- Page 1 CK622500TX-Espresso Finish CK612500TX-Black Finish For assistance with assembly contact: Southern Enterprises Inc. Nailhead End Table Trunk Customer Service 1-800-633-5096 service@seidal.com Assembly Instructions www.seidal.com PO#12972 Max Top Load 40 lbs. Max Load Inside the Trunk 60 lbs.
- Page 2 CK622500TX-Espresso Finish/CK612500TX-Black Finish Nailhead End Table Trunk Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 8 PCS 8 PCS 1 PC Cam Bolt Cam Lock ϕ6.8 x 36mm ϕ15 x 12mm Wrench 8 PCS 8 PCS 35 PCS ϕ8 x 30mm ϕ ¼” x 2 ¾” ϕ 3.5 x 16mm Dowel Bolt Screw 1 PC 1 PC 1 PC Left-Support...
- Page 4 CK622500TX-Espresso Finish/CK612500TX-Black Finish Nailhead End Table Trunk Assembly Instructions Attach handle-A (O) to the top (A) by using screw (M). Use Phillips screwdriver to tighten it as shown. Attach handle-B (P) to front panel (B) by using screws (M). Use Phillips screwdriver to tighten as shown.
- Page 5 Attach handle (Q) to side panel (D) using screws (M). Use Phillips screwdriver to tighten it as shown. Screw cam bolts (H) into back panel (C) as shown. Insert dowels (J) into to left side panel (D) and right side panel (G) as shown. Then combine left side panel (D), right side panel (G), front panel (B), back panel (C), and bottom panel (E)
- Page 6 Turn the trunk base up side down and attach legs (F)to the bottom of trunk by using screws (L) as shown. Attach hinge (T) to back panel (C) and top panel (A) by using screws (M) as shown and then tighten all screws using Phillips screwdriver.
- Page 7 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
