Summary of Contents for Global Sources HDEX009M1
- Page 1 USER MANUAL HDMI Extender By Coaxial Full HD up to 80 channel&500m Model No：HDEX009M1 Enjoy the vivid world! REMARK Manufacturer does not make any commitment to update the information contained herein.
- Page 2 Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. The products are designed to make your A/V device use more convenient, comfortable, productive and cost-efficient.
-
Page 3: Package Contents
PACKAGE CONTENTS: 1. Extender TX unit 1pcs 2. Extender RX unit 1pcs 3. AC power adapter 2pcs 4. User manual 1pcs FEATURES OF THE INTERFACE: Transmitter (TX) FIG.1 TX Front Panel View FIG.2 TX Rear Panel View PWR LED: POWER ON/OFF indicator CHANNEL: Channel selection switch HDMI LED: HDMI input indicator RF OUT: RF signal output... - Page 4 OPERATIONG AND CONNECTION: Ⅰ Point to point mode Coaxial cable TV/Monitor HDMI cable HDMI cable DVD/BD/STB FIG.5 CONNECTION DIAGRAM 1. Connect one SYV-75/RG59 coaxial cable from TX RF OUT into the RX RF IN. 2. Connect one HDMI cable from a DVD/BD player into the HDMI input port of TX. 3.
- Page 5 Ⅲ. Matrix mode HDMI HDMI cable cable TV/Monitor Coaxial cable DVD/BD/STB Coaxial cable Coaxial cable HDMI HDMI HD camera cable cable TV/Monitor DTV Mixer Coaxial cable Coaxial cable FIG.7 MATRIX CONNECTION DIAGRAM 1. Connect SYV-75/RG59 coaxial cables from TX RF OUT into the output ports of DTV mixer. 2.
- Page 6 Channel set and frequency reference table Channel Switch Setting Frequency Channel Switch Setting Frequency （12345678） （MHz） （MHz） （12345678） （MHz） （MHz） 0000 0001 142.5 0100 0001 0000 0010 149.5 0100 0010 0000 0011 156.5 0100 0011 0000 0100 163.5 0100 0100 0000 0101 177.5 0100 0101...
-
Page 7: Specifications
SPECIFICATIONS: HDEX009M1 HDMI resolution ……………………………………..24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i HDMI Audio Format……………………………………………………………………………………..LPCM HDMI Max bandwidth………………………………………………………….……………………...225MHz HDMI Max baud rate…………………….………………….………………….……………………6.75Gbps Input/Output TMDS signal ………….……………………………….……………….0.5~1.5Volts p-p(TTL) Input/Output DDC signal ……………………………………………..……………………. 5Volts p-p (TTL) RF frequency range…………………………………………………………………………...139～950 MHz RF Channel B/W…………………………………………………………………………....7/8 MHz The number of Channel…………………………………………………………………......80 RF Output power…………………………………………………………………...... - Page 8 Notes: Pls use the machine as the instruction listed to keep the long use lifetime of the machine. 1. The machine should be placed at the spot far from the Damp, High-Temperature, Dusty, Erosive, and oxidative environment. 2. All parts will be free from the strong shake, hit, fall. 3.
