AST a810 Manual

Weighing controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Weighing Controller
A 810
Manual
Rev. 1.10-22
A.S.T. Angewandte SYSTEM-TECHNIK GmbH Dresden
Marschnerstraße 26
01307 Dresden, Germany
Telefon (03 51) 44 55 30
Telefax (03 51) 44 55 555
www.ast.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the a810 and is the answer not in the manual?

Questions and answers

Summary of Contents for AST a810

  • Page 1 Weighing Controller A 810 Manual Rev. 1.10-22 A.S.T. Angewandte SYSTEM-TECHNIK GmbH Dresden Marschnerstraße 26 01307 Dresden, Germany Telefon (03 51) 44 55 30 Telefax (03 51) 44 55 555 www.ast.de...
  • Page 3 Thank You! Thank you for purchase A.S.T. products! SAFETY PRECAUTION The integrated circuits used in this equipment are highly immune to noise and RFI when properly installed in the unit. The terminal on the rear panel must be grounded directly, not with the AC ground. Therefore, when shipping please always use original packing (conductive material) for shiping.

  • Page 4: Table Of Contents

    Manual of Weighing Controller A 810 Table of contents DESCRIPTION ..............................7 1.1..............................7 RONT ANEL 1.1.1. Numeric Display............................7 1.1.2. Unit Display ............................7 1.1.3. Status display............................7 1.1.4. Keypad..............................9 1.1.5. Rear Panel............................10 1.2............................10 ANEL CUT SIZE CONNECTIONS ...............................11 2.1..........................11 OADCELL ONNECTOR 2.2.
  • Page 5 Manual of Weighing Controller A 810 3.1.6. Submenu “Control”..........................39 3.1.6.1. Sequence mode selection “SMS” ........................39 3.1.6.2. Feeding / Discharging control “Fd-Con”......................39 3.1.6.3. Complete signal output mode “CSO-MD” .......................39 3.1.6.4. User function “UF1” ............................40 3.1.6.5. User function “UF2” ............................40 3.1.6.6. Set to default “dEF” ............................40 3.1.7.
  • Page 6 Manual of Weighing Controller A 810 3.1.13.2.4. Gateway “Gate_W“..........................59 3.1.13.2.5. Set to default “def”..........................59 3.1.14. Submenu Key enable “KE” .........................60 3.1.14.1. Function – Key “Func”..........................60 3.1.14.2. Shift – Key “SHIFT” ........................... 60 3.1.14.3. Set – Zero – Key “ZE” ..........................60 3.1.14.4.
  • Page 7 Manual of Weighing Controller A 810 4.3..............................76 RINTERS 4.4..........................76 EMOTE ISPLAY NITS 4.4.1. A810 Remote Display Units.........................76 4.4.2. Foreign Remote Display Units ......................77 4.5. PC / SPC ..............................77 4.5.1. Acknowledgement Protocol .........................77 4.5.2. Structure of a Data Frame........................77 4.5.3.
  • Page 8 Manual of Weighing Controller A 810 0 History 1.10.22 (May 11): signal output B21 used in sequence-mode; generation of Err109 due to missing confirmation signal at input pins D18 or D19 (with user function “230” associated); detailed description of signal input D18/19 at page 65; change of picture “PC-Interface”...

  • Page 9: Description

    Manual of Weighing Controller A 810 1. Description 1.1. Front Panel Unit display Numeric display STAB Status display ZALM TARE GROSS HOLD LO LIM HI LIM FUNC SHIFT UPPER OVER NEAR Z GROSS TARE /NET LOWER UNDER FINAL USER Keypad The front panel contains a 7 digit numeric display, a two digit alphanumeric display, a multiple status display and 16 key membrane pad.
  • Page 10 Manual of Weighing Controller A 810 STAB : Turns on, if weighing value is stable. : Turns on, if Tare weight is displayed. TARE : “TARE” turns on, if Tare subtraction is active and Tare has a content. : Turns on, if Net weight is displayed. GROSS : Turns on, if Gross weight is displayed.

  • Page 11: Keypad

    Manual of Weighing Controller A 810 1.1.4. Keypad Display in weighing mode Display in setup mode Entry in setting modes according FUNC Shifting active cursor position one followed key inputs position to the left (see page 67) Entry into code display modes Shifting active cursor position one according followed key inputs SHIFT...

  • Page 12: Rear Panel

    AC input is labeled with the standard AC voltage of the country in which the unit was purchased. Available voltage is: 115 or 230 V AC Confirm the correct voltage on your A810. AC frequency is 48 to 62 Hz and voltage supply -15 to +10% Control signal Input/...

  • Page 13: Connections

    Manual of Weighing Controller A 810 2. Connections 2.1. Loadcell Connector Shield Frontview 4 wire standard: (+EX) 6 WIRE FOR REMOTE SENSING: (+EX) (+SE) (-SE) Page A.S.T. Angewandte SYSTEM-TECHNIK GmbH Dresden...

