- Page 1 INSTRUCTIONS FOR VERSONEL CARBON INFRARED HEATER Model No. VSLWMH200 VSLWMH200 Model Voltage(V) Wattage(W) 1500 Amps(A) 12.5 Btu(HR) 5115 34.6 x 7.7 x 3.3 Dimensions W×H×D(in) Weight(LB) Versonel | New Holland, PA www.versonel.com...
-
Page 2: Important Safety Instructions
Warning THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE! We cannot be liable for any damages caused by failure to observe these instructions. IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY-The infrared heater is designed for safe operation; however installation, maintenance and operation of the heater can be dangerous. -
Page 3: Installation
Please contact your local municipality for the nearest collection point. Introduction The VERSONEL Carbon Infrared Heater with Remote produce instant and comfortable heat like the sun. These robust and weatherproof heaters are designed for domestic and commercial heating applications within indoor and outdoor areas. - Page 4 4. For both wall and ceiling mounting, the lowest part of the heater must be located at or above a minimum height of 6FT from ground level, so that the heater cannot be touched when in operation. 5. For wall mounting, there must be a 6FT distance from your appliance to the ground. For ceiling mounting, there must be a 9FT distance from your appliance to the ground.
- Page 5 23. GROUNDING INSTRUCTION - This heater is for use on 120 volts. The cord has a plug as shown at A in below Figure. An adapter as shown at C is available for connecting three-blade grounding-type plugs to two-slot receptacles. The green grounding lug extending from the adapter must be connected to a permanent ground such as a properly grounded outlet box.
- Page 6 Wall/Ceiling Installation Wall mounted 1. Make holes on wall where heater is to be mounted with a pencil. Use a level to make sure heater will be mounted straight. 2. Drill holes with a smaller diameter drill bit than the plastic anchor. 3.
- Page 7 Correct and incorrect installation way...
- Page 8 (2 and 3). Noted: All VSLWMH200 heaters and their remote controls have the same frequency, so it is possible to control several heaters with just one remote.
-
Page 9: Maintenance
Replacing the battery 1. Press the battery compartment release button and then slide out the battery tray. 2. Remove the old battery and put the new AAA battery in. 3. Slide the battery tray back into the remote control until is clicks. Noted: Do not allow water or liquid to get into the remote control. - Page 10 CLEANING Regular and careful cleaning helps your infrared heater operate efficiently for many trouble free years. To clean your heater follow steps below: 1. Unplug the power cord for your safety before cleaning your appliance. 2. Make sure the heater is cool before continuing. 3.
