Operating Instructions VEGAPULS 67 4 … 20 mA/HART - four-wire Document ID: 32939... -
Page 2: Table Of Contents
7.3 Parameter adjustment with AMS™ and PDM ..............46 Saving the parameter adjustment data ................47 8 Maintenance and fault rectification 8.1 Maintenance, cleaning ....................48 Rectify faults ........................48 Exchanging the electronics module ................49 Software update ......................50 VEGAPULS 67 • 4 … 20 mA/HART - four-wire... - Page 3 10.2 Dimensions ........................56 Safety instructions for Ex areas Take note of the Ex specific safety instructions for Ex applications. These instructions are attached as documents to each instrument with Ex approval and are part of the operating instructions manual. Editing status: 2015-06-26 VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
-
Page 4: About This Document
This arrow indicates a single action. Sequence of actions Numbers set in front indicate successive steps in a procedure. Battery disposal This symbol indicates special information about the disposal of bat- teries and accumulators. VEGAPULS 67 • 4 … 20 mA/HART - four-wire... -
Page 5: For Your Safety
During work on and with the device the required personal protective equipment must always be worn. Appropriate use VEGAPULS 67 is a sensor for continuous level measurement. You can find detailed information about the area of application in chapter "Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions. -
Page 6: Ce Conformity
• NE 53 – Compatibility of field devices and display/adjustment components For further information see www.namur.de. 2.8 FCC/IC conformity (only for USA/Canada) The VEGAPULS 67 may only be used in closed vessels made of metal, concrete, or fibre-reinforced plastic. Note about this manual: This operating instructions manual is intended for use in a number of different countries. The illustrations show some applications of VEGAPULS 67 in atmospherically open vessels. These applications are not in conformity with the FCC/IC approvals of the instrument. -
Page 7: Environmental Instructions
That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfill this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" VEGAPULS 67 • 4 … 20 mA/HART - four-wire... -
Page 8: Product Description
Housing with electronics • Housing cover, optionally available with display and adjustment module PLICSCOM The components are available in different versions. Fig. 1: VEGAPULS 67 - threaded version with encapsulated antenna system and Alu double chamber housing Housing cover with integrated PLICSCOM (optional) Housing with electronics 3 Process fitting with encapsulated antenna system Antenna cover VEGAPULS 67 •... -
Page 9: Principle Of Operation
3 Product description Fig. 2: VEGAPULS 67, threaded version with plastic horn antenna and Alu double chamber housing Housing cover with integrated PLICSCOM (optional) Housing with electronics 3 Process fitting with plastic horn antenna Type label The type label contains the most important data for identification and use of the instrument: • Instrument type •... -
Page 10: Packaging, Transport And Storage
• Avoiding mechanical shock and vibration • Storage and transport Storage and transport temperature see chapter "Supplement - temperature Technical data - Ambient conditions" • Relative humidity 20 … 85 % VEGAPULS 67 • 4 … 20 mA/HART - four-wire... -
Page 11: Accessories And Replacement Parts
The rinsing connection is used to blow compressed air into the antenna area of the radar sensor. This protects the surfaces of the antenna system against dust or condensation. You will find additional information in the supplementary instructions manual "Rinsing connection" (Document-ID 49552). VEGAPULS 67 • 4 … 20 mA/HART - four-wire... - Page 12 3 Product description Electronics module "VEGAPULS series 60" is a replacement part for Electronics module radar sensors of VEGAPULS series 60. A different version is available for each type of signal output. You can find further information in the operating instructions "Elec- tronics module VEGAPULS series 60" (Document-ID 30176). VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
-
Page 13: Mounting
Measuring range The reference plane for the measuring range of the sensors is the bearing surface on the side of the focussing lens. With the version with adapter flange, the reference plane is the lower side of the flange. VEGAPULS 67 • 4 … 20 mA/HART - four-wire... - Page 14 With radar sensors, the polarisa- tion can be used to considerably reduce the effect of false echoes by turning the instrument in the connection flange or mounting boss. The position of the polarisation plane is marked on the instrument. Fig. 5: Position of the polarisation plane of VEGAPULS 67 Marking bars VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
-
Page 15: Mounting Preparation
Single chamber housing – Angle of inclination 180°, infinitely variable – Angle of inclination in three steps 0°, 90° and 180° • Double chamber housing – Angle of inclination 90°, infinitely variable – Angle of inclination in two steps 0° and 90° VEGAPULS 67 • 4 … 20 mA/HART - four-wire... - Page 16 4 Mounting Fig. 7: Adjustment of the angle of inclination Fig. 8: Turning by fastening in the centre Collar or adapter flange The compression flange allows mounting on a flange DN 80/ANSI 3", the adapter flange on flanges DN 100/ANSI 4" and DN 150/ANSI 6" You can find drawings of these mounting options in chapter "Dimen- sions". VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
