- Page 1 OneScreen Manual: Hardware Overview Hardware Overview of 84" OneScreen Hubware h4, OneScreen Canvas c4 and OneScreen Touchscreen t4 OneScreen onescreensolutions.com | +1 858.552.0290 | United States| Pakistan Colombia | Mexico | UAE...
-
Page 2: Table Of Contents
........................ 5 1.2. OneScreen Canvas ........................... 5 1.3. OneScreen Hubware ........................6 About OneScreen ............................7 2.1. Introduction to OneScreen: ......................7 2.2. About the hardware overview manual: ................7 Safety First! ..............................8 3.1. Important Safety Instructions ......................8 3.2. - Page 3 7.1. Settings for RS 232 Control: ......................22 7.2. RS 232 Commands ........................... 22 Technical Specifications ........................... 24 8.1. Touchscreen Specifications ......................24 8.2. On-board PC Specifications ......................24 Troubleshooting ............................25 Contact Us ................................ 26 USA ................................26 Dubai ................................26 Colombia ..............................
-
Page 4: What's Included
1.What’s Included * Optional items are sold as part of different models. These are also sold separately and can be purchased later on to complement your OneScreen . onescreensolutions.com | +1 858.552.0290 | United States| Pakistan Colombia | Mexico | UAE... -
Page 5: Onescreen Touchscreen
1 x Wall mount package (contains 1x horizontal mount and 2x mounting arms) · 1x Remote control (batteries not included) · Screws · 1.2 OneScreen Canvas 1x OneScreen Touchscreen 84” 4K display · 1x Logitech K400 Plus wireless keyboard with dongle · 1x Extendible Stylus · 2x Stylus pens ·... -
Page 6: Onescreen Hubware
1 x Wall mount package (contains 1x horizontal mount and 2x mounting arms) · 1x Remote control (batteries not included) · 1x on-board OneScreen PC (core i7) · 1x Logitech Group Conference cam (contains hub, HD PTZ camera, speakerpod) ·... -
Page 7: About Onescreen
2.About OneScreen 2.1 Introduction to OneScreen Every workday is unique. Collaborate the way you need to with OneScreen solutions. From hardware to software, OneScreen offers interactive video collaboration technology for all of your remote teams along with your conference room, board room and classroom needs. All of our solutions include unlimited free, online training and on-demand Screen Skills Guru support. -
Page 8: Safety First
Do not rip any wire bare handed or touch the power hubs without any proper insulating gloves or · tools. Do not install or use the OneScreen or its peripherals near any heat sources such as radiators, heat · registers, stoves, or other devices (including amplifiers) that produce heat. - Page 9 For better ventilation of the unit, if mounting on the wall, attach it with a minimum clearance of 5 · cm from the wall. If the unit is installed on the mobile cart, then do check if the tires are properly moving without any ·...
-
Page 10: Getting Ready
4.Getting Ready! 4.1 Installing the Wall Mount For mounting the unit, check the integrity of the wall, whether it can endure the load of the unit. After that, clean the surface on which the unit is to be installed. Make sure your technician has the proper tools to install the wall mount (these include screws, washers, drill machine, screwdriver etc.) Follow the steps given below: At least two persons are required to lift the screen. -
Page 11: Installing The Keyboard Tray
4.2 Installing the Keyboard Tray 1) The keyboard tray comes with a set of screws and has to be installed at the bottom of the screen as indicated by the diagram below. 2) There will be two holes present at the back side (towards the bottom) of the screen. 3) These holes should coincide with the two holes present on the keyboard tray. -
Page 12: Hardware Details
