Analytical Technology PortaSens II Owner's Manual

Gas leak detector
Hide thumbs
Table of Contents

Advertisement

Quick Links

PortaSens II
Home Office
Analytical Technology, Inc.
6 Iron Bridge Drive
Collegeville, PA 19426
Ph: (800) 959-0299
(610) 917-0991
Fax: (610) 917-0992
Email: sales@analyticaltechnology.com
Gas Leak Detector
European Office
ATI (UK) Limited
Unit 1 & 2 Gatehead Business Park
Delph New Road, Delph
Saddleworth OL3 5DE
Ph: 0800-018-4020
+ 44 (0) 1457-873-318
Fax: + 44 (0) 1457-874-468
Email: sales@atiuk.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PortaSens II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Analytical Technology PortaSens II

Summary of Contents for Analytical Technology PortaSens II

  • Page 1 PortaSens II Gas Leak Detector Home Office European Office Analytical Technology, Inc. ATI (UK) Limited 6 Iron Bridge Drive Unit 1 & 2 Gatehead Business Park Collegeville, PA 19426 Delph New Road, Delph Saddleworth OL3 5DE Ph: (800) 959-0299 Ph: 0800-018-4020...
  • Page 2 This warranty is void if the Manufacturer's product(s) has been subject to misuse or abuse, or has not been operated or stored in accordance with instructions or if the serial number has been removed. Analytical Technology, Inc. makes no other warranty expressed or implied except as stated above.

  • Page 3: Table Of Contents

    PortaSens II Gas Detector C16 Leak Detector TABLE OF CONTENTS SPECIFICATIONS..............................3 INTRODUCTION..............................4 UNPACKING ................................. 6 FIGURE 1 – FRONT PANEL OVERVIEW (ATI-0401)..................6 OPERATION................................7 LED............................7 ENSOR HARGE FIGURE 2 - MAIN DETECTOR DISPLAY ....................... 7 RESPONSE TEST..............................8 SAMPLE INLET OPTIONS ..........................

  • Page 4: Specifications

    PortaSens II Gas Detector C16 Leak Detector SPECIFICATIONS Range: Dependent on sensor module used Display: Back-lit graphics liquid crystal display Accuracy: Sensor dependent but generally ± 5% of value (limited by cal. gas) Sensitivity: 1% of sensor module range Repeatability: ±...

  • Page 5: Introduction

    C16 Leak Detector INTRODUCTION The Series C16 PortaSens II is a portable, battery operated instrument designed to measure a variety of gases in ambient air. While C16 detectors can only measure one gas at a time, the unit uses interchangeable smart sensors so that it can be quickly converted to measure another gas.
  • Page 6 PortaSens II Gas Detector C16 Leak Detector HYDRIDE GASES Arsine 00-1024 0-500 PPB 0-2000 PPB 1 PPB 00-1025 0-10 PPM 0-200 PPM 0.1 PPM Diborane 00-1026 0-500 PPB 0-2000 PPB 1 PPB 00-1027 0-10 PPM 0-200 PPM 0.1 PPM Germane...

  • Page 7: Unpacking

    When you receive your C16 Portable Gas Detector, open the carrying case and inspect the contents to be sure that no shipping damage has occurred. The following items should be included inside the case: 1 - Series C16 PortaSens II Gas Detector (without sensor module) 1 - Battery Charger 1 - Sampling Wand...

  • Page 8: Operation

    PortaSens II Gas Detector C16 Leak Detector OPERATION Sensor / Charge LED The C16 is equipped with a sensor / charge LED to give the user a visual indication that the sensor is ready for immediate use. This LED will flash about every 3 seconds. The sensor LED will flash even when the batteries in the C16 are too low to run the instrument.

  • Page 9: Response Test

    PortaSens II Gas Detector C16 Leak Detector RESPONSE TEST Prior to using the detector for field measurements, it is recommended that the unit first be tested for gas response. A response test simply means drawing a sample from some type of container that will give off the type of gas you are looking to measure.

  • Page 10: Sample Inlet Options

    C16 Leak Detector SAMPLE INLET OPTIONS The PortaSens II is shipped with a quick disconnect inlet fitting connected to the sample inlet port. A flexible extension wand is supplied in the kit for use in probing around mechanical equipment to determine the source of a gas leak or for pulling sample from a confined area without entering the area.

