V-8
True-bypass MIDI switching Pedalboard
User manual
Ed. 01 rev. 0
Advertisement
Table of Contents
Related Manuals for Vinteck V-8
Summary of Contents for Vinteck V-8
- Page 1 10128 Torino Corso Vittorio Emanuele II, 123 Tel. + 39 – 339 7626891 fax + 39 - 011 – 547712 Laboratorio Via Limone 22 10141 Torino Nr. Iscrizione RAEE IT08020000002500 (web) http://www.vinteck.com (e-mail) info@vinteck.com True-bypass MIDI switching Pedalboard User manual...
-
Page 2: Table Of Contents
_______________________________________________________________ 1-instrument marking. V-8 got in back side a little non removable area with serial and years of building. It is very important to report this information in case of need of technical supply. Edition 01eng rev. 0... -
Page 3: Gerneral Wornings
Maintenance must be operated ALWAYS with the instrument not connected to power supply V-8 is powered by an external 12 VDC 500mA. In no any case external power supply must be opened or dissasembled. In no any case the power plug and switch must be disassembled. -
Page 4: Technical Description Of V-Uno
To order the up-to-date versions of I.M. and for any further information, please contact Vinteck sas or the nearest Vinteck sas dealer. We will be pleased to receive your suggestions to improve our quality. -
Page 5: Installation And Connections (Wiring)
V-8 – true-bypass MIDI switching pedalboard installation and connections wiring) All connection are on back side of V-8 Low, from left to right: - BFR ON/OFF switch on or off the buffer on guitar buffer. Buffer must be switched off on case of signal higher than +4 dB . - Page 6 Never open the V-8 power supply. 230VAC inside when connected to 230 V socket. Vinteck sas do not have any responsibility in case of damage to people, animals or objects in case of non respect of this point. No warranty will be applied if power supply unit is disassembled or modified.
- Page 7 V-8 – true-bypass MIDI switching pedalboard Example 2 V-8 with 6 pedals in front and 3 in send/return. Example 3 V-8 with 6 pedals in front, 2 pedals in send/return and volume in send/return before delays Edition 01eng rev. 0...
-
Page 8: Programming And Midi Manager
Active banks show on display the DOT. Banks may be activated without sequence. (ex. Banks 0, 4 and 7 active). Following display show T0, T1, T2, T3. This is a function not active on V-8 To exit and confirm press button 8. - Page 9 Preset values is CC #80 . On some devices this the preset as well. Check on users manual the right CC values. Confirm and exit with button 8. PROGRAM CHANGE MIDI MAPPING. V-8 allows to assign a PROGRAM CHANGE number difference from program number. Factory preset got same number. To change number: Posizione V-8 con program ( 1 to 99) NOTE: It’s important to remeber the number of program you’re working.
-
Page 10: Spare Parts
VUNOPS External power supply 8- Warranty terms V-8 is covered of total warranty of 2 (two) years from purchase. Warranty operation will be performed only at Vinteck factory in Torino Italy. Shipping cost are charged to customers All operation and any spare parts are covered by warranty. - Page 11 Vinteck pag.11 V-8 – true-bypass MIDI switching pedalboard DECLARATION OF CONFORMITY Application of Council Directive(s): 89/336/EEC and 93/68/EEC Standard(s) to which Conformity is Declared EN 55103-1, EN 55103-2 and 60062: 1998 Manufacturer Vinteck SAS di Guido Michetti & C. Corso Vittorio Emanuele II, 123 10128 Torino –...