-
Page 17: Mounting Instructions
With the aluminium double chamber housing, retroactive mount- ing in this way is not possible - the mounting type must be specified with the order. Information: The mounting socket should be as short as possible and its end rounded. This reduces false echoes from the vessel mounting socket. VEGAPULS 67 • 4 … 20 mA/HART - four-wire... - Page 18 Tip: In new facilities it is useful to incline the vessel socket in the direction of the outlet. False reflections from the vessel wall are thus reduced and measurement all the way down to the bottom of the conical outlet is possible. VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 19 The optimum mounting position is on the outer wall of the silo with the sensor oriented towards the outlet in the silo center. Fig. 13: Installation and orientation in multiple chamber silos VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 20 Air rinsing Air rinsing is useful for avoiding buildup, particularly when there is strong condensation. Since VEGAPULS 67 has no direct rinsing air connection, a separate rinsing air connection must be provided in the mounting socket. By inclining this connection towards the top, a particularly effective cleaning of the antenna cover is achieved.
- Page 21 If the sensor is used on a movable boom, the max. measuring rate must be observed (see chapter "Technical data"). Fig. 17: Radar sensors on traverse crane VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
-
Page 22: Connecting To Power Supply
In Ex systems, the grounding is carried out according to the installa- tion regulations. With the Exd version, the minus side of the signal output is galvani- cally connected to ground via protective diodes. When connecting the instrument to a grounded PLC, equalising currents can flow in case VEGAPULS 67 • 4 … 20 mA/HART - four-wire... -
Page 23: Connection Procedure
11. Connect the lead cable for power supply in the same way accord- ing to the wiring plan, in addition connect the ground conductor to the inner ground terminal. 12. Screw the housing lid back on The electrical connection is finished. VEGAPULS 67 • 4 … 20 mA/HART - four-wire... -
Page 24: Wiring Plan, Double Chamber Housing
Fig. 19: Double chamber housing Housing cover, connection compartment Blind plug or plug M12 x 1 for VEGADIS 61 (optional) Housing cover, electronics compartment Filter element for air pressure compensation Cable gland VEGAPULS 67 • 4 … 20 mA/HART - four-wire... - Page 25 Ground terminal for connection of the ground conductor and screen Spring-loaded terminals for voltage supply Information: Keep in mind that the display and adjustment module must only be used in the electronics compartment. VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
-
Page 26: Switch-On Phase
Fig. 22: Wiring plan, double chamber housing Voltage supply Signal output Switch-on phase Switch-on phase After connecting VEGAPULS 67 to power supply or after a voltage recurrence, the instrument carries out a self-check for approx. 30 seconds: • Internal check of the electronics •... -
Page 27: Set Up With The Display And Adjustment Module Plicscom
4. Screw housing lid with inspection window tightly back on Disassembly is carried out in reverse order. The display and adjustment module is powered by the sensor, an ad- ditional connection is not necessary. VEGAPULS 67 • 4 … 20 mA/HART - four-wire... -
Page 28: Adjustment System
Adjustment system Fig. 24: Display and adjustment elements LC display Indication of the menu item number Adjustment keys • [OK] key: Key functions VEGAPULS 67 • 4 … 20 mA/HART - four-wire... -
Page 29: Setup Steps
The radar sensor measures the distance from the sensor to the Parameterization example product surface. For indication of the real level, an allocation of the measured distance to the percentage height must be carried out. VEGAPULS 67 • 4 … 20 mA/HART - four-wire... - Page 30 [OK]. Now the menu item "Min. adjustment" is displayed. Min. adjustment 0.00 % 5.000 m(d) 4.000 m(d) 3. Prepare the % value for editing with [OK] and set the cursor to the requested position with [->]. Set the requested percentage value VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 31 To adapt the sensor to these measuring conditions, this menu item offers different options depending on whether liquid or solid is selected. With "Solid" these are "Silo" or "Bunker", with "Liq- uid", "Storage tank", "Stilling tube", "Open vessel" or "Stirred vessel". VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 32 Enter the requested parameters via the appropriate keys, save your settings and jump to the next menu item with the [->] key. Caution: Note the following if the VEGAPULS 67 with corresponding approval is used as part of an overfill protection system according to WHG (Water Resources Act): If a linearisation curve is selected, the measuring signal is no longer necessarily linear to the filling height. This must be considered by the...