  • Page 14: Pin- Assignment Of Control Signal Input / Output Connector

    Manual of Weighing Controller A 810 2.2. PIN- Assignment of Control Signal Input / Output Connector Connector Power Control- Output- Signals Control- Input- Signals RS232, RS485, TTY- Interface, 4...20mA norm output Connector B / Output-Signals Connector D / Input-Signals Signal Signal D/Z ON SP3/ CPS...
  • Page 15 Manual of Weighing Controller A 810 Connector E Description Remarks RxD5+ TTY (Port 4) RxD5- TTY (Port 4) TxD5+ TTY (Port 4) TxD5- TTY (Port 4) RS232 RS232 TxD2 RS232 (Port 1) RxD2 RS232 (Port 1) R(A) RS485 (Port0) R(B) RS485 (Port0) D(Z) RS485 (Port0)
  • Page 16 Manual of Weighing Controller A 810 Relay outputs (connector B) and Opto inputs (connector D) can either be with power (active) or neutral (passiv) depending on interal jumper position on mainboard. Both Input and Output connectors are separated into four groups. Each group contains four signals with dedicated COM. By setting each individual jumper’s position to decide each group whether the I/O are with power or neutral.
  • Page 17 Manual of Weighing Controller A 810 Jumper-Positions: Connector B / Output-Signals Connector D / Input-Signals Signal Polarity (JP-OUT1…4) Signal Polarity (JP-IN1…4) none *2 none *2 none none none D/Z ON none SP3/ CPS none Tare subtraction ON none near zero none Tare subtraction OFF none...

  • Page 18: Control Input Signals

    Manual of Weighing Controller A 810 2.3. Control Input Signals - Gross / Net (G/N) (pin D4) (edge triggered) Display value is switched between Gross and Net by pressing key or by changing input When input signal is shorted to COM (OFF ON) Net weight is displayed. When input signal is opened to COM (ON OFF) Gross weight is displayed.
  • Page 19 Manual of Weighing Controller A 810 - Feed/ Discharge (pin D9) (level triggered) Feed or Discharge is accessed by shorten(Discharge) or open (Feed) input D9 to COM. “Fd-Con” (3.1.6.2 in submenu “control” at page 39 has to be “2”). 0: feeding 1: discharge 2: external control During Dischrage mode, “Upper/ Lower Limits”...
  • Page 20 Manual of Weighing Controller A 810 - User Function II (pin D19) (edge triggered) This user defined function is activated when shorten input D19 to COM (OFF ON). Refer to 3.1.16.2 at page 64. - Code selection (pins D20-23) (level triggered) This binary input select active codeset when inputs are shortened to COM.

  • Page 21: Control Output Signals

    Manual of Weighing Controller A 810 2.4. Control Output Signals - Setpoint1 (SP1) (Pin B1) (low-activ) Will set „ON“, if setpoint1 SP1 (3.2.3.2.7, p.69) of active codeset has been exceeded. - Setpoint 2 (SP2) (Pin B2) (low-activ) Will set „ON“, when setpoint2 SP2 (3.2.3.2.5, p.68) of active codeset has been exceeded. - Setpoint3/ Compensationpoint (SP3/CPS) (Pin B3) (low-activ) Will set „ON“, when setpoint3 SP3/CPS (3.2.3.2.3, p.68) of active codeset has been exceeded.
  • Page 22 “NZC” (p.45) and Setpoint SP1 confirmation “SPC” (p.46) possible. - Weight error (Pin B24) (low-activ) Will set „ON“, when an error of A810 or load cell has occured. Refer to „Description of States of Error“ at page 112. Page A.S.T. Angewandte SYSTEM-TECHNIK GmbH Dresden...

  • Page 23: How To Get Started

    Manual of Weighing Controller A 810 3. How to get started At delivery the A810 is preset on default parameters (comply with legal-for-trade) to operate as a simple scale provided the resolution is set and the calibration has been carried out.

  • Page 24: Parameter Setup Section

    Manual of Weighing Controller A 810 3.1. Parameter setup section To enter into the parameter setup please press SHIFT p. 30 p. 32 p. 36 p. 24 p. 34 p. 24 p. 30 p. 34 p. 32 p. 36 p. 24 p.
  • Page 25 Manual of Weighing Controller A 810 p. 48 p. 39 p. 41 p. 44 p. 50 p. 39 p. 44 p. 48 p. 50 p. 41 p. 39 p. 48 p. 50 p 41 p. 44 p. 39 p. 48 p.

  • Page 26: Submenu "Basic

    KG units The Weighing Controller A810 will be calibrated with this unit and after each restart this unit is shown. Note: Free Unit “FU” is scaled and calibrated as “KG”. Setting appropriate chars for “FU” is done in “basic”...

