Items Supplied in the Kit:

•
Two DNT900P radios installed in DNT900 interface boards (labeled Base and Remote)
•
Two 2 dBi dipole antennas with two U.FL coaxial jumper cables
•
Two 9 V wall-plug power suppliers, 120/240 VAC, plus two 9 V batteries (not shown above)
•
Two RJ-45/DB-9F cable assemblies, one RJ-11/DB-9F cable assembly, two A/B USB cables
•
One DNT900DK documentation and software CD

Additional Items Needed:

•
One PC with Microsoft Windows XP or Vista Operating System. The PC must be equipped with a USB port or a serial
port capable of operation at 9.6 kb/s.
Figure 1
©2010-2014 by Murata Electronics N.A., Inc.
DNT900DK (R) 11/3/14
Page 1 of 4
RFM products are now
Murata products.
DNT900DK
Quick Start
Guide
Figure 2
www.murata.com
