Total Control Products RCKP214 Installaton Manual

Power rack and pinion late 1967-69 mustang, big block
Hide thumbs

Advertisement

Quick Links

Download this manual
READ ALL INSTRUCTIONS COMPLETELY AND THOROUGHLY UNDERSTAND THEM BEFORE DOING ANYTHING.
CALL TOTAL CONTROL PRODUCTS TECH SUPPORT (916) 388-0288 IF YOU NEED ASSISTANCE.
Part Number
TCP EE-02
Instructions included for components listed in chart.
INSTALLATION GUIDE
TCP RCKP214
Power Rack and Pinion
Late 1967-69 Mustang, Big Block
Left Hand Drive (USA)
Power Rack and Pinion
Eccentric Eliminators
Tie-Rod Adapters
Steering Column Shaft
Column Floor Mount
Description
1
PDF Page
2
18
20
22
30
38

Advertisement

loading
Need help?

Need help?

Do you have a question about the RCKP214 and is the answer not in the manual?

Questions and answers

Summary of Contents for Total Control Products RCKP214

  • Page 1: Table Of Contents

    READ ALL INSTRUCTIONS COMPLETELY AND THOROUGHLY UNDERSTAND THEM BEFORE DOING ANYTHING. CALL TOTAL CONTROL PRODUCTS TECH SUPPORT (916) 388-0288 IF YOU NEED ASSISTANCE. INSTALLATION GUIDE TCP RCKP214 Power Rack and Pinion Late 1967-69 Mustang, Big Block Left Hand Drive (USA)

  • Page 2: Tcp Rckp-01

    READ ALL INSTRUCTIONS COMPLETELY AND THOROUGHLY UNDERSTAND THEM BEFORE DOING ANYTHING. CALL TOTAL CONTROL PRODUCTS TECH SUPPORT (916) 388-0288 IF YOU NEED ASSISTANCE. INSTALLATION GUIDE TCP RCKP-01 Power Rack & Pinion, Left-Hand Drive 1967-1970 Mustang/Cougar FE or Big-Block Engines Description: Power TCP Rack & Pinion with mounting brackets and hardware ONLY Applications: Fits ‘67-70 Mustang/Cougar with FE or big-block V8 engines...

  • Page 3: Tcp

    1967-70 Mustang Manual Rack assembly is shown in diagram. Included in TCP EE-02 Optional use...

  • Page 4: Tcp Tier-02

    PARTS LIST RCKP-01 - Power Rack and Pinion, BB Mustang Left Hand Drive Part Number Description TCP RCKP-01 Power rack and pinion, left-hand drive, big-block Mustang/Cougar 7900-184 Big-block mounting bracket set 7900-184 - Mounting Bracket Set, Big Block Part Number Description 7900-100 Clamp collar drilled half...
  • Page 5 1. Remove the battery cable from the negative side of the battery. 2. Raise the vehicle using a two-post lift or jack and secure with jack stands so that the suspension hangs freely and the vehicle is safe to work underneath. 3.
  • Page 6 16. Unbolt the lower control arms from the frame mounts. OEM eccentric adjustment hardware will be replaced with hardware supplied with the rack and pinion. 17. With the suspension at full extension, the lower control arms can be safely unbolted. Use caution as the arm may shift once the bolt is removed.
  • Page 7 20. Bolt the lower rack brackets to the lower control arm mounts using the orientation and hardware shown on page two. The bracket’s bend will face inward or outward depending upon the year of the vehicle. 21. Refer to installation guide (7903-EE-02), packaged with eccentric eliminator plates (TCP EE-02), for specifi...
  • Page 8 25. On the passenger-side frame rail, loosely bolt the frame bracket to the OEM-crossmember mounting point using the 1/2-13 x 1-1/2” bolt, fl at washer, and lockwasher. 26. Raise the rack-and-pinion assembly into position along the loosely installed brackets. 27. On driver-side frame rail, loosely bolt the rack and pinion’s attached frame bracket to the OEM-crossmember mounting point, using the same hardware as the...
  • Page 9 28. Loosely install each of the clamp collars (Item 2) onto their respective brackets so that the clamps seat against the rack tube to prevent rocking, but still allow rotation and sliding movement. A light lubricant can be used to more easily permit sliding of the brackets.
  • Page 10 34. Verify that each of the three clamps are just tight enough to correctly align the bracket with the rack tube before lightly tightening the outer-bracket bolts into the frame rails. 35. The rack and pinion is now accurately positioned. Install Intermediate Shaft 36.
  • Page 11 42. Begin by snugging up each bolt to remove any free play. 43. Verify that each bracket will seat squarely against its mounting surface without drawing the rack tube. 44. Make two to three passes through the tightening order to bring each bolt to its specifi ed torque value. Inner brackets –...
  • Page 12 • The clamp is not square to the bracket-side clamp. Check by measuring the gap at the opposite ends of the clamp. • There is debris, a burr, or other imperfection on the clamp or rack tube that must be removed. •...
  • Page 13 Fill the System with Fluid 54. Fill the reservoir using only petroleum based power steering fl uid. FLUID REQUIREMENT: The only medium recommended for use in our rack-and-pinion system is petroleum (OIL). DO NOT USE SILICONE SYNTHETIC FLUID, any automatic transmission fl uid, or any fl...
  • Page 14 • ENGINE MUST BE OFF PRIOR TO ADJUSTING. • (Perspective as viewed from underneath the rack and facing the front of the vehicle. The steering shaft must be rotated to position the set screws toward the bottom half of the shaft, closest to your vantage point.) 63.
  • Page 15 NOTES:...
  • Page 17 HIGHWAY. The products offered for sale are true race-car components and, in all cases, require some fabrication skill. NO PRODUCT OR SERVICE IS DESIGNED OR INTENDED TO PREVENT INJURY OR DEATH. Total Control Products A Chris Alston’s Chassisworks, Inc. Brand...
