USER MANUAL

VS-R12 GPS Watch

Table of Contents

Need help?

Do you have a question about the VS-R12 and is the answer not in the manual?

Questions and answers

Summary of Contents for ViaSat VS-R12

Page 1 USER MANUAL VS-R12 GPS Watch...
Page 2: Table Of Contents
Contents Introduction .................................... 3 Appearance and interface ............................... 4 Appearance ..................................4 Interface ....................................5 How to use the watch ................................6 Install the APP and register user account ........................... 6 Set-up the watch ................................. 7 Using the APP ..................................7 Locating the watch ................................
Page 3: Introduction
Introduction GPS Phone Watch R12 is designed especially for children. It comes in two colors and it can be customized on request for specific order quantities. It is water resistant and used for real-time tracking, emergency alarm (SOS button), safe zone alarm, voice message, and two way voice communication.
Page 4: Appearance And Interface
Appearance and interface Appearance Fig 3. Appearance  ON/SOS key – multiple functions: ▪ Power on the watch, long press ▪ If shortly pressed return to the previous interface or hang up the call (while in call) ▪ Pressed for more than 3 seconds, it will trigger SOS alarm and call the emergency phone number set from mobile ...
Page 5: Interface
 “Wechat” key: ▪ Select the message receiver by shortly pressing it, you can choose to send voice message to all family members or all contacts. ▪ After selecting a contact, press the key and hold it to record your voice message, until you finish the message. After releasing, it will send out the voice message to mobile APP automatically.
Page 6: How To Use The Watch
How to use the watch Install the APP and register user account Please access to www.viasatsystems.ro to download the APP on your mobile or look for MyRope in App Store or Google Play. After the APP is installed on mobile phone, use your phone number or email address to register as new user of the APP.
Page 7: Set-Up The Watch
Set-up the watch Charge the watch to have enough battery for setting up Fig 8 Charging Please make sure the SIM phone number used in the watch is correct, otherwise, the watch cannot be located. The country code is not required when inserting the phone number in the APP. Insert the SIM card in the slot with chipset upwards as shown in aside figure, when the watch is powered off.
Page 8: Locating The Watch
Locating the watch After registering the watch, while powered on, take it in an open space that has direct sky visibility and keep it for about 2 minutes, after this the APP will receive and report correct GPS location. In the main screen of the app will appear the watch position: The watch will continuously upload the GPS location every minute while moving, and switch to battery saving mode when standing still.
Page 9: Send Voice Message Between App And Watch
Fig 10. Time period selection Fig 11. Tracking playback Send voice message between APP and watch Please click the “Wechat” icon available in the lower bar in APP main map screen and the interface will switch into conversation window. Click “Hold to talk” button and keep it pressed while speaking your message, release it after you finish the message.
Page 10: Voice Monitoring
Voice monitoring By clicking the “Guard” button from the lower bar of main screen, your mobile will call the watch in “silent mode” meaning the watch will not ring and will pick up the call automatically. When the connection is made, you can listen the voice around the watch silently.
Page 11: Message Center
Message center There are two types of notifications (messages): 1. Guard messages – it contains alerts like: Zone Exit, Zone Entering, Low battery and SOS activations Fig 14 Guard messages 2. System messages – contains notifications about who registered the watch on their mobiles Fig 15 System messages...
Page 12: Fence List
Fence list From the APP you can set maximum 10 safe zones for notifications. The safe zones are locations for which you like to know if the watch is leaving or entering. You can create a zone by clicking on the predefined types available in the APP already (School or Home) or by clicking from the blue bar above map.
Page 13: Family List
Family list From this section you can add/remove family list members. The APP user registered phone number is binding to the family contact list automatically. You can add maximum 15 more phone numbers to this list. To add a member click on from the blue bar.
Page 14 Mute By default, the watch will ring when receiving a call or voice message, the mute option can be used if you wish to deactivate the default setting. From this menu you can set periods when the watch needs to be on “mute”. You can set the start/end time of silent period and also the days when to repeat.
Page 15: To Be Considered
Feeback and contact If you need any other additional information please don’t hesitate to contact us Viasat Systems Str. Dr. Nicolae Turnescu Nr. 11 Sector 5, Bucuresti - Romania...
