Summary of Contents for Billabong GBBPIC
- Page 1 Cover Billabong Picnic Portable Charcoal Barbeque. Product code: GBBPIC...
- Page 2 • Do not add instant light charcoal briquettes or firelighters to an existing fire. A flash fire may result in bodily injury or property damage USAGE AND OPERATION • The Billabong barbeque gets VERY hot when in use – do not touch hot surfaces. Always wear insulated mitts when the unit is hot. • Do not wear loose clothing when using this unit.
- Page 3 Page 2 Billabong Picnic Portable Charcoal Barbeque. Product code: GBBPIC Parts List Exploded View GBBPICLH Lid Handle 55-08-219 Lid Air Vent GBBPICLAV 55-08-222 GBBPICLID 55-22-301 Warming Rack GBBPICWR 55-08-231 Cooking Grid 55-08-215 GBBPICGRILL Firebox 55-11-067 GBBPICFB Charcoal Grid GBBPICGRATE 55-08-042...
- Page 4 Page 3 Assembly Instructions For Easiest Assembly: Attach Air Vent and Lid Handle to the Lid • To avoid losing any small components or hardware, assemble your product on a level surface that does not have cracks or openings. • Clear an area large enough to lay out all components and hardware.
- Page 5 Page 4 Assembly Instructions Assemble Legs Attach Firebox and Grill Slide to legs Secondly Firstly Thirdly Short Long Firstly Secondly Thirdly Attach Lid to Firebox Insert Warming Rack...
- Page 6 Page 5 Assembly Instructions Insert Charcoal Grid and Cooking Grid Lock Lid Note: Lid must be locked before folding transporting. Secondly First Unlock Lid Note: Always unlock and open lid before lighting. Fold Grill Note: Lid must be locked before folding grill. Unfold Grill Note: Lid must be locked before unfolding grill.
- Page 7 LIGHTING A FIRE Open the hood of your Billabong barbeque, as well as all of the vents. Remove the cooking grate. Add charcoal. Do not put more than 2 kilogrammes of charcoal briquettes or 1 kilogramme of lump charcoal onto the charcoal grill. Do not let burning charcoal or wood come in contact with the walls of the grill (keep fuel approximately 50 mm away from the ash pan edge).
- Page 8 Back WARRANTY AND CONSUMER GUARANTEE The BBQ’s Galore Warranty and consumer guarantees set out in this document override all other warranties on this product. Barbeques Galore Warranty is provided in addition to other rights and remedies as set out below under ‘Consumer Guarantees’. Warranty Term Subject to the conditions set out below, this product is warranted to the purchaser to be free from defects in workmanship and materials from the date of purchase for the terms specified below.
