5 Thanks to 32-bit high-precision processing at a 96 kHz sampling rate from input to output, the
RV-500 gives you stunningly high-quality reverb.
5 With an easily readable screen and an independent [TAP/CTL] switch, it delivers both high
functionality as well as ease of use during live performances.
5 A total of 12 types of reverb are provided, including classic varieties as well as "DUAL" which lets
you use two reverbs simultaneously, the sparkling "SHIMMER, " and models such as "Roland SPACE
ECHO RE-201" and "Roland DIGITAL REVERB SRV-2000. " Powerful DSP lets you use delay and
modulation simultaneously for all reverbs.
5 The memory function lets you store and recall 297 different setups from internal memory.
"CARRYOVER" provides seamless transition that preserves the reverberant sound when switching
between patches.
5 By connecting the RV-500 via a USB cable or MIDI cables, you can switch sounds and control
parameters in synchronization with your computer DAW or an external MIDI device.
Before using this unit, carefully read "USING THE UNIT SAFELY" and "IMPORTANT NOTES" (leaflet "USING THE UNIT SAFELY" and Owner's Manual
(p. 28)). After reading, keep the document(s) including those sections where it will be available for immediate reference.
© 2017 Roland Corporation
2
2
2
4
4
5
6
7
8
9
10
11
11
11
12
16
16
18
18
18
19
Owner's Manual
20
20
20
21
22
24
24
24
25
26
26
27
27
28
28
Advertisement
Table of Contents
Related Manuals for Boss RX-500
Summary of Contents for Boss RX-500
-
Page 1: Table Of Contents
Owner’s Manual 5 Thanks to 32-bit high-precision processing at a 96 kHz sampling rate from input to output, the RV-500 gives you stunningly high-quality reverb. 5 With an easily readable screen and an independent [TAP/CTL] switch, it delivers both high functionality as well as ease of use during live performances. -
Page 2: Getting Ready
Getting Ready Installing the Batteries Install four alkaline batteries (AA, LR6) in the battery compartment located on the bottom of the unit. * When turning the unit over, be careful so as to protect the buttons and knobs from damage. Also, handle the unit carefully;... - Page 3 Getting Ready INPUT A/MONO, B jacks OUTPUT A/MONO, B jacks Connect your electric guitar, or another instrument or effect unit, to these jacks. Connect these jacks to your amp or monitor speakers. * Use the INPUT A/MONO jack and B jack when connecting a stereo-output effects unit. Use If you’re using a mono setup, use only the INPUT A/MONO jack if you’re using a mono source.
-
Page 4: Basic Operation
Basic Operation Adjusting the Reverb [MODE] knob Selects the type of reverb. EARLY Reverb that simulates the reverberation in Reverb that extracts only the early ROOM REFLECTION a room. reflections. Reverb that simulates the reverberation in a NON-LINEAR Gated reverb or reverse reverb. HALL concert hall. -
Page 5: Adjusting The Delay
Basic Operation Adjusting the Delay The RV-500 lets you use reverb and delay simultaneously. Each time you press the [TIME/VALUE] knob, you alternate between adjusting the reverb and adjusting the delay. * To use delay, use CONNECTION to specify how delay is connected (p. 11). If CONNECTION is turned “OFF, ”... -
Page 6: Turning Reverb On/Off
Basic Operation Turning Reverb On/Off Patch A reverb Each time you press the [A] switch, the reverb alternately turns on (lit blue) / off (unlit). Patch B reverb Each time you press the [B] switch, the reverb alternately turns on (lit blue) / off (unlit). Blue: on Unlit: off Press once... -
Page 7: Switching Banks/Patches
Basic Operation Switching Banks/Patches Switch banks (01–99). Bank up (press the [B] and [TAP/CTL] switches simultaneously) Bank down (press the [A] and [B] switches simultaneously) Press a blinking switch ([A] or [B]) to switch patches. Blinking blue MEMO You can recall a different patch by turning the [TIME/VALUE] knob while you hold down the [EXIT] button. -
Page 8: Using The [Tap/Ctl] Switch To Control The Reverb
Basic Operation Using the [TAP/CTL] Switch to Control the Reverb With the initial settings, the [TAP/CTL] switch holds the reverb sound (HOLD); however, you can change this assignment so that the switch varies the way in which reverb is applied. Press the [EDIT] button. -
Page 9: Editing A Patch
Editing a Patch You can edit a variety of patch-related parameters. Press the [EDIT] button. Use the [ H ] [ I ] buttons to select “PATCH,” and then press the [EDIT] button. Use the [ H ] [ I ] buttons to select a parameter, and use the [TIME/ VALUE] knob to edit the value. -
Page 10: Saving A Patch
Saving a Patch Here’s how to save a patch that you’ve edited. Press the [EXIT] button and [EDIT] button simultaneously. Use the [TIME/VALUE] knob to select the save-destination number. Bank [A] switch [B] switch [TAP/CTL] switch Bank 01 Bank 02 Bank 99 * Patch C can be selected only if FSW MODE (p. -
Page 11: Parameter List
Parameter List PATCH Parameters Common to All Modes Parameter Value Explanation REVERB MODE Selects the type of reverb (p. 4). The same function as the [MODE] knob. TIME 0.1–10.0 s (*1) Adjusts the length (time) of the reverb sound. PRE-DELAY 0–200 ms Adjusts the time until when the reverb sound is output. -
Page 12: Parameters For Each Mode
Parameter List Parameter Value Explanation COMMON You can specify whether the reverb sound is carried-over when you switch CARRYOVER OFF, ON patches or turn the reverb off (p. 20). DIRECT LEVEL 0–100 Adjusts the volume of the direct sound. INPUT LEVEL 0–100 Adjusts the volume that is input to the reverb and delay. - Page 13 Parameter List FAST DECAY Parameter Value Explanation REVERB DECAY 1–10 Adjusts the decay of the reverb sound. EARLY REFLECTION Parameter Value Explanation REVERB TYPE 1–4 Selects the type of effect. ENVELOPE 1–10 Selects the envelope of the reverb. NON-LINEAR Parameter Value Explanation REVERB...
