Summary of Contents for Herz T-Control
- Page 1 Operating instructions Cascade control...
-
Page 2: Introduction
Your heating system is powered by a HERZ pelletstar boiler system and we are pleased to be able to count you as one of our many satisfied owners of a HERZ system. The HERZ boiler is the result of years of experience and continuous improvement. -
Page 3: Table Of Contents
General notes ............................. 5 1.3.2 Operation ............................6 1.3.3 Maintenance ............................6 HERZ CASCADE WITH T-CONTROL ..........7 Extension modules at cascade operation ..................7 Hardware connections ........................7 Cascade wiring ..........................8 Cascade parameters ........................9 Cascade overview ..........................9 2.5.1... -
Page 4: Safety Notes
Should you have any queries, please call us on +43/3357 / 42840-840. Initial commissioning must be carried out by the HERZ Customer Service department or an authorised specialist (otherwise any warranty claim will not be applicable). Ventilate the pellet storage area for ~ 30 minutes before going in. -
Page 5: Warning Notes
HERZ. Documents from the manufacturer relating to the heating devices... -
Page 6: Operation
(message displayed: MIN O2 [%] 5.0) recommended for maintenance to be carried out regularly by authorised personnel or by the HERZ The noise generated by the machine during Customer Service department. operation does not present any danger to health. -
Page 7: Herz Cascade With T-Control
HERZ cascade with T-Control 2 HERZ CASCADE WITH T-CONTROL Herz offers with T-Control the opportunity to cascade 2-8 T-Control modules together. The Cascade contains boilers of a heating system which can be operated parallel or serial. For example one boiler provides the basic load of a building and the other remaining boilers are requested at heat requirement (e.g.: e.g.: peak... -
Page 8: Cascade Wiring
(CAT5) has to be installed by customer. Ethernet switch Remote control (to X4) Ethernet switch Cascade (to X5) Figure 2.3 3 to 8-Cascade wiring Ethernet switch Remote control (to X4) Figure 2.4 2-Cascade wiring Bedienungsanleitung Kaskadenregelung T-Control Englisch V1.1... -
Page 9: Cascade Parameters
HERZ cascade with T-Control 2.4 Cascade parameters At T-control menu „system settings” in menu „K+“ cascade parameters get set (service code protection). Cascade parameters have to be set at every cascade user. Push the „K+“ button to get into the cascade overview. -
Page 10: Actual
The list in cascade overview sets the cascade order, e.g.: which cascade user gets master boiler first. Choose a not assigned user to set or offset the actual control system (T-Control). Click the saving sign to save changes. The prioritization of the master boiler within cascade is set by the arrangement 1-X. -
Page 11: Cascade Parameter
If start hysteresis = 0, only waiting time will be active Boiler runs only as slave boiler within the cascade. Boiler will never become a master Auxiliary boiler boiler. This operation mode is relevant for e.g.: peak load boiler or auxiliary boiler. Bedienungsanleitung Kaskadenregelung T-Control Englisch V1.1... -
Page 12: Udp User
HERZ cascade with T-Control 2.8 UDP user The UDP user menu (see Figure 2.8) shows only the T-Control panels within the cascade. Figure 2.8 UDP user Shows the serial number of the HZS 566 respectively T-Control panel within the Serial Nr. -
Page 13: Explanation Of The Symbols
When auxiliary boilers are provided within the cascade (e.g.: peak load), according to this, they can be addressed. We recommend to operate cascade heating systems only with buffers. Bedienungsanleitung Kaskadenregelung T-Control Englisch V1.1... -
Page 14: Recommended Cascade Diagrams
Cascade parameter recommendation 3.1 Recommended cascade diagrams Bedienungsanleitung Kaskadenregelung T-Control Englisch V1.1... - Page 15 Cascade parameter recommendation Bedienungsanleitung Kaskadenregelung T-Control Englisch V1.1...
- Page 16 Österreich/Austria Herz Energietechnik GmbH Herzstraße 1 7423 Pinkafeld +43 (3357) / 42 84 0 – 0 +43 (3357) / 42 84 0 – 190 office-energie@herz.eu Deutschland/Germany Herz Armaturen GmbH Fabrikstraße 76 D-71522 Backnang +49 (7191) 9021 – 0 +49 (7191) 9021 – 79...
