- Page 1 3-Axis Gimbal for Mirrorless Camera GuiLin FeiYu Technology Incorporated Company User Manual V 1.0...
-
Page 2: Product Overview
1. Product Overview [1] Tilting axis [2] Rolling axis [3] Rolling lock screw [19] [4] Vertical arm [18] [5] Indicator [24] [6] Joystick [21] [7] Function button [8] Shutter button [22] [9] Panning lock screw [10] Panning axis [14] [11] Socket connector [15] [16] [17]... - Page 3 Basic accessories Thumb screw Camera support USB cable SONY shutter line Camera support Battery X2 Smart charger Quick plate Tripod (Type: 18650) frame screw frame (3.5 audio to multi) Advanced accessories Installation way （Double-hand foldable set） Single-armed installation α2000 Single Handle 1/4 screw Code shoe Dual Handheld...
-
Page 4: Installation
2. Installation Attention: Please complete the following instructions before power on the gimbal Insert the batteries Installation of the camera Prior to use, please be sure to fill the batteries. (1) Align the adjustment skateboard to the 1/4 screw Remove the handle, insert hole at the bottom of the camera and place to the 2 pcs 18650 batteries and appropriate position，then tighten the screw. - Page 5 （2） After installing the camera, press and hold the anti-column, place the quick plate which the camera is mounted on the clamping plate, and tighten the screws. Anti- column Thumb screw Balance Adjustment Turn on the gimbal after adjust the center of gravity balance of the three axis(see the section "7.Balance Adjustment"...
- Page 6 Power on：Long press the function button and release it until green light is on and hear the tone. Power off： Long press the function button and release it until red light changes from quick flashing to constant and hear the tone. The current mode of the gimbal can be identified by the indicator status.
- Page 7 Modes / Functions Working Modes Panning Mode (Default mode ) Tilting and rolling direction are fixed, and the camera lens moves according to the hand movement of the user. Panning and Tilting Mode The rolling direction is fixed, and the camera lens moves according to the hand movement of the user. Lock Mode The orientation of the camera is fixed.
- Page 8 Autorotation Mode 1.Quadruple tap on function button, gimbal will access the autorotation mode . 2. Set the gimbal start rotation position: Pull the tilting axis or panning axis to the start position by hand,click the function button to record. 3. Pull the gimbal (which can be rotated more than one turn) according to the rotation path you want to set, and then click the function button to record the end position again.The gimbal will go to the start position and start the automatic rotation.Gimbal autorotation function with micrrorless camera delay photography function can be used to achieve a very special mobile delay photography.
- Page 9 Manual Lock Manual lock ，pull to the specified angle to stay half a second can be lock the current angle.(The tilting axis and panning axis in the lock mode can be manual lock and the tilting axis can be manual lock in the panning mode.) Take the tilting axis as an example: Hold the camera and change its angle in Keep this position for half second, the...
- Page 10 Photograph The shutter button can take pictures via the shutter line. Click the shutter button to focus, click again within 3s to take pictures.If there is no operation within 3s, the focus state is cleared. Charging Indicator 状态指示灯 Charging indicator 状态指示灯...
- Page 11 GuiLin FeiYu Technology Incorporated Company *Please scan the two-dimensional code Google play via the browser. Connecting App Start the App on your smartphone,follow the instructions to connect the smartphone App with gimbal via bluetooth. A2000 A2000 × FY_A2000_XX Choose a gimbal FY_XXX_XX 360°...
-
Page 12: Gimbal Initialization
4. Gimbal initialization You can initialize your gimbal when: （1） when camera is not level （2） if not used for a long period of time （3） in case of extreme temperature variations Adjusting steps: The gimbal still placed on the desktop, the gimbal will automatically initialization when detects the static, the blue light cycle three flash, then the initialization end. - Page 13 5. Firmware Upgrade Option 1: Connect the gimbal with PC via micro USB cable, and then upgrade the firmware. Please visit the official website www.feiyu-tech.com to download the relevant software for upgrading, including USB driver,firmware upgrade software and product firmware, and install the relevant software, decompress the firmware files . Firmware upgrade according to the firmware upgrade instructions.
- Page 14 6. Parameters 219mm 176.5mm 376mm Titling Angle 360° Rolling Angle 360° Panning Angle 360° Tilting Increments 2°/s ~ 75°/s Panning Increments 3°/s ~ 150°/s Life Time 10 Hours (Center of gravity balance) Load weight 250g~2000g Sony NEX-5N/NEX-7 and other N-series, SONY A7RII / ILCE-7R / ILCE-5100, Panasonic LUMIX GH4, Adaption Canon 5D Mark III (with standard lens), and other cameras with similar dimensions with weight less 2000g （...
-
Page 15: Balance Adjustment
7. Balance Adjustment Balance adjustment of the tilting axis STEP 1 Adjust the center of gravity of the camera in two steps to the axis of rotation of the tilting axis. （1） Adjust the center of gravity position of the tilting axis up and down: let the camera lens vertical down, hand arm to maintain the level, as shown in figure ①, let go and observe the state of rotation. - Page 16 （2） Adjust the center of gravity position of the tilting axis forward and backward: let the camera lens horizontal forward, hand arm to maintain the level, as shown in figure ①,let go and observe the state of rotation. Loosen the screw on the bottom of the camera and adjust the balance by slide the adjustment skateboard to up and down at the bottom of the camera.(Refer to Figure ②...
- Page 17 Balance adjustment of the rolling axis STEP 2 When the balance adjustment of tilting axis and rolling axis is completed, the balance of the panning axis can be adjusted.Keep the gimbal socket connector with the horizontal ground,Hand-held panning axis as shown in figure ①,let the arm in the natural state, observe the camera tilt state.
- Page 18 Balance adjustment of the panning axis STEP 3 Best balance When the balance adjustment of tilting axis and rolling axis is completed, the balance of the panning axis can be adjusted. Keep the gimbal socket connector with the horizontal ground, Hand-held panning axis as shown in figure ①,et go and observe the state of rotation.
- Page 19 D I S C L A I M E R Prohibit any user for any illegal purpose. Users will be responsible for all behaviors of purchase and use products. The Company assumes no liability for any risks related to or resulting from the debug and use of this product (including the direct, indirect or third-party losses).
- Page 20 GuiLin FeiYu Technology Incorporated Company Due to software and hardware improvements, your actual product might differ from the descriptions and pictures in this user manual. You can get the latest user manual from the official website. For more information, please visit our official website...
