Gas Countertop Griddle
This manual contains important information regarding
your purchased equipment. Please read the manual thoroughly
prior to equipment set-up, operation and maintenance.
Failure to comply with regular maintenance guidelines
outlined in this manual may void the warranty. Please keep it for future
reference after installation and do not throw it away!
This is a universal installation and operation instruction book which
SABA
3390 Enterprise Ave., Hayward, CA 94545
Toll Free: +1 (844) 422-8900 Telephone: +1 (510) 293-0189 Fax: +1 (510) 293-0199
would apply to different models.
PLEASE READ!!!
Advertisement
Table of Contents
Summary of Contents for Saba MG-16
- Page 1 This is a universal installation and operation instruction book which would apply to different models. PLEASE READ!!! SABA 3390 Enterprise Ave., Hayward, CA 94545 Toll Free: +1 (844) 422-8900 Telephone: +1 (510) 293-0189 Fax: +1 (510) 293-0199...
-
Page 2: Installation
WARNINGS • Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other equipment. • Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. • Read the installation and maintenance instructions thoroughly before installing or servicing this equipment. -
Page 3: Propane Gas Conversion
• The area in front and around the equipment must be kept clear to avoid any obstruction of the flow of combustion and ventilation air. • Adequate clearance must be maintained at all times in front of and at the sides of the equipment for servicing and proper ventilation. -
Page 4: Lighting The Pilot
LIGHTING THE PILOT: The manifold units are equipped with standing pilots and each should be lit immediately after the gas is supplied to the equipment. 1. Before attempting to light the pilots, turn off the main gas valve to the equipment and wait 5 minutes to clear the gas. -
Page 5: Operation
OPERATION: Before initial use, turn the gas control knob to the maximum setting and allow the equipment to burn-in for 20 minutes. Seeing smoke coming from the cooking surface is normal during burn-in. After 20 minutes of burn-in, equipment is ready for use. 1. -
Page 6: Using The Griddle
griddle to a low temperature (300-350°F) and apply a small amount of cooking oil – about one ounce per square foot of surface. Use a soft lint-free cloth to spread the oil over the entire griddle surface to create a thin film. Wipe off any excess oil with a cloth. Repeat the procedure until the griddle has a slick, mirror -like finish. - Page 7 PROBLEM POSSIBLE CAUSES 1. Problem with gas valve. (Call for service) 2. Burner does not come on when the Pilot burner not lit. (Call for service) 3. Low gas control knob is turned on pressure. (Call for service) 1. Manual gas valve not turned on. 2. Obstructed pilot orifice.
- Page 8 Product Specification Sheet MANIFOLD Total B.T.U. MODEL STYLE(Manual) GAS TYPE PRESSURE per Hour Single Burner MG-16 Natural Gas 4.0" W.C. 30,000 2 Burners w/ MG-24 Natural Gas 4.0" W.C. 60,000 individual control 3 Burners w/ MG-36 Natural Gas 4.0" W.C.
- Page 9 Code Description MG-16 MG-24 MG-36 MG-48 MG-60 Griddle 20129087001 20129088001 20129089001 20129090001 20129091001 plate knob 301110274 301110274 301110274 301110274 301110274 oil pan 20129087008 20129087008 20129087008 20129087008 20129087008 pilot 302130019 302130019 302130019 302130019 302130019 gas valve 302220059 302220059 302220059 302220059 302220059...
- Page 10 oil pan 20129087008 20129087008 20129087008 20129087008 20129087008 pilot 302130019 302130019 302130019 302130019 302130019 gas valve 302220045 302220045 302220045 302220045 302220045 foot 302090047 302090047 302090047 302090047 302090047 burner assy 302130363 302130363 302130363 302130363 302130363 inlet gas 302201568 302201569 302201570 302201571 302201572 pipe 9 Pilot gas pipe...
