Before designing and during the production, the safety of operators and products all have been
considered. Please following this users instructions strictly to operate or install the machine in
case of personal injury or accident occur.
(1)The installation of the inverter should be done by professionals or under the assistance of the local
dealer.
(2)Verify whether the input DC voltage range meets the requirements ±15% and the correctness of
voltage polarity.
(3)Confirm the grade of load device voltage ,power should not be more than rated output power of
the inverter
(4)Do not flow any liquid inside the inverter, or with a damp cloth to wipe the machine casing. Can
not be directly Contact the inverter input and output terminals when the machine is running,
especially with wet hands, otherwise electric shock injury will occur.
(5)If you need to change the working environment under the normal working state, do not change its
connection, your operated should be assistance and confirmation by the professionals or supplier.
(6)The operating environment of inverter should be well-ventilated, temperature range -20-45
degrees, keep away from the ignition sources spot and direct sunlight, Can not run in the
condensation, dust environment. During the operating, the heat is normal phenomenon, should
maintain the ventilation, clean installation environment, in particular, can not block the ventilation
holes.
(7)Minors can not use this product.
(8)Confirm weather the inverter can be connected with the earth wire,Live line and Zero line can not
Product
Product
Power
Power
Shenzhen
ORO
Shenzhen
ORO
industrial
park,
industrial
park,
Gushu,Baoan
District,Shenzhen,Guangdong,China
Gushu,Baoan
District,Shenzhen,Guangdong,China
Manual
Manual
inverter/ups
inverter/ups
Power
Equipment
Power
Equipment
Building
6
layer,
Building
6
layer,
CO.,LTD
CO.,LTD
Hangcheng
Road
Hangcheng
Road
,Xixiang
,Xixiang
Advertisement
Summary of Contents for ORO DC12V-AC220V
- Page 1 Product Manual Product Manual Power inverter/ups Power inverter/ups Shenzhen Power Equipment CO.,LTD Shenzhen Power Equipment CO.,LTD Address Dunfa industrial park, Building layer, Hangcheng Road ,Xixiang Address Dunfa industrial park, Building layer, Hangcheng Road ,Xixiang Gushu,Baoan District,Shenzhen,Guangdong,China Gushu,Baoan District,Shenzhen,Guangdong,China Before designing and during the production, the safety of operators and products all have been considered.
- Page 2 be reversed, the diameter shall comply with the conditions of safe use, for the cable, keep it as short as possible. (9)Do not open the case of the inverter without any special circumstances; otherwise we will not classify it as product warranty matter. (10)Please keep this manual for future reference.
- Page 3 battery. B、Give priority to the use of DC Recharge battery mainly from solar energy,Utility Grid assist recharging. Step1 ： When Utility Grid is normal,voltage of battery higher than 11V,DC turn into AC through inverter and power load. Step2：When the voltage of battery is lower than 11V,the system switch to Utility Grid automatically and recharging battery.
- Page 4 in5s.This mode save unnecessary power. 3.Characters 1、Pure sine wave output; do not harm electrical equipment, effective protection of the load; comes with UPS conversion function, high-speed conversion, the conversion time less than 5ms; ensure uninterrupted electricity; 2、CPU management, intelligent control, modular composition, which is more convenient for after-sale maintenance;...
- Page 5 12、Pure copper transformer , blind post and wire.High density conformal coating.Double ball bearing mute dc fan,Large LCD screen,Large current terminals,Best electric components,best packing,safe,efficient and high level. 4.Type and specification Specification Type Discribtion DC12V-AC220V 300W， 600W， 800W， 1KW， 1.5KW， 2KW， 1：AC voltage： AC110V/100V/120V/230V/ DC24V-AC220V 300W， 600W， 800W， 1KW， 1.5KW， 2KW， 240V 3KW，4KW，5KW，6KW...
- Page 6 63.0vdc ± 1.8Vdc （72V） 10.0Vdc ± 0.3Vdc （12V） Low Voltage Shut off (shut off 20.0Vdc ± 0.6Vdc （24V） when battery’s voltage is over 40.0Vdc ± 1.2Vdc （48V） low) 60.0Vdc ± 1.8Vdc （72V） Low Voltage Recovery 12.0Vdc ± 0.3Vdc (12V) (Automatic Boot when 24.0Vdc ±...