  • Page 27: Range Of Zero Setting Lower Limit "Llzs

    Manual of Weighing Controller A 810 b A S 3.1.1.3. Range of zero setting TARE lower limit “LLZS” The lower limit of zero setting range can be adjusted between 0 … –20% of full scale. GROSS /NET default setting: 1 GROSS >...

  • Page 28: Power-On Zero Setting "Pozs

    Manual of Weighing Controller A 810 b A S 3.1.1.7. Power-on zero TARE setting “POZS” TARE This toggle decision enables or disables the power-on zero setting option. Range is selected at 3.1.1.3 GROSS o F F /NET (Lower Limit) and 3.1.1.4 (Upper Limit) previous page.

  • Page 29: Stable Number "Stan

    Manual of Weighing Controller A 810 b A S 3.1.1.11. Stable number “StAN” TARE Set in terms of numbers in the range between values from 10 … 250. This value defines the number of averaged ADC values taken into account GROSS for testing the stable condition.

  • Page 30: Enable Quickstart "Enqs

    Manual Weighing Controller A 810 b A S 3.1.1.15. Enable quickstart TARE “EnQS” TARE This toggled decision defines whether the Power-on self test of the display is a full GROSS o F F /NET version (OFF) or just limited to a short segment test (ON).

  • Page 31: Set To Default "Def

    Manual of Weighing Controller A 810 b A S TARE 3.1.1.18. Set to default “dEF” Toggled decision to set all parameters TARE of the “BASIC” sub menu to the default values when ON. GROSS o F F /NET default setting: off GROSS /NET C L E...

  • Page 32: Submenu "Scale Division

    Manual Weighing Controller A 810 3.1.2. Submenu “Scale division” This menu is used to setup parameters for the selected unit “MU” 3.1.1.2 at page 24. Each used unit needs to be defined, the full scale interval (Dn) and the verification scale interval (VS). See 6.1”Calibration procedure”...
  • Page 33 Stability settings are done according to operators environment. set “MU” to “t” 3.1.1.2 “Dn” = 30t / 0.002t = 15000 set “Dn” to 15000 A810 is not legal-for-trade 3.1.2.1.1 set “VS” = 0.002 3.1.2.1.2 for confirmation of correctly set parameters: “FS” shows 30.002t 3.1.2.1.3...

  • Page 34: Submenu "Adc

    Manual Weighing Controller A 810 3.1.3. Submenu “ADC” This menu is used to select the ADC and filter characteristics of the data acquisition. Analogue parameters like gain and offset are preset during the production test procedure and need no further adjustment.

  • Page 35: Display Frequency

    Manual of Weighing Controller A 810 3.1.3.4. Display Frequency d I S P TARE Display frequency 0.4…32 This option regulates refreshing rate samples/sec of display. Value * 10ms = frequency. TARE Lower value means faster diplay GROSS frequency. /NET default setting: 030 (3Hz) GROSS /NET 3.1.3.5.

  • Page 36: Submenu "Calibration

    Manual Weighing Controller A 810 3.1.4. Submenu “Calibration” This menu allows the operator to perform either a practical or a theoretical calibration. During the practical calibration a desired load has to be applied a zero / full scale span calibration by using of at least two points.

  • Page 37: Additional Calibration Points "Addp

    Manual of Weighing Controller A 810 C A L I B 3.1.4.2. Additional calibration TARE points “AddP” To reduce the influence of any non linearity of the load cell arrangement 0 0 0. 0 additional calibration points might be entered by applying additional test weights.

  • Page 38: Submenu "Alibi

    Manual Weighing Controller A 810 3.1.5. Submenu “Alibi” This submenu defines the settings for internal legal-for-trade memory. This memory is used for proof of weighing. It is written to, when operator “prints” to this memory. The string is as follows: <Consecutive Number><Date><Time><1><Gross><Tare><Net><Productcode><0>...

  • Page 39: Alibi Confirmation "A-Prt

    Manual of Weighing Controller A 810 A L I 3.1.5.4. Alibi confirmation “A- A - P TARE Prt” TARE This parameter defines wether the print to Alibi memory is confirmed on display with “A-Prt” for 3s when done. GROSS o F F A - P /NET default setting: on...

  • Page 40: Set To Default "Def

    Manual Weighing Controller A 810 A L I 3.1.5.8. Set to default ”dEF” TARE Toggled decision to set all parameters TARE of the “Alibi” sub menu to the default values when ON. o F F GROSS /NET Page A.S.T. Angewandte SYSTEM-TECHNIK GmbH Dresden...

  • Page 41: Submenu "Control

    Manual of Weighing Controller A 810 3.1.6. Submenu “Control” This submenu defines the settings whether the A810 is working in “Comparison Mode” and “Sequence Mode” and certain in- and outputs. c o n t r 3.1.6.1. Sequence mode TARE selection “SMS”...

