master are either disabled or not present. -
Page 29: Clock And Lock Configurations
Master/Auxiliary which requires each chassis to have it's own controller. As such, it is possible to create 1, 2, or 3 phase power systems using 2 to 3 MX15 chassis. For most single phase configurations, the normal multi-box mode of operation as described in section 2.8 is recommended as it provides a single controller (and GPIB/RS232 control interface). -
Page 30: Table 2-8: Clock And Lock Initialization Settings
California Instruments 2.9.2 Clock/Lock Initialization Settings The mode of operation of the MX15 is determined by the MODE setting in the CONTROL menu. If the clock and lock option is enabled, three choices will be available for this field: STAN, MAST, and AUX. -
Page 31: Basic Initial Functional Test
Make sure the power resistor has sufficient power dissipation capability - up to 15 KW for full load test per MX15 - and that the load used does not exceed the maximum power rating of the MX15. -
Page 32: Figure 2-13: Functional Test Setup
Installation Manual - Rev C California Instruments Figure 2-13: Functional Test Setup. MX15 Series... -
Page 33: Index
Configuration ..........26 wiring ............14 DIP switch ............25 voltage drop cables ............ 12, 15 voltage rating ............ 8 External Sync Clock/Lock ........... 27 Wire Sizes ..........12, 15 wiring Functional Test ..........28 input ............... 9 MX15 Series...