  • Page 11: Response Time

    PortaSens II Gas Detector C16 Leak Detector RESPONSE TIME The response time for the gas sensors varies depending on the particular type of sensor. The following table shows the typical response times for sensor modules available for the C16 detector. The table provides typical time constants to 66% and 90% of exposure. This data should be used to determine how long you need to measure in a particular location to be sure you have a representative reading.

  • Page 12: Interferences

    PortaSens II Gas Detector C16 Leak Detector INTERFERENCES Individual gas sensors respond to other gases or vapors in various ways. Some sensors are very specific, exhibiting very little cross-sensitivity with other gases. Other sensors are not as selective, and will respond to a variety of gases if present. Refer to the tables on the following pages for data on the response of ATI gas sensors to other gases that might be present.
  • Page 13 PortaSens II Gas Detector C16 Leak Detector SENSOR TYPE Hydride COCl 0.005 0.001 0.00002 0.01 0.001 0.001 0.001 0.05 -0.1 0.65 -0.3 0.05 -0.07 -2.5 0.42 Hydride -0.8 0.00005 0.02 0.05 0.005 0.00001 0.001 0.001 0.01 Interference Table Notes: 1. Sensors marked with an asterisk (*) in the oxygen column are 3 electrode sensors that require a minimum of 5% oxygen to operate properly.

  • Page 14: Gas Concentration Alarm Functions

    This condition can occur if the pump is filled with water or if the filter becomes completely blocked. A flowmeter is included in the PortaSens II kit to allow quick verification of proper flow. Turn the instrument on and connect the sampling wand. Place the tip of the sampling wand into the tubing adapter attached to the flowmeter.

  • Page 15: Battery Power Supply

    1 minute intervals. RS-232 COMPUTER INTERFACE The PortaSens II is equipped with an on-board data logger, which can be used to store gas concentration readings over time and transfer the data to a PC. The data logging function is enabled in units with firmware version 2.00 and higher.
  • Page 16 PortaSens II Gas Detector C16 Leak Detector FIGURE 3– CHARGER JACK / COMM PORT ORIENTATION (ATI-0402) O & M Manual Rev. G, 11/07 - 15 -...

  • Page 17: Start-Up Sequence

    PortaSens II Gas Detector C16 Leak Detector START-UP SEQUENCE When the C16 power switch is activated, a number of messages are sequentially displayed. Note that the display always has a row of text across the bottom. The four switches on the front panel are called “soft switches” because they have different functions depending on what mode of operation the unit is in.

  • Page 18: Operating Modes

    PortaSens II Gas Detector C16 Leak Detector OPERATING MODES Look at the display D10 on the previous page. Along the bottom line you will see the key functions OFF, MENU, and SMPL. To turn the unit off, press and hold the OFF key as previously described.

  • Page 19: Sensor Module Exchange

    C16 Leak Detector SENSOR MODULE EXCHANGE The versatility of the PortaSens II leak detector stems from its ability to use a variety of sensor modules. These interchangeable modules allow one instrument to measure a wide variety of gases with extended range capabilities as described in the Introduction section.
  • Page 20 PortaSens II Gas Detector C16 Leak Detector FIGURE 4 – MANIFOLD ASSEMBLY EXPLODED VIEW (ATI-0403) O & M Manual Rev. G, 11/07 - 19 -...

  • Page 21: Programming

    PortaSens II Gas Detector C16 Leak Detector PROGRAMMING As previously mentioned, the C16 is ready to operate when received. However, there are a number of operating variable such as range, alarm setpoints, display damping, and sample mode timing that can be programmed. In addition, sensor module zero adjustment and calibration can be done from the programming menu.

  • Page 22: Adjusting Alarm Setpoints

    PortaSens II Gas Detector C16 Leak Detector ADJUSTING ALARM SETPOINTS The C16 contains three alarms, one for Caution, one for Warning, and one for Alarm. In the C16 as shipped from the factory, the Caution setpoint is programmed to detect negative drift of the sensor zero.

  • Page 23: Setting Display Variables

    C16 Leak Detector SETTING DISPLAY VARIABLES Three display variables may be adjusted on the PortaSens II. The adjustments include display averaging, display blanking, and display range. To adjust display variables, start from display PD2 (see page 20). Press the key marked DISP. The display will change to VD1 below.
  • Page 24 PortaSens II Gas Detector C16 Leak Detector The measuring range of the C16 detector depends on the sensor module installed. Display D8 (page 16) in the information displays shows the minimum and maximum full scale range for the sensor currently installed. Keep in mind the fact that the full scale range you set in this routine will only affect the voltage output, data logging functions, and sampling mode recovery setpoint.

