Stevens makes no warranty as to the information furnished in these instructions and the reader assumes all risk in the
use thereof. No liability is assumed for damages resulting from the use of these instructions. We reserve the right to
make changes to products and/or publications without prior notice.
1
SDX
Submersible
Depth
Transmitter
User Manual
July 2017
USER INFORMATION
Stevens Water Monitoring Systems, Inc.
12067 NE Glenn Widing Drive, Suite 106
Portland, OR 97220
Tel: (800) 452-5272
Tel: (503) 445-8000
Fax: (503) 445-8001
Email:
info@stevenswater.com
Web: http://www.stevenswater.com
Advertisement
Table of Contents
Related Manuals for Stevens SDX
Summary of Contents for Stevens SDX
- Page 1 USER INFORMATION Stevens makes no warranty as to the information furnished in these instructions and the reader assumes all risk in the use thereof. No liability is assumed for damages resulting from the use of these instructions. We reserve the right to make changes to products and/or publications without prior notice.
- Page 2 WARNING! ELECTRICAL POWER CAN RESULT IN DEATH, PERSONAL INJURY OR CAN CAUSE DAMAGE TO EQUIPMENT. If the instrument is driven by an external power source, disconnect the instrument from that power source before attempting any repairs. WARNING! BATTERIES ARE DANGEROUS. IF HANDLED IMPROPERLY, THEY CAN RESULT IN DEATH, PERSONAL INJURY OR CAN CAUSE DAMAGE TO EQUIPMENT.
- Page 3 GENERAL DESCRIPTION The Stevens SDX ( Figure 1) is a sensing device designed for water-level measurement applications. It is totally sealed for direct insertion into the media to be monitored, and offers multiple applications. Low range units are ideal for open channel flow applications.
- Page 4 A pressure transducer is used as the primary sensing element, and measures the water depth by sensing pressure above the unit. Internal circuitry within the SDX housing converts the signal to a 4-20 milliampere (mA) output, with 4 mA corresponding to zero depth (atmospheric pressure) and 20 mA to rated depth for selected range. Power for the two-wire current loop is derived from an external power supply.
- Page 5 GENERAL The Stevens SDX is a sealed unit that is suitable for submersion in water. The SDX is an isolated (floating) electrical device. Connect the SDX, an appropriate direct current loop power supply, and the receiving device (recorder, etc.) in a series loop.
- Page 6 Replace the desiccant cartridge when the indicating crystals have turned from blue to pink. If used with a flume, weir, or stilling well, it should be kept clear of obstructions, debris, or silt. When cleaning, the SDX should be removed prior to hosing out the channel, tank, or well.
- Page 7 Ordering Manufacturer Part # Description 93720-102 SDX Pressure sensor, 9-26VDC,Temp.Compensated, 2.5 ft. range, without cable. 93720-105 SDX Pressure sensor, 9-26VDC,Temp.Compensated, 5 ft. range, without cable. 93720-110 SDX Pressure sensor, 9-26VDC,Temp.Compensated, 10 ft. range, without cable. 93720-135 SDX Pressure Sensor, 9-26VDC,Temp.Compensated, 35 ft. range, without cable.
