Summary of Contents for Mercury RV Duoetto HCE-10
- Page 1 Mercury RV Water Heaters Duoetto HCE-10 Dual Voltage 12VDC/240VAC www.ausj.com.au sales@ausj.com.au P.O. Box 777, Leichhardt, NSW 2040...
-
Page 2: Product Features
Thank you for your purchase of the Duoetto Dual Voltage Water Heater! This device is approved to European Quality Standards, CE, as well as AS/NZS 60335.2.21 : 2002 A1-3. The Duoetto is a simple system with high quality parts designed to meet your needs. Please read the instruction manual for maintenance and correct installation and operation of the Duoetto. -
Page 3: Safety Cautions
3. List of Technical Parameters Feature HCE-10 HCE-5 AC240v DC12v AC240v DC12v Rated Capacity(L) Rated Voltage(V) 220~V 12v-24v 220~V 12v-24v Rated Power(W) 1000W 300W 1000W 180W Rated Current(A) 4.6A 4.6A Rated Tank 0.6Mpa 0.6Mpa Pressure(Mpa) Net Weight(Kg) Gross Weight(Kg) 5.5kg Dimensions(mm) 425x235x235mm 210x220x265mm... -
Page 4: Installation
Don’t handle the plug with a wet hand. Do not operate this device if the cord, feed or plug is damaged in any fashion. Don’t replace the safety valve with any unauthorized products. The blowdown hose on the outlet of the pressure relief valve should be kept downward and open to the air. - Page 5 Screw the pressure relief safety valve onto the inlet, with the arrow on the valve pointing upward toward the water heater. Do not remove the small screw on the pressure relief valve. Connect the inlet to the water supply. (Fig 6) During operation you may observe a small leak of water from the drainage hose connected to the pressure relief valve, this is normal due to the expansion of water while heating.
-
Page 6: Methods Of Usage
4. The device must maintain circuit breaker protection. 12V Installation All appliance installations should be only carried out by a qualified individual. 1. Connect the red 5mm large wire directly to house battery or another suitable power source. 2. Connect the black 5mm large ground wire to an earth point or a negative battery terminal. 3. -
Page 7: Troubleshooting
To clean the shell of the Duoetto Water Heater, do not spray water directly onto it. After the power is disconnected, use a soft wet cloth to clean it, drying with a dry cloth afterward. Keep the water heater shell dry and clean. 9. - Page 9 12. 12V Cable Length and Current Capacity Guide Current, Length (Twin) to area (sq mm) 12.6VDC, current carrying capacity(CCC)(top) then follows 5% volt drop to 70 sq mm.
- Page 10 Please fill in all details correctly. Retain this card with original purchase invoice for any future warranty claim. Please note in the event of this document and the original purchase invoice not being provided, warranty will commence from the date of manufacture. Owner’s Details: Surname……………………………………………………………………………..
