Komodo CoaXPress Frame Grabber
Hardware Reference and Installation
Guide
(Part-No. KY-FGK-XXX)
2 0 a M e s i l a S t . , N e s h e r 3 6 8 8 5 2 0 , I s r a e l
J
anuary
201
5
P O B 2 5 0 0 4 , H a i f a 3 1 2 5 0 0 1 , I s r a e l
T e l : ( + 9 7 2 ) - 7 2 - 2 7 2 3 5 0 0 F a x : ( + 9 7 2 ) - 7 2 - 2 7 2 3 5 1 1
w w w . k a y a i n s t r u m e n t s . c o m
Advertisement
Table of Contents
Summary of Contents for KAYA Komodo CoaXPress
- Page 1 Komodo CoaXPress Frame Grabber Hardware Reference and Installation Guide (Part-No. KY-FGK-XXX) 2 0 a M e s i l a S t . , N e s h e r 3 6 8 8 5 2 0 , I s r a e l...
-
Page 2: Table Of Contents
Contents Figures and Tables ....................2 Introduction ......................3 Safety Precautions ..................3 Disclaimer ....................4 Key Features ......................6 ....................6 Overview Features ....................6 Product Applications ................7 Related documents and accessories ............8 System Description ....................9 Example System Block Diagram .............. -
Page 3: Figures And Tables
Figures and Tables Figures 1: C ................9 IGURE RESS SYSTEM BLOCK DIAGRAM 2: K ..................10 IGURE OMODO BOARD EXTERNAL VIEW 3: E ................12 IGURE XTERNAL OWER SUPPLY CONNECTOR 4: PCB M ..................13 IGURE ECHANICAL IMENSIONS LED’ 5: K ................. -
Page 4: Introduction
Introduction Safety Precautions With your Komodo CoaXPress Frame Grabber board in hand, please take a minute to read carefully the precautions listed below in order to prevent unnecessary injuries to you or other personnel or cause damage to property. Before using the product, read these safety precautions carefully to assure correct use. -
Page 5: Disclaimer
CoaXPress video streams. KAYA Instruments assumes no responsibility for any damages resulting from the use of this product for purposes other than those stated. Even if the product is used properly, KAYA Instruments assumes no responsibility for any damages caused by the following: - Earthquake, thunder, natural disaster or fire resulting from the use beyond our responsibility, acts caused by a third party or other accidents, the customer’s willful or... - Page 6 Introduction KAYA Instruments assumes no responsibility or liability for: - Erasure or corruption of data arising from use of this product. - Any consequences or other abnormalities arising from use of this product, or damage of this product not due to our responsibility or failure due to modification.
-
Page 7: Key Features
Key Features Overview Komodo is best in its class Frame Grabber supporting CoaXPress standard. The Komodo is capable of receiving video streams from up to 8 CoaXPress links in single, dual, quad or octal modes. It is used for simultaneous capture from up to two quad link cameras. Each link supports standard CoaXPress bitrates up to 6.25 Gbps. -
Page 8: Product Applications
Key Features Plug-ins modules for Matlab, HALCON and Labview Gen<i>Cam compliant GenTL support Up to 18 GByte image buffer Data rates up to 6.25 Gpbs per link Transfer Rate of up to 60 Gbps ... -
Page 9: Related Documents And Accessories
Key Features Related documents and accessories Documents: Vision Point App User Manual Komodo API Reference Book CoaXPress standard 1.0 Accessories: CoaXPress cables (DIN to DIN) CoaXPress cables (DIN to BNC) Komodo Frame Grabber User Guide... -
Page 10: System Description
System Description Example System Block Diagram The Komodo Frame Grabber supports multiple modes of configuration and system topology. Few of these are presented in following diagrams. Dual Camera Topology: Two Single, Dual or Quad CoaXPress links with up to 6.25 Gb per link topology. Maximum throughput to PCIe of 25 Gb/sec. -
Page 11: External View Of The Board
System Description External View of the Board Figure 2: Komodo board external view Komodo Frame Grabber User Guide... -
Page 12: Mechanical Specifications
An availably x4 (or x8 or x16) PCIe slot. Gen 3 support is recommended to faster data transfer. Vision Point Application installation KAYA Instruments doesn’t guarantee compatibility with all computers that have the above specifications. Please, consult KAYA representative for any specific issue Power supplies... -
Page 13: Absolute Maximum Ratings
