Every encoder group of signals can operate on a separate power supply SY057 reduces the noise in the output signal due to the absence of long cable runs. Plug in Screw terminal wiring ...
Page 3
The following figure shows a block diagram explaining the principle of operation and the potential conditions between the circuits SY057 Block Diagram...
Page 4
Location of Frequency divider & Input configuration switches Encoder output connectors...
Page 5
Divider’s Switch Settings The Divider functionality is available on channels 3 and 4. The following diagrams show how to set the divider’s functionality switches. Divider = 4 Divider = 1 Divider = 2 Divider = 8 Divider = 16 Divider = 32 Divider = 64 Divider = 128 Division...
Page 6
Input Configuration switches The following diagrams show how to set the input signal’s type. Single ended pulse input with SY057 5V encoder excitation. Differential input with external 5 – 30V encoder excitation. RS485/RS422 input with external 5 – 30V encoder excitation.
Page 7
Technical Specifications Feature Specification Power Supply 9 – 30 Vdc Number of Impulse Inputs 1 in for each 4 out OR 1 in for multiples of 4 out Galvanic Isolation Input types Differential Max frequency; TTL, HTL 500 KHz Input type single ended signals with TTL levels Divide feature On Channels 3 and 4;...
Page 8
Cascading several units The number of outputs from the SY057 can be increased in blocks of 4, up to 32, by adding 4 channel expansion modules to the master unit. The expansion modules can be identified as having no power in or input encoder connections.
