Page 1: Operating Instructions
Product Manual 7410_TMA_0354_Issue_03.fm(19520).fm Page -1 Friday, June 5, 200 7410 Concrete Moisture Meter Elcometer 7410 Concrete Moisture Meter Operating Instructions Copyright 2016 Burwell Technologies For more information: 1300 287 935 / mail@burwell.com.au / www.burwell.com.au... - Page 2 (electronic, mechanical, magnetic, optical, manual or otherwise) without the prior written permission of Elcometer Limited. Doc.No. TMA-0354 Issue 03 Text with Cover No: 19520 For more information 1300 287 935 2 of 17 mail@burwell.com.au www.burwell.com.au...
-
Page 3: Table Of Contents
Section Page About this gauge ........2 Getting started .........5 Taking a reading ........9 A guide to moisture testing ....10 Maintenance ...........12 Accessories ..........13 Technical specification ......13 Related equipment .........14 For more information 1300 287 935 3 of 17 mail@burwell.com.au www.burwell.com.au... -
Page 4: About This Gauge
Your Elcometer 7410 Concrete Moisture Meter is a world beating product. With the purchase of this product you now have access to the worldwide service and support network of Elcometer. For... - Page 5 Meter will not detect or measure moisture through any electrically conductive materials including metal sheeting or cladding, black EPDM rubber or wet surfaces. The Elcometer 7410 Concrete Moisture Meter is not suited for taking comparative readings in the concrete substrate through thick coverings such as wood.
- Page 6 7410 Concrete Moisture Meter 7410_TMA_0354_Issue_03.fm(19520).fm Page 4 Friday, June 5, 200 The Elcometer 7410 Concrete Moisture Meter is packed in a cardboard and foam package. Please ensure that this packaging is disposed of in an environmentally sensitive manner. Consult your local Environmental Authority for further guidance.
-
Page 7: Getting Started
7410_TMA_0354_Issue_03.fm(19520).fm Page 5 Friday, June 5, 200 2 GETTING STARTED 2.1 Fitting a battery Your Elcometer 7410 Concrete Moisture Meter is powered by a single 9 V battery. The battery is located in a battery compartment at the rear of the instrument. - Page 8 7410 Concrete Moisture Meter 7410_TMA_0354_Issue_03.fm(19520).fm Page 6 Friday, June 5, 200 2.2 The buttons Your Elcometer 7410 Concrete Moisture Meter is controlled by the two buttons on the front of the instrument. Press once to switch the gauge on. OFF:...
- Page 9 When the battery is nearing the end of its useful life both lights flash for 3 seconds whenever the gauge is switched on. For more information 1300 287 935 9 of 17 mail@burwell.com.au www.burwell.com.au...
- Page 10 Graduated from 0 to 10 and 0 to 100. scales: these scales obtain comparative or qualitative moisture readings for gypsum and other floor screeds. Note: The bottom scales do not provide quantitative readings moisture content. For more information 1300 287 935 10 of 17 mail@burwell.com.au www.burwell.com.au...
-
Page 11: Taking A Reading
HOLD to retain the reading on the dial if required. 4. Repeat steps 2 and 3 a number of times and record the highest value. For more information 1300 287 935 11 of 17 mail@burwell.com.au www.burwell.com.au... -
Page 12: Guide To Moisture Testing
48 hours. All artificial heating or drying equipment should be turned off at least 96 hours before final For more information 1300 287 935 12 of 17 mail@burwell.com.au www.burwell.com.au... - Page 13 If they are being used it is recommended they should be turned off at least four days before taking final readings. For more information 1300 287 935 13 of 17 mail@burwell.com.au www.burwell.com.au...
-
Page 14: Maintenance
7410 Concrete Moisture Meter 7410_TMA_0354_Issue_03.fm(19520).fm Page 12 Friday, June 5, 20 5 MAINTENANCE The Elcometer 7410 Concrete Moisture Meter is designed to give many years reliable service under normal operating and storage conditions. Regular calibration checks over the life of the... -
Page 15: Accessories
7410 Concrete Moisture Meter 7410_TMA_0354_Issue_03.fm(19520).fm Page 13 Friday, June 5, 20 6 ACCESSORIES Your Elcometer 7410 Concrete Moisture Meter is complete with all the items needed to take measurements. The following optional accessory is available from Elcometer or your local supplier:... -
Page 16: Related Equipment
