Summary of Contents for Eminent AB7819
- Page 1 AB7819 4 x 1 HDMI switch with 3D and 4K support...
-
Page 2: Table Of Contents
ENGLISH AB7819 5 x 1 HDMI switch with 3D and 4K support Table of contents 1.0 Introduction ......................2 1.1 Packing contents ....................2 2.0 Panel description ....................3 3.0 Installation instructions ..................4 4.0 Remote Control instructions................... 5 5.0 Frequently Asked Questions and other related information ........5 6.0 Service and support .................... -
Page 3: Panel Description
ENGLISH 2.0 Panel description 1. HDMI input1 port 2. HDMI input ports 2/3/4/5 3. Power input 4. Indicator of power input 5. Input select button 6. IR receiver 7. Indicator of HDMI input 8. Indicator of HDMI output 9. HDMI output port... -
Page 4: Installation Instructions
ENGLISH 3.0 Installation instructions 1. Connect the HDMI input sources ( such as Media player, BD/DVD player etc.) to the five HDMI-in ports. 2. Connect the HDMI display device (such as HDTV) to the HDMI output port. 3. Insert the DC side of 5V power supply to the HDMI switch and connect the AC side of the power supply to the wall outlet. -
Page 5: Remote Control Instructions
The latest Frequently asked questions for your product can be found on the support page of your product. Eminent will update these pages frequently to assure you have the most recent information. Visit www.eminent-online.com for more information about your product. - Page 6 A power socket is needed which should be close and easy accessible from the device. Repairing of the device should be done by qualified Eminent staff. Never try to repair the device yourself. The warranty immediately voids when products have undergone self-repair and/or by misuse.
-
Page 7: Warranty Conditions
Eminent warranty. Products are not covered by the Eminent warranty when exposed to incorrect/improper use, external influences or when opening the service parts of the product by parties other than Eminent.
