USER MANUAL
QVS HD-ADE
HDMI 2CH/5.1CH Audio Extractor
Table of Contents
1.0 Introduction..........................................................................1
2.0 Specifications.......................................................................1
3.0 Package Contents................................................................2
4.0 Panel Descriptions...............................................................2
5.0 Connection and Operation..................................................3
Advertisement
Summary of Contents for QVS HD-ADE
-
Page 1: Table Of Contents
USER MANUAL QVS HD-ADE HDMI 2CH/5.1CH Audio Extractor Table of Contents 1.0 Introduction................1 2.0 Specifications...............1 3.0 Package Contents..............2 4.0 Panel Descriptions...............2 5.0 Connection and Operation..........3... -
Page 2: Introduction
However, that can be a drawback for those who need separate audio outputs. Fortunately, the QVS HD-ADE is able to offer HD quality video signal with the choice of audio output. The HD-ADE can extract the audio signal from the HDMI interface, and transmit the audio to the display and amplifier receiver by SPDIF or Stereo. -
Page 3: Package Contents
HDMI 2CH/5.1CH Audio Extractor Environmental Operating Temperature 0℃ to +70℃ Operating Humidity 10% to 80 % RH (no condensation) Storage Temperature -10℃ to +80℃ Storage Humidity 5% to 90 % RH (no condensation) Power Requirement External Power Supply 5V DC @2A Power Consumption (max) 2.5W Regulatory Approvals... - Page 4 HDMI 2CH/5.1CH Audio Extractor 1）Power and Active LED With a double color LED when supplying power to this unit the light is red and when it starts to work normally the light is purple(red and blue mixed). 2）DC/5V Connect this port to power adapter. 3）HDMI In Connect this port to HDMI source device.
-
Page 5: Connection And Operation
HDMI 2CH/5.1CH Audio Extractor 5.0 CONNECTION AND OPERATION 1) Connect the input of this product to HDMI Source. 2) Connect the output of this product to HDMI Display. 3) Connect SPDIF or Stereo port to Amplifier Receiver 4) Insert the DC side of 5V power supply into the unit and then connect the AC side of the power supply into the wall outlet.
