- Page 1 Microscopes Operation Manual 1200MM Series Covering Models: 1241MM & 1242MM Printed in the USA No. VGMNL071708-1200MM...
- Page 2 (unseen) The eyepieces and objectives on VanGuard Microscopes are coated. They should never be wiped while dry as any dirt or dust will scratch the coating. The surfaces should either be blown off with an air canister, or blown and cleaned with an air-bulb and camel-hair brush. It is recommended to then use a lens cleaner. Apply with Upper Illuminator a cotton swab for a minimum of wetting, then wipe the surface clean with a quality lens tissue.
- Page 3 General Operation General Operation Thank you for purchasing a VanGuard Microscope. With the user in mind, VanGuard Microscopes are built from modern Lamp Replacement (Lower Illuminator) [MODEL 1242MM ONLY] designs and should provide a lifetime of reliable performance. We recommend you read this entire manual carefully before beginning to use the instrument.
- Page 4 General Operation General Operation Focusing and Mechanical Stage Mechanisms Focus the image by turning the coarse/fine focus control knobs. The large knob is used for coarse adjustment, while the smaller knob is used for fine adjustment. The coaxial arrangement allows for easy, precise adjustment without stage drift. Turning the coarse/fine focus control will raise and lower the stage vertically.
