Summary of Contents for CHINA AIR TOOL XAGD1022J
- Page 1 USERS MANUAL 20GA. 7/8" UPHOLSTERY STAPLER MODEL: XAGD1022J WARNING Failure to follow warning could result in DEATH OR SERIOUS INJURY. M0727 02/12 V2...
-
Page 2: Table Of Contents
CONTENTS: IMPORTANT INFORMATION EXPLANATION OF THE NAILING ACTION GENERAL SAFETY RULES WORK AREA PERSONAL SAFETY TOOL USE AND CARE SERVICE AIR SOURCE DESCRIPTION AND SPECIFICATION SPECIFICATION FEATURES ASSEMBLY/INSTALLATION OPERATION LUBRICATION ADJUSTING AIR PRESSURE CONNECTING AIR SUPPLY TOOL TESTING NAIL LOADING METHODS OF OPERATION COLD WEATHER OPERATION ADJUSTING THE EXHAUST... -
Page 3: Important Information P1
IMPORTANT INFORMATION and make sure others in work area wear safety glasses. Safety glasses must conform to the requirements of American National Standards Institute, ANSI Z87.1 and WARNING provide protection against flying particles both from the TO AVOID SERIOUS PERSONAL INJURY, ALL USERS AND front and side. -
Page 4: Tool Service
TOOL SERVICE potential hazards related to this tool. USE ONLY FASTENERS THAT ARE RECOMMENDED FOR USE ONLY ACCESSORIES THAT ARE IDENTIFIED BY THE YOUR MODELS. Do not use the wrong fasteners or load MANUFACTURER FOR THE SPECIFIC TOOL MODEL. the fasteners incorrectly. USE OF UNAUTHORIZED PARTS OR FAILURE TO FOLLOW CHECK FOR MISALIGNMENT OR BINDING OF MOVING MAINTENANCE INSTRUCTIONS MAY CREATE A RISK OF... -
Page 5: Specification P3
FUNCTIONAL DESCRIPTION AND SPECIFICATIONS WARNING Disconnect the tool from the air source before making any adjustments, changing accessories o storing the tool. Such precautionary safety measures reduce the risk of unintentional tool operation. FIG. 1 Air Cap Trigger Hand Grip Air Plug Magazine Latch... -
Page 6: Features P4
FEATURES If the tool is not used with an in-line lubrication system on 360 adjustable exhaust ° the air supply it is necessary to periodically lubricate the Allows user to direct air away from debris. tool with air tool lubrication. Comfort-grip handle. -
Page 7: Tool Testing
against the wood. WARNING THE TOOL MUST NOT OPERATE. Do not exceed maximum recommended air pressure Separate the safety from the wood. Next, point the tool marked on the tool. Verify prior to using the tool that the air downward, pull the trigger and then wait in that position source has been adjusted within the rated air-pressure for 5 seconds or longer. -
Page 8: Methods Of Operation
After nailing: FIG. 6 1).Disconnect air hose from the tool. 2).Remove all nails from the tool. 3).Supply 5-10 drops of pneumatic tool lubricant into the air plug on the tool. 4).Open the petcock on the air compressor tank to drain any moisture. -
Page 9: Cleaning P7
CLEANING With ON/OFF switch in OFF position, plug compressor into electrical outlet. WARNING Close pressure regulator by turning all the way to the When cleaning a tool be careful not to disassemble any left. Turn compressor ON and let it pump all the way up portion of the tool since internal components may be to automatic shut-off pressure. -
Page 10: Trouble Solving P8
TROUBLE SOLVING PROBLEMS POSSIBLE CAUSES SUGGESTED SOLUTIONS Air leaking near the top of 1. Loose screws. 1. Tighten screws. the tool or in the trigger 2. Worn or damaged O-rings or seals. 2. Install overhaul kit. area. Air leaking near the bottom 1.
