- Page 1 L38B Product Manual Version Date Author Page No. Update details 2015-11-30 Zhong Da Premier release...
- Page 2 Contents...
-
Page 3: Usage Environment
Usage environment Operation temperature -20°C to 55°C。 Waterproof functionality classification Day-to-day waterproof functionality. The band can be used during daily ablution or in midst of rain, so long as only the surface is exposed to the water drops and no water pressure is exerted on the device. -
Page 4: Wearing The Device
3. Make sure that the band is located nearby. Select 3PLUS ELITE from your Bluetooth menu; 4. A connection request will be shown on your mobile device. Tap on the screen to accept the connection; 5. When the band is connected successfully, both your band and mobile device will receive a notification. -
Page 5: Screen Operation
Screen operation All screen operations can be done by touching the screen with your finger tip. Slide left or right to change the screen and menu. Slide your finger horizontally on the screen surface. Tips: If you are not sure what to do on a specific screen, try swiping left or right to switch to another interface. -
Page 6: Clock Interface
， Steps ， Sport duration ， Heart rate ， Timer Slide left or right to change the interface. Clock interface Time interface, Time and date on your band will be automatically synchronized with the connected mobile device. You can also setup your preferred time and date manually through the settings of 3PLUS ELITE APP. - Page 7 Steps, sport duration, calories, distance ， Calories ， Sport duration ， Distance ， Steps The band can monitor the steps and the distance you have walked throughout the day, as well as the calories you have burnt. You can check the data shown on the band screen.
-
Page 8: Heart Rate
Heart rate ， Heart rate Tap and hold the screen for 3 seconds or more to change to the heart rate interface and to start monitoring your heart rate. After the heart rate has been activated, switch to the heart rate interface. Tap and hold the screen for 3 seconds or more to turn off the heart rate monitoring. -
Page 9: Sport Mode
APPS menu Tap on the “APPS” to enter the APPS menu. APPS menu Mode change Device setting Back Slide left or right to change the interface. Sport mode Tap on the“ ” to enter sport mode. ， Calories... - Page 10 ， Distance ， Steps ， Sport duration ， Heart rate ， Timer Slide left or right to change the interface. Sleep mode Tap on the “ ” to enter sleep mode.
-
Page 11: Setting Menu
， Sleep duration ， Go to sleep ， Exit sleep ， Back Slide left or right to change the interface. Setting menu Tap on the “ ” to enter setting menu. ， Battery charges... - Page 12 ， Device info ， Flip screen ， Restart ， Factory reset ， Back Battery charges You can check the battery charges with the first option of the setting menu. To ensure the optimal functionalities, please make sure that the battery charges are not lower than 20%.
- Page 13 Device info You can check the device info with the “info” option of the setting menu. ID number of your device is available in the “info” section. Flip screen Vertically rotatable screen display This functionality allows you to choose the orientation of the band best suited to your wrist.
- Page 14 Tap on the “Restart？” option on the screen to enter the confirmation screen. Select either option. Factory reset Factory resetting will return your device to its original state during factory shipment. This function will delete the activity, sleep, etc. data on your device. To factory reset, enter the “Factory Reset?”...
- Page 15 SMS notifications: Click on the icon to check your messages. You can check up to 3 messages. And each message will display up to 3-page contents. (The first page will show sender name and the second, third pages will show the contents. Contents exceeding 3 pages will be replaced with “…”...
- Page 16 The band can display notifications from incoming call, missed call, SMS, email, social media, calendar event, device-tracking function. Open the 3PLUS ELITE App, single-tap “Setting” > “Notifications” to select the notifications you wish to receive on your band. If you would like to dismiss a certain notification, slide the select button leftwards. Then, dismiss the notification by single-tapping your band screen.
- Page 17 Sleep Activity Add new reminder by clicking on the “Reminder” section of your 3PLUS ELITE App. You can set up to 6 types of daily reminders, as well as selecting the type, preferred time, and date. The band will vibrate slightly and display the corresponding reminder. Single-tapping the band will dismiss the reminder.
-
Page 18: Customer Support
Goal Select the “Goal” section of the 3PLUS ELITE App to set up your goals for daily walking steps, distance, calorie burnt, and sleeping hours. Single-tap the upper right synchronization button will save your goal settings. When your goal is reached, your band will vibrate slightly and display the “Goal achieved”... -
Page 19: Supported Devices
Supported devices iOS 7+，Bluetooth 4.0 BLE，iPhone 4s+，iPad3+，iPad Mini+，iPod touch5+ Android 4.3 + ，Bluetooth 4.0 BLE Product standards Display：TFT 80*160 Wristband material：TPU Accelerometer sensor：Three-axis Heart rate monitor：Heart rate sensor Bluetooth：Bluetooth BLE 4.0 Battery：200mAh Waterproof classification：Day-today utilization waterproof functionality Weight：Approximately 25g Remarks Please charge the device promptly when it shows low power, and please use our standard charging clip.