  • Page 42: User Function "Uf1

    Manual Weighing Controller A 810 c o n t r TARE 3.1.6.4. User function “UF1” This function is activated once when complete signal is ON at the beginning of “Complete Output Time”. GROSS Refer to 7.2 /NET “Survey of Operating Functions” at page 109.

  • Page 43: Submenu Comparison Mode "Comp

    Manual of Weighing Controller A 810 3.1.7. Submenu comparison mode “COMP” All settings in this submenu are for the basic behaviour in “Comparison Mode” and “Sequence Mode”. 3.1.7.1. Near-Zero-Compare “nZC” TARE This selection defines whether Gross or Net will be used to carry out the Near-Zero-Compare mode.

  • Page 44: Over-Under-Go-Compare Mode "Ouc-Md

    Manual Weighing Controller A 810 3.1.7.4. Over-under-go- O U C - TARE compare mode “OUC- MD” This selection defines when Over and Under signal is taken into account. GROSS /NET 0: compare always GROSS 1: compare when judging input is ON /NET 2: compare when complete output is ON 3: compare when complete output is ON...

  • Page 45: Complete Output Time "Coti

    Manual of Weighing Controller A 810 3.1.7.8. Complete output time TARE “COTI” This timer defines duration between 50…9999ms of how long the complete output pin is ON. This setting is GROSS /NET according to 3.1.6.3 “CSO-MD” at page 39. GROSS >...

  • Page 46: Submenu "Sequ

    3.1.8. Submenu “SEQU” In this submenu additional settings for “sequence mode” can be set. 3.1.8.1. Auto Zero Count “AZC” TARE The A810 will do an “Auto zero” for that number of starts. “Auto zero” is disabled GROSS do an “Auto zero” every start /NET do an “Auto zero”...

  • Page 47: Auto Free Fall Compensation "Affc

    Manual of Weighing Controller A 810 3.1.8.4. Auto free fall TARE compensation “AFFC” TARE Toggled decision to set “Auto free fall compensation” ON or OFF. GROSS o f f /NET default setting: off GROSS /NET Refer to application note 6.9 at page 107. A F F C - 3.1.8.5.

  • Page 48: Setpoint Sp1 Confirmation "Spc

    Manual Weighing Controller A 810 3.1.8.8. Setpoint SP1 TARE confirmation “SPC” Toggled decision to ensure a weight TARE below SP1 during starting a cycle. When weight is higher SP1 GROSS o F F “Err 105” is shown. /NET default setting: off GROSS /NET 3.1.8.9.

  • Page 49: Set To Default "Def

    Manual of Weighing Controller A 810 TARE 3.1.8.12. Set to default “dEF” Toggled decision to set all parameters TARE of the “sequence” sub menu to the default values when ON. o F F GROSS /NET Page A.S.T. Angewandte SYSTEM-TECHNIK GmbH Dresden...

  • Page 50: Submenu "Print

    /NET 3.1.9.2. Printer port select “PoRT” TARE Set in terms of numbers to defines the physical address of the communication port at A810 to the printer. GROSS default setting: 2 (Pins E19, 20) /NET Refer to 2.2 at page 12.

  • Page 51: Protocol Typ Select "Hndsh

    Manual of Weighing Controller A 810 P r i H n d 3.1.9.5. Protocol typ select TARE “HndSH” TARE This toggled decision defines whether a software Xon / Xoff in enabled. o F F H n d default setting: on GROSS /NET H n d...

  • Page 52: Submenu Pc-Interface "Pc

    Manual Weighing Controller A 810 3.1.10. Submenu PC-Interface “PC” This menu defines all parameters required for communication between A810 and a PC. TARE 3.1.10.1. PC-Interface “EN” This toggled decision defines whether the TARE PC-port in enabled. GROSS o F F...

  • Page 53: Block Check Character Select "Bcc

    Manual of Weighing Controller A 810 3.1.10.5. Block check TARE character select “bCC” TARE This toggled decision defines whether the data transmission includes block check GROSS o F F /NET character. GROSS default setting: off /NET 3.1.10.6. ACK / NAK-Protocol TARE “ACK”...

  • Page 54: Submenu "2Nd Panel

    3.1.11. Submenu “2nd Panel” The following menu is used for a 2nd display as remote control that is mounted in distance from A810. For example A810 is mounted in rough and hot environment and can be operated from a control center via the 2nd panel.

  • Page 55: Set To Default "Def

    Manual Weighing Controller A 810 2 n d P a n TARE 3.1.11.5. Set to default “dEF” Toggled decision to set all parameters TARE of the “2nd Panel” sub menu to the default values when ON. o F F GROSS /NET Page A.S.T.

  • Page 56: Submenu "Dac

    Manual Weighing Controller A 810 3.1.12. Submenu “dAC” This submenu defines the function of the onboard digital to analogue converter for an norm standard output of 4…20mA resp. 0…10V. 3.1.12.1. Activate DAC “Act” TARE This toggled decision defines whether TARE the output to the DA conversion is enabled.

