- Page 1 Installation manual Résidencia 2 1/ Presentation of the central Unit 2/ Presentation of radio components 3/ Recommendations 4/ Installation and commissioning procedure 5/ Programming in the factory Issue 3 - December 2003...
-
Page 2: Table Of Contents
Table of Contents 1. Presentation of Alarm Unit Equipment Wireless Components Programming on the Installer overlay Event Log Remote Viewing Technical Data 2. Presentation of Wireless Components p 10 3. Recommendations 3.1 Recommendations before Starting Installation 3.2 Recommendations Relative to Alarm Unit and Wireless Component Installation 3.3 Safety Recommendations p 14... -
Page 3: Presentation Of Alarm Unit
1/ Presentation of Alarm Unit The unit combines the functions of an Alarm Unit and Telephone Modem. Equipment Battery level: Each detector monitors its built- in battery and informs the alarm unit if the The alarm unit is equipped with: battery is low. -
Page 4: Event Log
Programming from a PC Using Technical Data the Configurator The alarm unit performs a self-test when controlling and transmitting a line power failure Programming from a laptop requires the use of and return, the battery level and by cyclically the configuration pack. sending status messages (cycle in hours or This pack includes a special connecting cable days). - Page 5 1/ Infrared movement detectors Series 1: A/ Standard infrared 10D9310 B/ Animal infrared 10D9320: The "Animal" detector is used for the surveillance of premises whilst ignoring an animal of less than 18 Kg and less than 50 cm. Operating temperature:-10° C to 50° C. Weight: 120 g;...
- Page 6 Recommendations concerning the installation of "animal" detectors We advise you to set the jumper of the pulse counter to position 5, which corresponds to a maximum protection against unwanted trips. According to place and installation conditions, the jumper can be set to position 3 (good immunity) or to position 1 (instantaneous detection).
- Page 7 2/ Opening detectors or technical transmitters A/ Series 1: 10D9330 Operating temperature: 0° C to 50° C. Weight: 50 g with battery - Magnet: 15 g; Colour: white. Power supply by Lithium 3 V – CR123A battery; life: 50 transmissions per day = 3 years; transmission of low battery signal.
- Page 8 3/ Remote controls, call SOS and Rounds A/ Series 1 2 On/Off keys: 10D9230 4 On/Partial On/Off/ SOS keys: 10D9250 1 SOS key: 10D9220 1 Round key: 10D9210 Operating temperature: 0° C to 50° C. Weight: 50g, Colour: dark grey. Dimensions: 60h X 40L X 11P mm.
- Page 9 4/ Smoke Detector 10D9350 Wireless smoke detector P/N 10D9350 is designed to be installed inside the protected premises. It must be installed on the ceiling in the center of the room. When smoke is detected, the system generates a series of three audio signals and triggers a radio transmission to the alarm unit.
-
Page 10: Recommendations
Recommendations You are about to install and put into service an alarm unit. We suggest you comply with the following recommendations: 1. Read this manual carefully and, in particular, the chapter concerning the installation recommendations. 2. Follow the instructions set out in the installation procedure to the letter. - Page 11 Environment and location of the unit The unit is a wireless alarm system which communicates with its peripherals using radio transmissions. The propagation of radio frequencies differs depending on the place of installation, location and height of components, and on the construction materials found. The position of the unit on the site to be protected is therefore strategic.
- Page 12 The installation, upkeep and maintenance of this equipment may only be carried out qualified, authorised personnel. Installation conditions, environment ▲ Wherever possible, the unit and keypads should not be installed in a room with a static floor covering (carpet, etc.), close to high power distribution cubicles, switches generating high over voltages and in the immediate vicinity of a source of heat (radiator, electric convector heater, etc.).
- Page 13 Connection of the 230 Volt electrical network ▲ The equipment is designed to operate at a single phase voltage of 230 volts, 50 Hz. Before making the electrical connection, check that the parameters of the electrical network (voltage, power, frequency, etc.) correspond to the operating parameters shown on product rating plate and in the manual.
