CONTENTS Introduction Safety Precautions Technical Information Pre-Installation Instructions Electrical Installation Diagrams and Assembly drawings Operating Instructions Fault Finding Maintenance and Servicing 10 - Spare Parts List 11 - Test Certificate and Serial Number... -
Page 5: Introduction
IMAX spares whenever any part should be replaced, just to ensure and to prolong service life and performance. A spare parts list is attached to this manual. Always quote Product Serial Number in case there is a need to contact IMAX B.V. regarding the equipment. -
Page 6: Safety Precautions
SAFETY PRECAUTIONS To create a safe working environment and safety of the user, the instructions given hereunder must be strictly adhered to : ATTENTION : In order to prevent personal injury or damage to the searchlight, when unpacking or manoeuvring the unit into its final position, suitable lifting points must be used. Prevent rain, snow, condensation and water droplets from contacting the lamp as this may cause bulb failure and possible shattering. -
Page 7: Technical Information
TECHNICAL INFORMATION The searchlight IM490RC has the following features : All marine grade materials and fixings • Parabolic silvered glass mirror/reflector • Epoxy powder coatings • Pan movement 360 • Tilt movement +30 to –30 • Pan speed 12 /sec •... -
Page 8: Pre-Installation Instructions
PRE-INSTALLATION INSTRUCTIONS In case the equipment is to be stored for a relatively long period of time, care must be taken for a clean and dry environment. In case the unit has been in storage for several months it is advised to conduct a routine maintenance check before it is installed in its definite position. -
Page 9: Electrical Installation
– ELECTRICAL INSTALLATION The electrical installation of the equipment should be performed by competent personnel in accordance with current Electrical Installation Rules and Standards. It is essential that full operating voltage is applied to the lampholder in order to obtain maximum performance of the lightsource. -
Page 10: Diagrams And Assembly Drawings
DIAGRAMS and Assembly drawings Drawing number : IM08095 - Wiring diagram, single panel control IM08096 - Wiring diagram, single panel control + optional focus control IM08097 - Wiring diagram, multi panel control with Electronic Interlocking IM400-111 Outline Joystick Control Panel General outline IM490RC... -
Page 11: Operating Instructions
OPERATING INSTRUCTIONS The searchlight is designed for use outdoors. When in use never cover the searchlight or lay anything on it because this will create a serious possibility of fire or other hazard. The searchlight is electrical remote controlled by an 8-position joystick controlpanel. Two movements, e.g. -
Page 12: Fault Finding
FAULT FINDING Test 1. LAMP CIRCUIT. Check condition of the lamp and lampholder . Replace if worn out. If lamp is in good condition, check supply. Junction box terminals 1 + 6 must read 230V * Test 2 PAN and/or TILT CIRCUIT. If one or more functions fail : Open junction box at the back of the searchlight Check whether supply voltage and movement commands arrive on terminals :... - Page 13 MAINTENANCE To prolong the service life and to ensure the maximum performance of the searchlight, we recommend the following maintenance guidelines : Dirt on front glass and/or mirror reflector will result in a considerable loss of light. Before every voyage the equipment should be checked on these points as well as on good working of the lamp.
-