  • Page 57: Limit Definition "Lim

    Manual Weighing Controller A 810 3.1.12.4. Limit definition “LIM” TARE This selection is required to define whether the output range (defined at TARE 3.1.12.3 “NI”) should be related to o F F GROSS on: 0…100% fullscale /NET off: UNDER to OVERLOAD – Limits (refer to “”LUNL”...
  • Page 58 Manual Weighing Controller A 810 Examples: Settings: = on; = off; = off; Under Over weight Fullscale = off; = off; = on; = off; = off; = on; Under Over weight Under Over weight Fullscale Fullscale default setting = on; = on;...

  • Page 59: Submenu Interface Option "If

    Manual Weighing Controller A 810 3.1.13. Submenu Interface option “IF” This submenu defines the required information for Profibus DP or TCP/IP – interface if equipped. TARE 3.1.13.1. Submenu P r o f i B “Profibus“ Settings for Profibus selectable. TARE 3.1.13.1.1.

  • Page 60: Submenu "Ethernet

    Notice: Content of display will be left shifted to show whole data. TARE N E t 3.1.13.2.3. Subnetmask “Net_M“ Selection of subnetmask of A810 GROSS in range between 1…255.255.255.255 2 5 5 2 5 5 2 /NET default setting: 255.255.255.000...

  • Page 61: Gateway "Gate_W

    Manual Weighing Controller A 810 TARE E t h e r n G A T E TARE 3.1.13.2.4. Gateway “Gate_W“ Selection of gateway-address of A810 in range of 1…255.255.255.255 GROSS default setting: 192.168.000.254 1 9 2 1 6 8 0 /NET...

  • Page 62: Submenu Key Enable "Ke

    Manual Weighing Controller A 810 3.1.14. Submenu Key enable “KE” This menu defines which keys are enables or disabled during weighing mode. TARE 3.1.14.1. Function – Key “Func” This toggled decision defines whether TARE -Key is enabled in weighing FUNC GROSS o F F mode.

  • Page 63: Tare - Key "Ta

    Manual Weighing Controller A 810 TARE 3.1.14.5. Tare – Key “TA” This toggled decision defines whether TARE -Key TARE is enabled in weighing mode. GROSS o F F /NET default setting: on GROSS /NET TARE 3.1.14.6. Enter – Key “ENT” This toggled decision defines whether TARE -Key...

  • Page 64: Submenu Key Functions "Kf

    Manual Weighing Controller A 810 3.1.15. Submenu key functions “KF” This menu defines the assignment of functions to key combinations. These settings are used for combining keys with any user defined action. Refer to appendix 7.2 “Survey of Operating Functions“ at page 109.
  • Page 65 Manual Weighing Controller A 810 Function Description (Refer to 7.2 at page 109) Default settings for “Shift” + edit Preset Tara weight show date for 5 seconds show time for 5 seconds show input ratio [mV/V] show Tara weight clear Tara weight (set Net to Gross) Page A.S.T.

  • Page 66: Submenu "Input

    Manual Weighing Controller A 810 3.1.16. Submenu “Input” The following menu defines the setup of the available inputs D°18 and 19. The instrument allows to run a function by activating an control input. Refer to appendix 7.2 “Survey of Operating Functions” at page 109.

  • Page 67: Set To Default "Def

    Manual Weighing Controller A 810 I n P 3.1.16.5. Set to default “dEF” TARE TARE Toggled decision to set all parameters of the “Input” sub menu to the default values when ON. o F F GROSS /NET Input signal D18 dominates D19. When D18 keeps “Low”...

  • Page 68: Submenu "Diagnostics

    Manual Weighing Controller A 810 3.1.17. Submenu “Diagnostics” This function is required to carry out a basic test of the load cell, the instrument and their interconnections. 3.1.17.1. ADC – Integer output “I - INT” This function shows the direct output value of the 24-Bit-ADC.

  • Page 69: Combination Of "Func" And Any Numeric Key

    Manual Weighing Controller A 810 3.2. Combination of “Func” and any numeric key To call one of the following functions press “FUNC” key and after that please press any numeric key. These functions are dedicated to numeric keys and can not be edited by user. To switch back to weighing mode press “TARE”...

  • Page 70: Parameter Set Of Code N° 0

    Manual Weighing Controller A 810 c o d E 3.2.3.2.1. Parameter set of code N° 0 GROSS After confirming this by pressing /NET the following parameter can be set. codeset 1 3.2.3.2.2. Parameter F I N TARE “FINAL” of code N°...

  • Page 71: Constant Analog Output "Sp2 Out

    Manual Weighing Controller A 810 c o d E s P 2 3.2.3.2.6. Constant analog TARE output “SP2 out” This parameter is only available when Parameter “SPFix” (3.1.12.6) is “ON”. GROSS This parameter equates an analog output /NET between 0% (0V / 0mA) and 100% (10V / 20mA) at setpoint SP2.

