Summary of Contents for high pointe M-ID185
- Page 1 User Manual Of Induction Cooktop Model: M-ID185 Thank you for purchasing HIGH POINTE' s induction cooker. Please thoroughly read through this instruction manual before use and store it carefully for future use.
-
Page 2: Table Of Contents
CONTENTS IMPORTANT SAFEGUARDS........2-3 SAFETY INSTRUCTIONS........4-7 PRODUCT INTRODUCTION........8-9 OPERATION INSTRUCTIONS......10-11 INSTALLATION REQUIREMENTS......12 COMPATIBLE COOKWARE........13 CLEANING AND MAINTENANCE ......13 TROUBLE SHOOTING..........14 WARRANTY............15 DISCLAIMER............15... -
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS Do not touch hot sur faces. To protect against electrical shock do not immerse cord/plugs in water or other liquid. Close supervision is necessary when any appliance is used by or near children. Do not operate any appliance with a damaged cord or plug , after the appliance malfunctions or has been damaged in any manner. -
Page 4: Important Safeguards
IMPORTANT SAFEGUARDS Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the product. -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS 1. For safety reasons and to avoid damage to the appliance or injuries to people, please abide by all the safety instructions below. 2. Ignoring safety warnings may result in injuries. 3. This appliance does not take into consideration the following situations: —... - Page 6 SAFETY INSTRUCTIONS To avoid danger, do not insert any foreign People with heart pacemake rs s hould object, such as iron wire, nor block the air consult a doctor. Only use the appliance ventilation opening or air entry port. after confirming that it does not affect the pacemaker.
- Page 7 SAFETY INSTRUCTIONS Pleas e use a dedicated and high quality The cooker cannot be overloaded. power outlet, with high power rating, equal Overloading the plate may damage th e to or above 15A. plastic cover and c ooker plate. Please keep the Induction Cooker clean. When operati ng the appliance or after Protect the induction cooker from bugs, moving the pot, the cooking area will remain...
-
Page 8: Safety Instructions
SAFETY INSTRUCTIONS Never operate the induction cooker Keep electrical appliance out of to cook wi th an empty pot, reach from children. otherw ise its operational Do not let them use the appliances performance may be affected and without supervision. danger may happen. -
Page 9: Product Introduction
Weight Dimension Model Rated power ( kg ) voltage/frequency Rated power Rated power " M-ID185 120Vac,60Hz 1500W 1500W 1800W 24.4"x15"x2.6" Product Sketch Map Po w er c o r d A i r v en t Cer am i c p l at e... -
Page 10: Product Introduction
PRODUCT INTRODUCTION Control Panel 1. ON/OFF 2. Power regulating / Childproof Lock 3. Timer 4. Heating 5. Temperature Before using New Induction cooker Read this guide, and take special note of the “Safety Warnings” section. Remove any protective film that may still be on your ceramic plate. Using the Touch Controls The controls respond to touch, so you don't need to apply any pressure. -
Page 11: Operation Instructions
OPERATION INSTRUCTIONS Plug in After the power supply is connected, a beep will sound. The LED indicator flash 1 second. Turn on After pressing the " ON/ OFF" button, the buzzer will ring once. The induction cooker is ready for heating. After pressing the "... -
Page 12: Operation Instructions
OPERATION INSTRUCTIONS Heating The default timer of each level are as follow: Level Default t ime Childproof Lock Press the " " and " " button at the same time to start childproof lock function, the " Lock" indicator lights up. Then only the " ON/ OFF" button can be used to switch off the induction cooker, all the other operations are forbidden. -
Page 13: Installation Requirements
INSTALLATION REQUIREMENTS ① Minimum distance from cook- top any object above must be at least 18" ② Minimum distance from cook- top to any surface below must be at least 3.25 " ③ Cut- out width:14.3" ④ Cut- out length:23.8" ⑤... -
Page 14: Compatible Cookware
COMPATIBLE COOKWARE Stainless steel Iron pan Iron kettle Enamel stainless Enamel cooking Iron plate steel kettle utensil Induction-compatible cookware contains ferromagnetic materials. In other words, it contains iron, or has a layer with magnetic properties. Cookware must have a flat smooth bottom with the diamete more than 5"... -
Page 15: Trouble Shooting
TROUBLE SHOOTING Key checking points and trouble shooting Abnormalities * Is the power plug properly connected? Plug the power cord and press the “ON/OFF” key, * Is the switch, power outlet, fuse or power cord but the indicator and display do not light up. damaged? * Is the cookware compatible. -
Page 16: Warranty
DISCLAIMER Inform ation in this Use r's Manua l is subject to change without notice.H igh P ointe assume s no responsibil ity for any inaccuracies that may be contained in this Use r's Manual. If you find inform ation in this manual that is incorrect, misleading,or incompl ete, we woul d appreci ate your comments and suggestions...
