General Safety and Maintenance Manual
Model
Number
56VL
56VS
The henry Tool Co., ManufaCTured by henry Tools
498 so. belvoir blvd., souTh euClid, oh 44121 u.s.a.
Ph: (216) 291-1011 or (800) 826-5257 ● Fax: (216) 291-5949 or (800) 303-2800
Email: daviidh@msn.com ● WEbsitE: WWW.hEnrytools.com
3 HORSEPOWER VERTICAL GRINDERS
Throttle
Power
Weight
Type
Output
LEVER
3 H.P.
8.8 Lbs.
(2250 W)
(4.0 Kg)
SAFETY
LEVER
Height over
Air
Spindle
Consumption
7.1 Inches 18 cm
45 cfm
(21.2 L/s)
MODELS
56 VL
56 VS
Rated Speed/Wheel Capacity
4500 RPM w/ 9 Inch T27 Wheel Guard
4500 RPM w/ 9 Inch T28 Wheel Guard
6000 RPM w/ 7 Inch T27 Wheel Guard
6000 RPM w/ 7 Inch T28 Wheel Guard
6000 RPM w/ 9 Inch T27 Wheel Guard
6000 RPM w/ 9 Inch T28 Wheel Guard
8000 RPM w/ 7 Inch T27 Wheel Guard
8000 RPM w/ 7 Inch T28 Wheel Guard
(NOTE: Standard RPM is 6000RPM)
Advertisement
Summary of Contents for Henry Airtools 56 VL
- Page 1 MODELS 56 VL 56 VS General Safety and Maintenance Manual 3 HORSEPOWER VERTICAL GRINDERS Model Throttle Power Weight Height over Rated Speed/Wheel Capacity Number Type Output Spindle Consumption 56VL LEVER 3 H.P. 8.8 Lbs. 7.1 Inches 18 cm 45 cfm...
- Page 2 General Operators Instructions and Service Manual MODELS 56 VL 56 VS www.HenryTools.com | Page 172 For additional product information visit our website. Revised 12/10/15...
- Page 3 General Operators Instructions and Service Manual MODELS 56 VL 56 VS Part No. Description Part No. Description 200-9 O-Ring AA-650-1-ALS Safety Lock Handle Assembly 500-46 Snap Ring (Complete) 550-33-L Live Handle Adaptor bushing 650-33 Screen Bushing(1/2x3/8) 550-33-SW Screen Filter 650-54...
- Page 4 General Operators Instructions and Service Manual MODELS 56 VL 56 VS PART NO. DESCRIPTION PART NO. DESCRIPTION 200-9 O-RING 650-57 SET SCREW 500-46 SNAP RING 650-58 SCREW 550-1-BT BEARING SUPPORT(OLD STYLE) still 650-60 ASSEMBLY COLLAR AND SCREW supported by Henrytools...
- Page 5 General Operators Instructions and Service Manual MODELS 56 VL 56 VS PART NO. DESCRIPTION AA-560-1 CASE ASSY.(Comes with all screws) Specify the speed AA-650-1-AL LEVER LIVE HANDLE ASSEMBLY COMPLETE with screwsNON lockout Style AA-650-1-ALS LOCKOUT LEVER LIVE HANDLE AS- SEMBLY COMPLETE with screws...
- Page 6 General Operators Instructions and Service Manual MODELS 56 VL General Wheel Mounting Instructions 56 VS Wheels known to have been subjected to improper mounting procedures can burst violently and should be destroyed rather than risk their use by someone who may not notice that the wheels are damaged.
-
Page 7: Safety First
General Operators Instructions and Service Manual MODELS 56 VL 56 VS in this operating instruction, alerting to hazards for life and health of people. Observe these notes and proceed with special care in the cases described. SAFETY FIRST! Pass all safety instructions on to other operators. In... - Page 8 General Operators Instructions and Service Manual MODELS 56 VL 56 VS reach when operating this tool. High reaction torques can nated. occur at or below the recommended air pressure. • Do not remove any labels. Replace any damaged label. Tool accessories may continue to rotate briefly after throttle •...
- Page 9 General Operators Instructions and Service Manual MODELS 56 VL 56 VS PRODUCT SAFETY INFORMATION - WHEN USING THE TOOL:(CONTINUED) • Use accessories recommended by Ingersoll-Rand. sory. Be aware that it may fail at this time if it is defective, improperly mounted •...
- Page 10 General Operators Instructions and Service Manual MODELS 56 VL 56 VS PRODUCT SAFETY INFORMATION - WHEN USING THE TOOL:(CONTINUED) Additional Warnings for Use of Cut-off Wheels (Type 1 and 27A) • When cutting, support the workpiece so the slot is kept at constant or increasing width during the whole operation.
- Page 11 General Operators Instructions and Service Manual MODELS 56 VL 56 VS DISASSEMBLY on spindle.(Press on inner race of bearing.) Be Disconnect air and remove all wheels and accessories from sure that short dowel pin in cylinder goes into grinder. hole in rear thrust(550-3).