- Page 33 Indication value "Distance": Presentation of the measured value in the selected adjustment unit, e.g. m(d). Displayed value ▼ Scaled Display unit ▼ Volume ▼ Scaling 0 % = 0.0 l 100 % = 100.0 l VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 34 "Start trend curve". Diagnosis - Curve pres- A comparison of the echo curve and the false echo curve allows a entation more detailled evaluation of measurement reliability. The selected VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 35 3. Confirm "False signal suppression - Change now" with [OK] and select in the below menu "Create new". Enter the actual distance from the sensor to the product surface. All false signals in this area are detected by the sensor and saved after confirming with [OK]. VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 36 Service - Extended set- The menu item "Extended setting" offers the possibility to optimise ting VEGAPULS 67 for applications in which the level changes very quickly. To do this, select the function "Quick level change > 1 m/min.". Extended setting quick level change > 1 m/min.
- Page 37 Menu item Reset value Max. adjustment 0 m(d) Min. adjustment Meas. range end in m(d) Medium Liquid Vessel form not known Damping Linearization Linear Sensor-TAG Sensor Displayed value Distance Sensor-specific basic adjustment. Depending on the sensor type, see chapter "Technical data". VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 38 3.50: • Deutsch • English • Français • Espanõl • Pycckuu • Italiano • Netherlands • Japanese • Chinese Language German Special parameters are parameters which are set customer-specifically on the service level with the adjustment software PACTware. VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 39 Displayed value • Display unit • Scaling • Current output • Unit of measurement The 4 … 20 mA signal of the HART sensor is switched off. The sensor consumes a constant current of 4 mA. The measuring signal is transmitted exclusively as digital HART signal. VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 40 Software version: Edition of the sensor software, e.g. 3.80 Date of manufacture 24. March 2015 Software version 3.80 • Date of last change using PC: Date of the last change of sensor parameters via PC, e.g. 24. March 2015 Last change using PC 24. March 2015 VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
-
Page 41: Menu Schematic
Sensor Display Basic adjustment ▶ Display Diagnostics Service Info Displayed value Display unit Scaling Backlight ▼ ▼ Scaled 0 % = 0.0 l Volume Switched off ▼ 100 % = 100.0 l VEGAPULS 67 • 4 … 20 mA/HART - four-wire... - Page 42 Basic adjustment Display Diagnostics Service ▶ Info Instrument type Date of manufacture Last change using PC Sensor characteristics 22. November 2010 Software version Display now? Serial number 3.80 22. November 2010 12345678 VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
-
Page 43: Saving The Parameter Adjustment Data
They are thus available for multiple use or service purposes. If VEGAPULS 67 is equipped with a display and adjustment module, the most important data can be read out of the sensor into the display and adjustment module. -
Page 44: Set Up With Pactware And Other Adjustment Programs
Fig. 27: Connection via VEGACONNECT externally I²C bus (com.) interface on the sensor I²C connection cable of VEGACONNECT VEGACONNECT USB cable to the PC Necessary components: • VEGAPULS 67 • PC with PACTware and suitable VEGA DTM VEGAPULS 67 • 4 … 20 mA/HART - four-wire... -
Page 45: Parameter Adjustment With Pactware
To ensure that all instrument functions are supported, you should always use the latest DTM Collection. Furthermore, not all described functions are included in older firmware versions. You can download the latest instrument software from our homepage. A description of the update procedure is also available in the Internet. VEGAPULS 67 • 4 … 20 mA/HART - four-wire... -
Page 46: Parameter Adjustment With Ams™ And Pdm
Parameter adjustment with AMS™ and PDM For VEGA sensors, instrument descriptions for the adjustment programs AMS™ and PDM are available as DD or EDD. The instru- ment descriptions are already implemented in the current versions of AMS™ and PDM. For older versions of AMS™ and PDM, a free-of-charge download is available via Internet. Move via www.vega.com and "Downloads" to "Software". VEGAPULS 67 • 4 … 20 mA/HART - four-wire... -
Page 47: Saving The Parameter Adjustment Data