  • Page 72: Parameter "Over" Of Code N° 0

    Manual Weighing Controller A 810 c o d E 3.2.3.2.9. Parameter TARE “Over” of code N° 0 This parameter defines when OVER is set ON. It refers to “Final” value and GROSS 0 1 0. 0 /NET OVER is set when actual weight >...

  • Page 73: Parameter "Near Zero" Of Code N° 0

    Manual Weighing Controller A 810 c o d E 3.2.3.2.13. Parameter TARE “Near Zero” of code N° 0 This parameter defines NEAR ZERO. NEAR ZERO is set ON when GROSS 0 1 5. 0 /NET actual weight < NEAR ZERO. “0”...

  • Page 74: Show Accumulation Total Sum (3)

    Manual Weighing Controller A 810 3.2.4. Show accumulation total sum (3) Funtion Call 196: According present selected code. Parameter “FOU-CMD” (3.1.7.2 at page 41) defines wheter Net or Gross weight is accumulated. Scrolling is done when accumulation sum is greater than 999.999.999.

  • Page 75: Clear All Codesets (6)

    Manual Weighing Controller A 810 3.2.7. Clear all codesets (6) Funtion Call 195: Clear all ten codesets and accumulationall memories. c L r c o d E FUNC LOWER TARE o F F c o d E GROSS /NET c o d E 3.2.8.

  • Page 76: Edit Consecutive Number (8)

    Manual Weighing Controller A 810 3.2.9. Edit Consecutive number (8) Funtion Call 45: This function allows the operator to enter a consecutive number. This number can be shown on the printout and is incremented every time a printout is initiated. 0 0 0 0 0 FUNC FINAL...

  • Page 77: Serial Interfaces

    Manual Weighing Controller A 810 4. Serial Interfaces 4.1. Modes of Operation of the Serial Interfaces Each of five serial interfaces of an A810 terminal is suited for the asynchronous exchange of data in full duplex mode. 4.2. Exchange of a Character 4.2.1.

  • Page 78: Physical Protocol (Handshake)

    4.3. Printers The type A810 terminal is able to communicate with different printers. The type of printer has to be set during commissioning. Traffic between a terminal and a printer depends on the selected mode. This applies to the transmission of certain print commands (Escape sequences).

  • Page 79: Foreign Remote Display Units

    The default setting of an A810 terminal is such that it will transmit data only in case of error when no request is received.

  • Page 80: Keyboard Commands

    Manual Weighing Controller A 810 4.5.3.1. Keyboard Commands KEYS_ON Command No 20h Parameters: none The entire keyboard of a terminal is re-enabled (made active) after the command KEYS_OFF. This applies also to a second operating unit possibly connected. This is the on-condition.

  • Page 81: Commands For Weighing Operations

    ASCII string (integer) Example: command from PC/SPS '7KLM20X100P1' the display reads out: input of 7 5 ‘Ret’ response by A810 'W75' 4.5.3.2. Commands for Weighing Operations S_D_STI Command No 25h Parameters: none The weight value indicated by the display (gross, net or tare) is transmitted one single time as soon as the display is updated after the dwell condition has been met.
  • Page 82 Manual Weighing Controller A 810 The continuous transmission of the data on display as started by S_D_CONT is shut down. S_ALL Command No 29h Parameters: none The weighing data gross, net and tare weights as well as status are transmitted. Returned data record: * Status byte condition of load cell, see Table 2...
  • Page 83 '0' for inactive / '1' for active * identifier 'S' for dwell range of scale * number ASCII string of 1/10 divisions * identifier irrelevant for A810, is transmitted for reason * numeral ‘0’ of compatibility with previous controller Example: 'A2500P20I9Z1S10F0' 2500 divisions, count-by step 0.002*unit of...

  • Page 84: Commands For Printer Output

    Manual Weighing Controller A 810 4.5.3.3. Commands for Printer Output E_TIME Command No 2Eh Parameter: time This parameter is made up of time in the format HH:MM:SS for setting the real-time clock. Example: '.17:39:05' time: 17h 39min 5sec E_DATE Command No 2Fh Parameter: date This parameter is made of date in the format YY.MM.DD for setting the real-time clock.
  • Page 85 This command is for direct printing to logical printer 1. Printdata can contain printable characters as well as ESC-sequencies. A binary zero is interpreted as end of datastream. Length of printdata is restricted to 1000 characters. Example: 'CA810' Text ‘A810’ will be printed directly. Page A.S.T. Angewandte SYSTEM-TECHNIK GmbH Dresden...

  • Page 86: Commands For Data Protocol

    ACK and NAK are transmitted according to DIN 66019. A810 will not transmit ACK and NAK. A810 will transmit ACK and NAK enclosed in a block frame made up of STX and ETX. The command takes effect immediately, so command PROTOK is acknowledged already by the newly set protocol.