- Page 14 Parameter List DUAL Parameter Value Explanation REVERB TYPE1 ROOM, HALL, PLATE, Selects the type of reverb (p. 4). The same function as the [MODE] knob. SPRING TYPE2 TIME1 0.1–10.0s Adjusts the length (time) of the reverb sound. TIME2 PRE-DELAY1 0–200 ms Adjusts the time until the reverb sound is output.
- Page 15 Parameter List SPACE ECHO Parameter Value Explanation ECHO REPEAT RATE 1 ms–10.0 s Adjusts the spacing of the echoes (delay time). Specifies the tempo. The range of this setting depends on the REPEAT RATE and NOTE values. Adjusts the delay time. This is specified in terms of a note length relative to the ˜...
-
Page 16: Control
Parameter List CONTROL You can specify the functions of the [TAP/CTL] switch and of a footswitch or expression pedal connected to the CTL 1,2/EXP jack. 5 “Using the [TAP/CTL] Switch to Control the Reverb” (p. 8) 5 “Assigning a Function to an External Pedal” (p. 22) ASSIGN ASSIGN INPUT SENS Parameter... - Page 17 Parameter List Parameter Value Explanation Within the operating range of the source, this specifies the range that will ACT LOW 0–126 control the target parameter. The target parameter will be controlled within the range specified. Normally, you ACT HIGH 0–127 should leave ACT LOW at “0”...
-
Page 18: Bank
Parameter List BANK You can specify how patches A and B are connected and output when using simul mode. 5 “Using Two Patches Simultaneously (Simul Mode)” (p. 21) SYSTEM Parameter Value Explanation CONTRAST 1–16 Adjusting the contrast of the display Selects how output occurs. -
Page 19: Midi Pc Map
[HIGH] knob (delay) For details on MIDI, refer to “MIDI Specifies the controller EFFECT SW Implementation” (PDF). number that switches EFFECT A SW http://www.boss.info/manuals/ between effect-on and EFFECT B SW bypass. CTL1 CC External CTL1 switch CTL2 CC External CTL2 switch... -
Page 20: Convenient Functions
Convenient Functions Specifying Whether to Carry-Over the Reverb Sound You can specify whether the effect sound is carried-over (ON/OFF) when you switch patches or turn the reverb off. Press the [EDIT] button. Use the [ H ] [ I ] buttons to select “PATCH,” and then press the [EDIT] button. -
Page 21: Using Two Patches Simultaneously (Simul Mode)
Convenient Functions Using Two Patches Simultaneously (Simul Mode) If FSW MODE is set to “A/B SIMUL, ” you can use two patches A and B simultaneously (simul mode). Set FSW MODE to “A/B SIMUL” (p. 20). Selected patch Press the unlit [A] or [B] switch to make them both light. Now you can use two patches simultaneously. -
Page 22: Assigning A Function To An External Pedal
Assigning a Function to an External Pedal You can assign a function to a footswitch (sold separately: FS-5U, FS-5L, FS-6, FS-7) or expression pedal (sold separately: EV-30, Roland EV-5 etc.) connected to the CTL 1,2/EXP jack. Press the [EDIT] button. Use the [ H ] [ I ] buttons to select “CONTROL,”... - Page 23 Assigning a Function to an External Pedal EXP FUNC Settings Value Explanation No function is assigned. Select this if you’re using the ASSIGN1–8 setting (p. 16). RV TIME Controls the reverb time. RV PRE-DLY Adjusts the time until when the reverb sound is output. RV LOW Adjusts the character of the effect sound’s low-frequency range.
-
Page 24: Synchronizing With A Daw Or External Midi Device
Synchronizing with a DAW or External MIDI Device You can synchronize your RV-500 performance with a computer or an external MIDI device by sending and receiving MIDI messages. For example, an external MIDI device or DAW could switch patches on the RV-500 or control its tempo. -
Page 25: Midi Routing
If you experience problems connecting with your DAW Normally, you don’t need to install a driver in order to connect the RV-500 to your computer. However, if some problem occurs, or if the performance is poor, using the BOSS original driver may solve the problem. -
Page 26: Restoring The Factory Default Settings
Restoring the Factory Default Settings Here’s how to reset the settings to their factory state. If you like, you can also reset the system settings or just a specific range of patches. Press the [EDIT] button. Use the [ H ] [ I ] buttons to select “FACTORY RESET,” and then press the [EDIT] button. -
Page 27: Troubleshooting
Could the SYSTEM: FSW MODE (p. 20) effect is turned off even if CARRYOVER is setting be “A/B SIMUL”? turned “ON. ” Check the setting. Main Specifications BOSS RV-500: Reverb Alkaline battery (AA, LR6) x 4 Power Supply AC adaptor Current Draw 225 mA Alkaline batteries (AA, LR6): Approximately 4.5 hours... -
Page 28: Using The Unit Safely
Co.,Ltd. eParts is a trademark of eSOL Co., Ltd. in Japan. malfunction and damage. • Roland, BOSS, and SPACE ECHO are either registered • If operating this unit on batteries, please use alkaline batteries. trademarks or trademarks of Roland Corporation in the United States and/or other countries.
