MMC-1105 Quick Guide

MMC-1105 is a micro digital wireless camera, which is digital totally from lens to RF output

circuit. For real time wireless monitor use, its resolution can be HDTV 1280×1024; its

definition is 3-10 times as the equipments of former microwaves(CCD wireless camera,

the theoretic resolution is 720*576 or 760*480) and COFDM. If use it for low altitude

aerial photography, you can see clearly the brand name of the cigarette box on the ground

don't need change the lens focus. . For book photographing or evidence taking, at one

time it can photograph clearly all the words on 2-3 A4-sized papers. The above-mentioned

performance of MMC-1105 is beyond the normal PAL/NTSC videography equipment can

do, including some of the equipments for broadcast use.

Taking advantage of the most update 2.4GHz BroadWide

RF blind-area compensable

technology, the advanced technology MM-1105 takes has very good performance in

signal transmission. It can attain very long transmission distance with very small

transmission power. Take basic specification of MMC-1105 as an example, the

transmission power of it is only 50mW, but its reference transmission distance can be

more than 5KM and MMC-1105S is 15KM. Comparably, to meet the above mentioned

long transmission distance 15KM, the standard 8M-bandwidth CODFM or microwave

equipments must need very high transmission power of above 1000mW.

Additionally, MM-1105 has interfaces of voice input and output, data link and it is built in a

16G memory cell (optional). If necessary, you can use it for communication, transmit data

with speed of <9600bit or record video of an extra 3 hours or so.

http://www.edimaeg.com/ http://www.pagerchina.com/

+86 771 3161151

Table of Contents

Need help?

Do you have a question about the MMC-1105 and is the answer not in the manual?

Questions and answers

Summary of Contents for MMC MMC-1105

Page 1 MMC-1105 Quick Guide MMC-1105 is a micro digital wireless camera, which is digital totally from lens to RF output circuit. For real time wireless monitor use, its resolution can be HDTV 1280×1024; its definition is 3-10 times as the equipments of former microwaves(CCD wireless camera, the theoretic resolution is 720*576 or 760*480) and COFDM.
Page 2 MMC-1105-Center, and then wirelessly transmit to the laptop. From the above, we can see the three parts can be separated in different places. And the user doesn’t need to stay with MMC-1105-Center; it can be independently put in high place.
Page 3 After enter exact account and passwords, we will see the monitor video and operation administration page of MMC-1105. NOTE: If it is the first time for the computer to connect with MMC-1105, some operating system maybe need to install ActiveX control, otherwise the user will only see the toolbar, and cannot see the pictures.
Page 4 Buttons for bi-directional voice communication and data link application Warning For Information Safety & Conflicts Between Equipments 1. If you don’t want anyone can visit your MMC-1105 and its accessories, please set passwords for your admin account. 2. If you want your MMC-1105-Center to be visited and used by authorized persons, please set passwords for your MMC-1105-Center.
Page 5 For personal use, limited by the condition and environment, it is very difficult or cost too much for a person to get the best position to place MMC-1105 center. But to get better result, the user still needs to find a better position to install MMC-1105 center (mainly for its antenna).
