Enag F 3645 Manual

Protection, control and power supply box for gmdss system
Hide thumbs
Table of Contents

Advertisement

Quick Links

DESCRIPTION :
Vessels equipped with an AC or DC onboard network
(external regulated filtered charger *)
TYPE
REFERENCE
SERIAL NUMBER
MANUFACTURER CODE
CUSTOMER
Protection, control and
power supply box
for GMDSS system
:
ICA - GMDSS 30 - RAE
(Deported platen A + V)
:
SEEL006715F
:
:
F 3645
:
September 23nd 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F 3645 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Enag F 3645

  • Page 1 GMDSS system Vessels equipped with an AC or DC onboard network (external regulated filtered charger *) TYPE ICA - GMDSS 30 - RAE (Deported platen A + V) REFERENCE SEEL006715F SERIAL NUMBER MANUFACTURER CODE F 3645 CUSTOMER...
  • Page 2 06715DAF Page 1 / 14 IDENTIFICATION MATERIAL ICA - GMDSS 30 - RAE Material identification procedure TYPE GMDSS INTERNATIONAL RULES FRENCH RULES ALTERNATING CURRENT ² DIRECT CURRENT GLOBAL MARITIME DISTRESS and SAFETY GMDSS SYSTEM SYSTEME MARITIME de DETRESSE et de SMDSM SECURITE en MER OUTPUT NOMINAL...
  • Page 3 06715DAF Page 2 / 14 CONTENTS DESIGNATION PAGE Cover Identification Contents Generalities Presentation Operating Description Electrical Characteristics Mechanical Characteristics Installation - Connection - Settings Troubleshooting Maintenance Appendix General Guidelines on Equipment Installation 12 to 14...
  • Page 4 06715DAF Page 3 / 14 1 - GENERALITIES ENAG has been specializing in the production of power supplies for the marine environment for more than 30 years. ENAG manufactures a complete range of automatic battery chargers. We can also propose some regulated and filtered power supplies and converters, some monitoring systems which enable to compose the global supply of the GMDSS system.
  • Page 5 06715DAF Page 4 / 14 2 - PRESENTATION Compact box in conformity with 219 (project from 8/07/98). It includes : • 1 main source protected input (On-board main) 219 - 13 - 1 • 1 battery charger • 1 separator diode navigation post engine room 219 - 13 - 5 •...
  • Page 6 Page 5 / 14 06715DAF OPERATING DESCRIPTION The functioning principle of the GMDSS box is based on Automatic detection System (RAE system). Taking into account the “GMDSS” supply logic, the aim is to supply the appropriate power with an optimal autonomy thanks to radio-communications systems. Functioning modes : 1 –...
  • Page 7 06715DAF Page 6 / 14 4 - TECHNICAL CARACTERISTICS ELECTRICAL CARACTERISTICS • Main supply input: 230 VAC 50Hz • Battery charger 24VDC 30A • Radio battery input 24 VDC 30 A • Service battery input 24 VDC 30 A • Protected loads outputs 1 x 24VDC 30A 6 x 24VDC 7.5A MECHANICAL CHARACTERISTICS...
  • Page 8 06715DAF Page 7 / 14 5 - INSTALLATION - CONNECTION - SETTINGS TROUBLESHOOTING INSTALLATION Ceiling As the appliance is cooled by natural L=100 convection, a minimum allowance must be left for installation as shown. Mounting centre distance and space requirement: see enclosed drawing. The situation of the charger must be adapted to its protection rating.
  • Page 9 06715DAF Page 8 / 14 TROUBLESHOOTING 5.4.1 Switch on 0 The led functioning on emergency battery remains switched off. Check the presence of voltage at the input terminals, the state of the F5 and F6 fuses. The voltmeter does not show the stand-by battery voltage. Check the presence of voltage at the input terminals, the state of the F3 and F4 fuses.
  • Page 10 In both cases, check the stand-by battery. Contact the ENAG Technical Department who will indicate any further tests to be carried out according to the measuring and testing means available to the operator. In case of failure persistence, please contact the ENAG factory. The material must be dismounted and sent to the factory where the internal electronic circuits are checked on an appropriate test bench.
  • Page 11 06715DAF Page 10 / 14 APPENDIX Dimensions (alimentation box) N° 06715 05 Dimensions (deported platen) N° 06715 15 Terminal N° 04933 04 Implantation N° 04933 09 Implantation cover N° 06715 10 Electrical drawing N° 06715 06 Spare parts list N° 06715 RF Cables fixation N°...
  • Page 12 06715DAF Page 11 / 14 Guidelines on equipment installation By virtue of European directive 89/336/EC, the equipment must conform to electromagnetic compatibility criteria Date of application: January 1st, 1996. The two main demands in terms of electromagnetic compatibility are: Emission : Protection of the environment against disturbance by conduction and radiation.
  • Page 13 06715DAF Page 12 / 14 Emc-related installation guidelines Cables: Use shielded cable for all connections (*). The shielding must be grounded on the transmitter side and the receiver side. Keep the cables and shielding connections as short as possible. Feed the cables as close as possible to the ground (“loose” cables or loops are to be avoided - fasten the cables down to the ground).
  • Page 14 06715DAF Page 13 / 14 Additional attenuator systems The coils of contactors, relays, solenoid valves and electromagnets must be equipped with overvoltage arresters (RC circuits, varistor or diode on direct current, RC circuits or varistor on alternating current). Additional filters may be mounted according to applicable standards. Disturbance attenuation enables the specified levels to be attained.
  • Page 21 SPARE PARTS LIST SEEL006715D N° 06715RAD PAGE 1 / 1 Designation : DATE : NATO CODE : Ind : ICA - GMDSS 30 - RAE (Deported platen A + V) 23/09/2016 F3645 Designation Partnumber Manufacturer Item code F17-F18 Fuse 10Agg 10x38 13310 LEGRAND 30001307...