  • Page 87: Miscellaneous Command

    After command TERMINAL has been transferred all characters contained in a data block are read out by the display of the A810 as far as the display is able to do so. Vice versa the A810 transmits each character entered directly by keyboard to the PC/SPC.

  • Page 88: Behaviour In Case Of Trouble

    Manual Weighing Controller A 810 E_DAC0 Command No 4Eh Parameters: voltage This command is to set DA-converter to a voltage level. Parameter 0 is equal to a voltage of 0V resp. a current of 0mA and the maximum of 4095 (FFFh) is equal to a voltage of 10V resp.

  • Page 89: Examples Of Communication Interfaces

    4. One A810 specified by host is open for communication 5. Format of communication commands are set up in Submenu PC-Interface “PC” at page 50 6. Communication is opened to specified A810 until ADDRESS command to another A810 is sent Page A.S.T.

  • Page 90: Interface

    - Setting the Address ID Menu “PC” submenu Device address “Adr” at page 51. - ADDRESS command 0x02 0x39 0x35 0x03 (hexadecimal) open communication to A810 with address “5” <STX>95<ETX> (String) 4.6.2. RS-232 Interface A810 GND TxD RxD Frontview female...

  • Page 91: Tables Of Serial Interfaces

    S_KEYOFF transmit key code off S_INPUT transmit input of numbers PROTOK set protocol ADDRESS address A810 in TTY-Ring / RS485-BUS LINES define line structure DR_PCON print output by PC on DR_PCOFF print output by PC off S_CONFIG...

  • Page 92: Code-Table A810 Keyboard

    Manual Weighing Controller A 810 4.7.2. Code-Table A810 Keyboard Key name Key code Comment normal to scroll SET TO ZERO key 'Set to zero' TARE key 'TARE' FUNC ‘H’ ‘h’ key ‘FUNC’ SHIFT ‘I’ ‘i’ key ‘SHIFT’ key 'ENT’ GROSS/NET...

  • Page 93: Specifications

    Manual Weighing Controller A 810 5. Specifications General: Power supply 115 / 230 V AC 48 to 62 Hz -15% to +10 % power consumption approx. 15 VA operating temperature -10 to +40°C (14°F to 104°F) storage temperature -20°C to +85°C (-28,4°F to 185°F) <...

  • Page 94: Interface

    5.2. Features / Basic functions Theoretical Calibration In addition to the capability of adjusting the A810 by using calibrating weight a theoretical calibration via the characteristic value and rated load of the load cells is also possible. Auto free fall compensation The automatic free fall compensation (AFFC) provides closer tolerance and better accuracy in batching application.

  • Page 95: Calibration Lock

    Manual Weighing Controller A 810 5.3. Calibration Lock accesseble via Increment ID- Remarks to increment ID- Menu Description reduced setup Number Number ‘dIAG’ diagnostics ‘basic’ basics for weighing ‘Scale div’ scale division ‘ADC’ parameters of A/D-converter ‘CALIB’ calibration ‘ALIBI’ legal-for-trade memory ‘Control’...

  • Page 96: Application Notes

    Manual Weighing Controller A 810 6. Application notes 6.1. Calibration procedure 1: Release Calibration Lock (CAL Switch = ON) at rear panel of A810. 2: Select primary measurement unit “MU” 3.1.1.2. The calibration is done with this unit. This unit is shown on display after each restart of A810.
  • Page 97 When the loadcell is non-linear, the operator can set additional 3.1.4.2 calibration points. In that example the testweight is 50kg. A810 would show approx. 45kg. To adjust this loadcell error, put testweight on and enter 50.00kg in menu “AddP”. Now A810 shows correct weight.

  • Page 98: Theoretical Calibration

    Theoretical calibration is used for calibration without balance weight. It is possible to enter a known input ratio of an load cell to A810. This procedure is not as accurate as calibration with balance weight because tolerances of components influence the result.

  • Page 99: Simple Comparison Mode - Feeding Weighing E . G . 1

    Manual Weighing Controller A 810 6.3. Simple Comparison Mode – Feeding Weighing e.g. 1 Page A.S.T. Angewandte SYSTEM-TECHNIK GmbH Dresden...
  • Page 100 “OUC-MD” in menu 3.1.7.4 at page 42. In this case parameter is set to “2“: compare when complete output is ON”. When set this parameter to 3, A810 will not change any outputs, weighing value or indicators during “Complete Output Time”.

  • Page 101: Simple Comparison Mode - Feeding Weighing E . G . 2

    Manual Weighing Controller A 810 6.4. Simple Comparison Mode – Feeding Weighing e.g. 2 Page A.S.T. Angewandte SYSTEM-TECHNIK GmbH Dresden...
  • Page 102 “OUC-MD” in menu 3.1.7.4 at page 42. In this case parameter is set to “2“: compare when complete output is ON”. When set this parameter to 3, A810 will not change any outputs, weighing value or indicators during “Complete Output Time”.