Mechanical Specifications External Power Supply connector Figure 3: External Power supply connector Absolute maximum ratings Specification Values 3.3V power supply -1.0V to +7.0V 12V power supply -0.3V to 14V Storage temperature -55°C to 125°C Operating ambient temperature 0°C to 50°C Table 1: Absolute maximum ratings Komodo Frame Grabber User Guide... -
Page 14: Mechanical Dimensions
The Komodo board is a half-length PCIe card according to PCI Express Card Electromechanical Specification. The exact board mechanical dimensions are as defined in Figure 4. For more detailed information please, contact KAYA Instruments representative. Figure 4: PCB Mechanical Dimensions Komodo Frame Grabber User Guide... -
Page 15: Installation And Configurations
Installation and Configurations Installation instructions Komodo board is standard PCIe card with 8 lanes connector. It can be installed in any PCIe Gen3 connector of the motherboard with 8 lanes and up. Note: Board should be installed before you install your software. 1. -
Page 16: Komodo Leds
Installation and Configurations Komodo LEDs Each CoaXPress link of the Frame Grabber is equipped with indication bi-color LED. The LEDs behave according to definition in section 5.4 of the CXP standard. The LEDs’ different states are described in Table 2. LED state Description Solid orange... -
Page 17: Komodo Hardware Reference
Installation and Configurations In additional to CoaXPress links LEDs, the Komodo Board is equipped with status LEDs. LED 0 LED 1 LED 2 LED 3 CH 0 LED CH 1 LED CH 2 LED CH 3 LED CH 4 LED CH 5 LED CH 6 LED CH 7 LED... -
Page 18: Komodo Board Block Diagram
Installation and Configurations Komodo Board Block Diagram External GPIO GPIO PoCXP power connector Video stream Equalizer 1.0/2.3 channel GPIO Controller Control channel Video stream Equalizer 1.0/2.3 channel Control channel Video stream Equalizer BANK A 1.0/2.3 channel DDR3 64 bit Control channel up to 64 Gb Video stream Equalizer... -
Page 19: Video Stream Acquisition
Installation and Configurations Video stream acquisition Komodo is designed to acquire different video streams compliant with CoaXPress standard 1.0 over up to 4 CoaXPress links. When connected to transmitting device, the frame grabber communicates with Camera device to determine link parameters, such as data rate. For different options please refer to Vision Point Application User Manual. -
Page 20: Figure 7: Gpio Connectors Location
Installation and Configurations Figure 7: GPIO connectors location Komodo Frame Grabber User Guide... -
Page 21: Table 4: J1 Connector Pinout
Installation and Configurations The pinout of each of these connectors is as described in Table 4 and Table 5. Signal Name Function Electrical Standard Description Number LVDS Input 0p LVDS input LVDS Positive signal of LVDS pair LVDS Input 0n LVDS input LVDS Negative signal of LVDS... -
Page 22: Table 5: J2 Connector Pinout
Installation and Configurations Signal Name Function Electrical Standard Description Number LVDS Input 2p LVDS input LVDS Positive signal of LVDS pair LVDS Input 2n LVDS input LVDS Positive signal of LVDS pair LVDS Input 3p LVDS input LVDS Negative signal of LVDS pair LVDS Input 3n LVDS input... -
Page 23: Table 6: Lvds Output Dc Specifications (Driver Outputs)
Installation and Configurations Electrical characteristics for board IO’s: Symbol Parameter Condition Units Differential Output Voltage ∆V Change in Magnitude of | mV for Complementary = 100 Ω Output States Offset Voltage 1.12 1.23 1.375 ∆V Change in Magnitude of | mV OUT- for Complementary OUT+... -
Page 24: Table 8: Lvttl Input Specifications
Installation and Configurations Symbol Parameter Test condition (note 1) Units ≥ V Input High Voltage +0.3 OH (min) ≤ V Input Low Voltage -0.3 OL (max) Input Current = 0 V or V ±5 µA Note: Vdd = 3.3V, unless specified otherwise Table 8: LVTTL input specifications Symbol Parameter... -
Page 25: Figure 8: Io's Schematic
Installation and Configurations The electrical connection of the IO signals is designed as on following principal schematic diagram: Figure 8: IO’s schematic Komodo Frame Grabber User Guide... -
Page 26: Absolute Maximum Ratings For Gpio
Absolute maximum ratings for GPIO Specification Minimum voltage [V] Maximum voltage [V] LVDS -0.3 Opto-isolated (in) Opto-isolated (out) -0.5 LVTTL -0.5 Note: The maximum current that the Opto-isolated (out) IOs can support is 150mA Table 12: Absolute maximum ratings for GPIO Komodo Frame Grabber User Guide...