5.Hardware Details 5.1 Locations of Ports The following image shows the back side of the unit. It will help you identify the position of different ports on the OneScreen . On-board PC Camera connector Top Ports Bottom Ports Power Side Ports onescreensolutions.com | +1 858.552.0290 | United States| Pakistan... -
Page 13: Top View
5.2 Top View 1. HDMI port 2. Touch USB port 3. Camera cables hole (The required adapter will pass through the hole here) 5.3 Bottom View 6. 7. 9. 10. 4. USB Touch port 5. RS 232 port 6. Headphone (3.5mm ) Audio port 7. -
Page 14: Side View
5.4 Side View 13. HDMI Out port 14. USB port 15. USB port 16. HDMI 3 port 17. HDMI 2 port 18. Display port 19. RJ 45 port 20. RJ 45 port onescreensolutions.com | +1 858.552.0290 | United States| Pakistan Colombia | Mexico | UAE... -
Page 15: Power
5.5 Power 21. Power button 22. Power Cable port onescreensolutions.com | +1 858.552.0290 | United States| Pakistan Colombia | Mexico | UAE... -
Page 16: Front View
5.6 Front View 23. Freeze button (enable or disable touch input) 24. Power button 25. Menu button 26. Volume decrease button 27. Volume increase button 28. OPS Button (Switches to on-board PC input) 29. Home button (Takes you to Android home page) 30. -
Page 17: On-Board Pc
5.7 On-board PC 1. RS 232 port 2. USB 2.0 ports 3. USB 2.0 ports 4. USB 3.0 ports 5. RJ 45 port 6. VGA port 7. HDMI port 8. Headphone port 9. Microphone port 10. Power button onescreensolutions.com | +1 858.552.0290 | United States| Pakistan Colombia | Mexico | UAE... -
Page 18: Setting Up Your Unit
Connect one end of the HDMI or VGA cable to your laptop and the other end to one of the corresponding ports on the OneScreen Touchscreen. If you are connecting the VGA cable, please also use the AUX cable to transfer audio. -
Page 19: Onescreen Canvas
Connect one end of the HDMI or VGA cable to your laptop and the other end to one of the corresponding ports on the OneScreen Touchscreen. If you are connecting the VGA cable, please also use the AUX cable to transfer audio. -
Page 20: Onescreen Hubware
OneScreen Hype and a perpetual license OneScreen Annotate. If you would like to connect an external PC you will have to install the software on it. OneScreen Hubware comes with the Logitech Group camera and speaker pod, please see below how to set it up. Please contact us for the digital copy of the software and license. - Page 21 Connect one end of the HDMI or VGA cable to your laptop and the other end to one of the corresponding ports on the OneScreen Touchscreen. If you are connecting the VGA cable, please also use the AUX cable to transfer audio.
-
Page 22: Rs 232 Guide
Use a Straight through Female to Female cable. Connect RS-232 cable between control Processor and OneScreen display. Set your program RS -232 port to the setting below. Control is one-way serial. However you may receive feedback when sending the power on/off commands. - Page 23 Set Contrast 55 00 2A 00 7F Set Brightness 55 00 2C 00 81 Set Saturation 55 00 2E 00 83 Set Hue 55 00 30 00 85 Set Sharpness 55 00 32 00 87 Set Color Temperature 55 00 34 00 89 Set Reduction Noise 55 00 36 00 8B Set Bass...
-
Page 24: Technical Specifications
8. Technical Specifications 8.1 Touchscreen Specifications Specification Details Screen Type TFT LED Resolution 3840(H) ×2160 (V) Response Time <8ms Touch Capability 10 Points (Finger or Pen) Surface Protection Anti-glare Tempered Glass Panel Size 84" Brightness 350 cd/ Dynamic Contrast 4000:1 Display colors 1.07 Billion (10-bit) Input Ports... -
Page 25: Troubleshooting
9. Troubleshooting It is always advisable to contact OneScreen technical support team in case of any problem. The table below will help you identify how to get the system running efficiently in case you encounter any of the following: PROBLEM Do’s... -
Page 26: Contact Us
CONTACT US Corporate Headquarters 6224 Ferris Square, Suite C San Diego, CA 92121 Phone: (858) 552-0290 Fax: (858) 552-0910 Marketing: (858) 552-0290 support@onescreensolutions.com Office No. 402, 4th Floor East Wing Building E3 Dubai Airport Free Zone Authority. Dubai, UAE Phone: +971-4-2149508 Mob Line 1: +971-55-4514278 Mob Line 2: +971-55-1985127 COLOMBIA...