- Page 7 Efficiency Conversion Time (AC to DC) <4ms Conversion Time (DC to AC) <8ms AC output specifications Rated output voltage (V) 220Vac/230Vac/240Vac 110Vac/120Vac/130Vac Output Voltage Range ±10% rms Rated output frequency(Hz) 50Hz ± 0.3Hz/60Hz ± 0.3Hz(Optional) Power Factor Output Waveform Pure sine wave Waveform distortion ≤3% ( Linear load )
- Page 8 6、The battery type set Because of the batteries have many types, different types of them have different charging parameters, to effectively protect batteries, we specially design a rotary switch of selected batteries types on the inverter’s panel. As long as to select the corresponding gear of battery’s type, our inverter can be guaranteed the most suitable charging specification.
- Page 9 DC Voltage Charge current (±5A) Initial Charge According to battery type Voltage Charger Circuit Breaker short-circuit protection Constant current charging( Constant current stage) → constant voltage Charging Rule charging (constant voltage stage) → float charging (constant voltage stage) Boost CC Stage：If AC input is applied, the charger will run at full current in CC mode until the charger reaches the boost voltage.
-
Page 10: Lcd Display
“First grade”power save Detect load automatically, when load≥ 30w,boot,otherwise stay by Boat switch “Zero grade”turn off Turn off “Second grade”boot Normal working mode First green indicator on, stand for saving power P-Save mode(load≤30w) Second green indicator on, stand for AC utility grid supply electricity mode Third yellow indicator on, stand for battery inverter to supply power Mode... - Page 11 Broken type display Communication broken （0-Nor 1-Bro） TX 000000 Battery down voltage （0-Nor 1-Bro） 100000 Inverter broken （0-Nor 1-Bro） 010000 Fan broken （0-Nor 1-Bro） 001000 Output overload （0-Nor 1-Bro） 000100 Output circuit （0-Nor 1-Bro） 000010 Battery broken （0-Nor 1-Bro） 000001 Postscript：TX 000000 “TX”means monitor can`t connect inverter well.built-in wire broken.
- Page 12 Low-voltage Red LED Lighting, and the buzzer beep 0.5s every 5s Red LED Lighting, and the buzzer beep 0.5s every 1s, and shut down after Over-voltage 60s. 110%< load<125%, no alarm in 14 minutes, beeps every 5s in 15th minute, and shut down after 1 minutes.
- Page 13 D C - D C + D C I N P U T 1 2 V 2 4 V 4 8 V 黑 色 红 色 P o w e r S a v e r A u t o 节...
-
Page 14: Inverter ＆ Charger
Remote port RS232 PS-ON 节能开机 关机 PS-ON Alarm 节电 市电 逆变 充电 故障 BAT type DIP-SW 正常开机 电池类型 Next page 翻页 50 AC Solar / UPS Inverter output protect AC OUTPUT AC IN SW AC OUT SW Inverter ＆ Charger Charger input protect MAX 8A... - Page 15 Attention：No AC input and output reverse connecting! No power line and zero line reverse connecting! No DC input and output reverse connecting! 10、Description of Temperature-control fan （Give priority to DC） Control Item Start Stop speed T≤60℃ T﹥65℃ Temperature of 65℃≤T﹤85℃ T≤60℃...
-
Page 16: Appendix 1.Instruction Of Lcd Inverter Indicator And Buzzer
Appendix 1.Instruction of LCD inverter Indicator and Buzzer POWER Item SAVER P-grid inverter charge alarm buzzer Status × √ × √ × × × √ × √ × × Line Mode Float × √ × √ × × Standby × √... - Page 17 Appendix2：Instruction of general type indicator and buzzer Indicator light Over Status Power overl -tem erte inverte Item save buzzer broken × × × × √ × √ √ × × × √, Line Mode × × × × × √ √...
- Page 18 Appendix3: Product Warranty Cards Warranty Card Products name Item number Model Purchase date Warranty Buyer Contacts Distributor Maintenance Record date...