-
Page 14: Installation And Commissioning Procedure
Installation and commissioning procedure To ensure that installation is carried out under optimal conditions, it is necessary to perform the steps below in the order given. With the alarm unit user 1/ Establish an installation plan based on the default factory programming. This plan is used to determine: The approximate locations of the detectors. -
Page 15: Connecting The Telephone Line
Inlet for 230 VAC connection 230 VAC line power terminals Inlet for the telephone line Terminals for analog fixed telephone Hasardous line and system telephone sets voltage The ribbon cable interconnecting the front panel card and main card is installed in the unit supplied. - Page 16 2/ ISDN system with one or more telephone sets and an Internet link L1/L2 P1/P2 ℡ ℡ ℡ ISDN Telephone coupler line unit feeder ISDN Interface 3/ System with one or more telephone sets and an Internet link by ADSL L1/L2 P1/P2 ℡...
-
Page 17: Installer Code
The alarm unit does not boot unless 230 VAC line power is connected and present. The 3 LEDs on the front panel come on if the battery is connected but line power is absent. ● Disconnect the 230 VAC via the isolating switch and make sure the green LED flashes, confirming absence of 230 VAC. - Page 18 1. Accessing Installer Setup Mode from Off Mode Entry in setup mode is protected by an access code. Follow the procedure below to access setup mode: administrator code installer code (factory-set administrator code: 1111; factory-set installer code: 2222). If the codes entered are correct, the alarm unit goes into Installer Setup mode. The Mode LED flashes twice per second.
- Page 19 The alarm unit acknowledges data entry by generating an acceptance signal if accepted or a refusal signal if the number or the sequence is entered incorrectly. The alarm unit returns to Installer setup mode. When programming the telephone number, you can press to return to the start of Installer setup mode.
- Page 20 The factory parameter settings can be changed to customize the system. The new settings can be made from a PC equipped with the Configurator software and connected to the alarm unit via the special adapter cable or by download. Rules to be followed: The detectors and other devices must be set on a desktop near the alarm unit for storage before they are installed.
- Page 21 Memorisation procedures A/ "Infrared" detectors Series 1: standard infrared 10D9310 and Animal infrared 10D9320 Open the detector and set the jumper 1 to the "RST" position, Select a channel from 01 to 22, Press key )): The Mode LED flashes Insert the batteries in their housing respecting their polarities, Wait for the stabilisation time (15 seconds to 2 minutes).
- Page 22 C/ SOS transmitters Series 1: SOS transmitter 10D9220 Select a channel from 28 to 32. Press key )): The Mode LED flashes Press the button for at least 10 seconds: the indicator lamp comes on once after 2 seconds then comes back on 10 seconds. Check that the alarm unit broadcasts the acceptance audio signal Confirm the recording using the OK key.
- Page 23 Series 3: 2 On/Off/SOS keys: 10D3005 The remote control should be memorised on 2 channels: the "remote control" channel for placing under and off surveillance and the "SOS"' channel for duress calls. Memorisation of the remote control: Select a channel from 23 to 27. Press key )): The Mode LED flashes Press one of the remote control keys: the indicator lamp comes on during transmission,...
-
Page 24: Deleting A Detector
F/ Wireless Keypad ▲ Select a channel between 23 and 27 ▲ Press key )): The Mode LED flashes ▲ Insert the battery in its housing being careful not to reverse the poles or remove the insulating tape battery ▲ When the battery is installed, the two LEDs come on and the keypad generates two beeps for one second... -
Page 25: Installation Test
Caution: After a complete power failure (line power + battery), the time must be reset to synchronize the cyclic test. Proceed as follows to set the time: Press key : The Mode LED flashes Enter the date on 2 digits and press to confirm Enter the month on 2 digits and press to confirm... - Page 26 Tamper switch activated: The keypad generates three beeps, the green LED flashes three times and the alarm unit must generate a siren echo. Tamper switch deactivated: The keypad generates one beep, the green LED flashes twice and the alarm unit must generate a siren echo. Note: Wait five seconds before each activation and deactivation of the tamper switch.
-
Page 27: Servicing
During the 15-minute timeout, the installer can adjust the intercom volume by means of the SOS and Fire keys. . This adjustment must be made with the loudspeaker on. Testing the Range of Stored or Unstored Detectors This test is operational on all the detectors recognized by the alarm unit, even those which have not been stored. -
Page 28: Factory Settings
Appendix: Factory Notes Settings Channel 1 (130) Chime + time delay Channel 2 (130) Conditioned (1) Channel 3 (130) Conditioned (1) Channel 4 (130) Conditioned (1) Channel 5 (130) Conditioned (1) Channel 6 (130) Channel 7 (130) Channel 8 (130) Channel 9 (130) Channel 10...