  • Page 25: Setting Sample Mode Variables

    PortaSens II Gas Detector C16 Leak Detector SETTING SAMPLE MODE VARIABLES As previously explained, the C16 detector provides the capability of measuring gas concentrations using a predefined measuring cycle. The measuring sequence used in “Sample Mode” measurements include the following sequence.

  • Page 26: Calibration

    Calibration of the PortaSens II is recommended approx. every 6 months in normal use. If the unit is used very infrequently, yearly calibration should be sufficient. This can be done easily provided that the user has a reliable gas standard to use for the calibration procedure.

  • Page 27: Figure 5 - Calibration Flow Schematic

    PortaSens II Gas Detector C16 Leak Detector CAL GAS SOURCE PortaSens II BYPASS “T” TO VENT FIGURE 5 - CALIBRATION FLOW SCHEMATIC To zero the detector, start at display PD1 and press the SENS key. The display CD1 will appear.

  • Page 28: Data Logging

    PortaSens II Gas Detector C16 Leak Detector DATA LOGGING The data logging function in the C16 is provided to allow collection and storage of gas concentration data over variable time periods. The data logger will store instantaneous gas values every 1, 5, 10, or 15 minutes. The logging interval is user selectable, and the logging is started and stopped using the keys on the instrument.

  • Page 29: Data Logger Software

    C16 Leak Detector DATA LOGGER SOFTWARE Your PortaSens II gas detector is supplied with “DataLog” software used to transfer stored data to a computer running Windows 95, Windows 98, or Windows 2000. The software is supplied on a CD ROM for installation.

  • Page 30: Starting The Datalog Program

    PortaSens II Gas Detector C16 Leak Detector Starting the DataLog Program Connect the C16 to your PC using the RS-232 cable supplied and turn on the C16. From your computer’s “START” menu, select “PROGRAMS”, “C16 Data Logger”, “C16Log”. As soon as you start the DataLog program, your computer will try to establish a connection to the detector.
  • Page 31 PortaSens II Gas Detector C16 Leak Detector 2. Communication port selection. The default communication port is set to COM1. If you connect the C16 to a different serial port, simply scroll to the port using the down key next to the COM1 designation and click the port name when displayed.

  • Page 32: Display And Graph Of Data

    PortaSens II Gas Detector C16 Leak Detector After you have adjusted your configuration to the desired settings, click the “Download” tab next to the configure tab. The display in Figure 7 will appear. FIGURE 7 - DOWNLOAD TAB IN DATALOG SOFTWARE This tab is provided to initiate the transfer of data from the C16 to your computer.

  • Page 33: Maintenance

    PortaSens II Gas Detector C16 Leak Detector MAINTENANCE Series C16 gas detectors require little maintenance. Sensors do not have a regular service requirement other than calibration, and pumps are sealed and permanently lubricated. The only item in the instrument that requires periodic maintenance is a filter that protects the pump against particulate that might cause it to stall.

  • Page 34: Troubleshooting

    C16 Leak Detector TROUBLESHOOTING The PortaSens II is a self contained instrument that does not require regular service. Only periodic calibration should be necessary to maintain proper operation. Should a problem arise with the unit, there are a few tests that can be done to determine the source of the problem.

  • Page 35: Troubleshooting (Cont'd)

    PortaSens II Gas Detector C16 Leak Detector TROUBLESHOOTING (cont’d) H: UNIT DOES NOT RESPOND WHEN KEYS ARE PRESSED. 1. Press and hold all four front panel keys for 5 seconds. This will reset the C16. Turn the C16 on by pressing the green key. If the C16 still does not operate, contact ATI for service.

  • Page 36: Spare Parts List

    PortaSens II Gas Detector C16 Leak Detector SPARE PARTS LIST PART NO. DESCRIPTION 28-0015 Charger, 110 VAC 28-0016 Charger, 220 VAC 34-0137 Front panel Overlay 00-1088 Calibration "T" 44-0096 Quick Disconnect Inlet Fitting 05-0038 Spare filter disks, package of 10...
  • Page 37 PortaSens II Gas Detector C16 Leak Detector Part Number Smart Module 00-1026 Diborane, 0-500/2000 PPB (1000 PPB Standard) 00-1027 Diborane, 0-10/200 PPM (10 PPM Standard) 00-1028 Germane, 0-500/2000 PPB (1000 PPB Standard) 00-1029 Germane, 0-10/200 PPM (10 PPM Standard) 00-1030...