It is recommended to document or save the parameter adjustment data. That way they are available for multiple use or service purposes. The VEGA DTM Collection and PACTware in the licensed, profession- al version provide suitable tools for systematic project documentation and storage. VEGAPULS 67 • 4 … 20 mA/HART - four-wire... -
Page 48: Maintenance And Fault Rectification
The following table describes possible errors in the current signal and helps to eliminate them: Error Cause Rectification 4 … 20 mA signal Level fluctuations Set damping via the display and ad- not stable justment module VEGAPULS 67 • 4 … 20 mA/HART - four-wire... -
Page 49: Exchanging The Electronics Module
Or on site by the user In both cases, the sensor serial number is necessary. The serial num- bers are stated on the type label of the instrument, inside the housing or on the delivery note. VEGAPULS 67 • 4 … 20 mA/HART - four-wire... -
Page 50: Software Update
Attach the completed form and, if need be, also a safety data sheet outside on the packaging • Please contact the agency serving you to get the address for the return shipment. You can find the agency on our home page www.vega.com. VEGAPULS 67 • 4 … 20 mA/HART - four-wire... -
Page 51: Dismount
WEEE directive. Correct disposal avoids negative effects on humans and the environ- ment and ensures recycling of useful raw materials. Materials: see chapter "Technical data" If you have no way to dispose of the old instrument properly, please contact us concerning return and disposal. VEGAPULS 67 • 4 … 20 mA/HART - four-wire... -
Page 52: Supplement
Distance to the level - scaled (for example hl, %) Resolution, digital > 1 mm (0.039 in) Input variable Measured variable distance between process fitting and product surface Min. distance from antenna end 50 mm (1.969 in) Measuring range up to 15 m (49.21 ft) With inductive load ohmic share min. 25 Ω/mH. For products with a low dielectric figure up to 50 cm (19.69 in). VEGAPULS 67 • 4 … 20 mA/HART - four-wire... - Page 53 Time to output the correct level (with max. 10 % deviation) after a sudden level change. Incl. non-linearity, hysteresis and non-repeatability. Relating to the nominal measuring range, in the temperature range -40 … +80 °C . VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 54 Ʋ unassembled IP 20 Ʋ mounted into the sensor without cover IP 40 Material Ʋ Housing Ʋ Inspection window Polyester foil Tested according to the guidelines of German Lloyd, GL directive 2. VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 55 For that reason the associated approval documents of these instruments have to be carefully noted. They are part of the delivery or can be downloaded under www.vega.com via "VEGA Tools" and "Instrument search" as well as via "Downloads" and "Approvals". VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
-
Page 56: Dimensions
~ 87mm (3 ") ø 84mm ") M12x1 M20x1,5/ ½ NPT Fig. 31: Double chamber housing of Aluminium (with integrated display and adjustment module the housing is 9 mm/0.35 in higher) VEGAPULS 67 • 4 … 20 mA/HART - four-wire... - Page 57 125 mm (4.92") 2,5 mm (0.10") 1.4301 PBT-GF30 75 mm (2.95") 9 mm 107 mm (0.35") (4.21") 115 mm (4.53") 12 mm (0.47") Fig. 32: VEGAPULS 67, version with mounting strap VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 58 10 Supplement VEGAPULS 67, version with compression flange ø 107 mm ø 21 mm (4.21") (0.83") ø 75 mm (2.95") ø 115 mm (4.53") ø 156 mm (6.14") ø 200 mm (7.87") Fig. 33: VEGAPULS 67, compression flange DN 80/3"/JIS80 VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 59 10 Supplement VEGAPULS 67, version with adapter flange ø 75 mm (2.95") ø 98 mm (3.86") Fig. 34: VEGAPULS 67, adapter flange DN 100/DN 150 Adapter flange Seal VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 60 Линии продукции фирмы ВЕГА защищаются по всему миру правами на интеллектуальную собственность. Дальнейшую информацию смотрите на сайте www.vega.com. VEGA系列产品在全球享有知识产权保护。 进一步信息请参见网站<www.vega.com。 10.4 Trademark All the brands as well as trade and company names used are property of their lawful proprietor/ originator. VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 61 Notes VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 62 Notes VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 63 Notes VEGAPULS 67 • 4 … 20 mA/HART - four-wire...
- Page 64 Printing date: All statements concerning scope of delivery, application, practical use and operat- ing conditions of the sensors and processing systems correspond to the information available at the time of printing. Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2015...