  • Page 103: Simple Comparison Mode - Discharging Weighing

    Manual Weighing Controller A 810 6.5. Simple Comparison Mode – Discharging Weighing Page A.S.T. Angewandte SYSTEM-TECHNIK GmbH Dresden...
  • Page 104 “OUC-MD” in menu 3.1.7.4 at page 42. In this case parameter is set to “2“: compare when complete output is ON”. When set this parameter to 3, A810 will not change any outputs, weighing value or indicators during “Complete Output Time”.

  • Page 105: Sequence Mode

    Manual Weighing Controller A 810 6.6. Sequence Mode Page A.S.T. Angewandte SYSTEM-TECHNIK GmbH Dresden...
  • Page 106 Manual Weighing Controller A 810 Sequence Mode is activated setting parameter “SMS” in submenu “control” 3.1.6.1 at page 39 to ON. Wheighing sequence starts at the rising edge of Start signal; SP1, SP2, SP3 turn on. In Sequence Mode the Over, Go and Under comparison is always done when the “Complete output” is ON and Judging Count “JC”...

  • Page 107: Sequence Mode Without Judgement

    Manual Weighing Controller A 810 6.7. Sequence Mode without Judgement Entering a Judging Count of 0 in “JC” (3.1.8.2 in submenu “SEQU” at page 44) disables Over, Under and Go comparison during Complete Output Time “CTI”. When SP3/CPS turns OFF, Complete signal turns ON immediately. Timers: t1: Comparison Inhibited Time “CITI”...

  • Page 108: Sequence Mode With Adjust Feeding

    Manual Weighing Controller A 810 6.8. Sequence Mode with Adjust Feeding Enable Adjust Feeding in “AdFd” (3.1.8.3 in submenu “SEQU”). In Sequence Mode the Over / Under comparison is done when the Complete output is ON. Timer “CFT” re-opens SP3 for a certain time to adjust final weight. Timers: t1: Comparison Inhibited Time “CITI”...

  • Page 109: Auto Free Fall Compensation

    Manual Weighing Controller A 810 6.9. Auto Free Fall Compensation Auto Free Fall Compensation adjust the amount of feeded ingredient in “Sequence Mode” to automatically reduce weighing errors, reaching Final weight as close as possible. For that procedure AFFC-CN completed cycles are recorded differences (error) between actual weight and Final weight is calculated each time average the errors after AFFC-CN cycles this average is multiplied by CPS-CE for weighting...

  • Page 110: Appendix

    Manual Weighing Controller A 810 7. Appendix 7.1. ASCII-table Dez Hex Char Dez Hex Char Dez Hex Char 32 0x20 64 0x40 96 0x60 33 0x21 65 0x41 97 0x61 34 0x22 " 66 0x42 98 0x62 35 0x23 67 0x43 99 0x63 36 0x24 68 0x44...

  • Page 111: Survey Of Operating Functions

    Manual Weighing Controller A 810 7.2. Survey of Operating Functions The operating functions listed here can be called by certain keys (submenu “KF” at page 62) or key sequences provided that the respective settings have been made during Setup. To enter numerical code of a function call directly, please press ) and ) together.
  • Page 112 Manual Weighing Controller A 810 set to increased display resolution till acknowledgment set to increased display resolution for 5 sec display input voltage, mV/V display input voltage of calibrated zero, mV/V display input voltage of calibrated max, mV/V display input voltage of 1 e, µV/V display internal resolution between zero and max CALL EDUCED...
  • Page 113 “ ” EDIT FINAL OF CURRENT CODESET PUT CURRENT VALUE TO DIFFERNCE STATISTIC SHOW AVERAGE VALUE OF DIFFERNCE STATISTIC IN INCREASED ; A810 RESOLUTION CONTINUES WORKING IN BACKROUND SHOW UM OF IFFERENCES SHOW MAX OF IFFERENCES SHOW MIN OF IFFERENCES ;...

  • Page 114: Description Of States Of Error

    Manual Weighing Controller A 810 7.3. Description of States of Error When an error occurs, the terminal reads out an error message in place of weight. Apart from underload and underload, every error message has to be acknowledged by pressing key 'Set to zero'. Depending on the type of error, the terminal will either restart or continue its operation.
  • Page 115 Manual Weighing Controller A 810 Err 30 interface 0 (RS422/RS485) overflow distant station prohibits transmission or transmitter buffer defective terminal Err 31 interface 0 (RS422/RS485) overflow distant station transmits too many data, receiver buffer XON/XOFF protocol not operational Err 32 interface 0 (RS422/RS485) interruption interruption or short circuit of receiving line receiving line...
  • Page 116 Reduce vibration or set “STAN” 3.1.1.11 and “STAR” 3.1.1.12 at page 27 to higher values Err 196 no positive acknowledgement from no module integrated; reset A810 Profibus-module Err 197 no answer from Profibus-module no module integrated; reset A810...

Table of Contents
