Summary of Contents for Quattro H2O-3
- Page 1 WATER-PROOF SCALE User’s Manual quattro Version 1.0...
-
Page 2: Table Of Contents
CONTENTS PRECAUTIONS ………………..……………… 3 INTRODUCTION ………………………………. 4 FEATURES …………………………………….. 4 TECHNICAL SPECIFICATION ………………. 5 FRONT PANEL ………………………………… 6 DISPLAY LAMPS ……………………………… 6 BUTTON KEYS ………………………………… 7 BACK PANEL ………………………………….. 7 SET MODE …………………………………….. 8 TROUBLESHOOTING …………….………….. 9... -
Page 3: Precautions
PRECAUTIONS Place the scale on a flat and stable surface. Do not use inflammable materials in cleaning. Do not severely press because light pressing of keys can incite the operation. Keep the scale away from strong EMI noises may cause incorrect weight readings. -
Page 4: Introduction
INTRODUCTION We greatly appreciate your purchase of the QUATTRO water-proof portable scale. These products have hold excellent performance and splendid properties through strike tests as well as devoting ourselves under severe quality management. H2O is shaped firmly and delicately designed a coincide with the special requirements of several industrial fields and include many functions. -
Page 5: Technical Specification
TECHNICAL SPECIFICATION MODEL H2O-3 H2O-6 H2O-15 H2O-30 Capacity/division 3kg/0.5g 6kg/1g 15kg/2g 30kg/5g Internal Resolution 1/30,000 External Resolution 1/6,000 1/6,000 1/7,500 1/6,000 Response Time 3 seconds Max Tare 100% of FS Zero Range 4% of FS Measurement Type Loadcell Display Weight... -
Page 6: Front Panel
FRONT PANEL 1. Display Lamps HOLD: ON when the current weigh is stable. >T: ON when the tare weight is stored. >0<: ON when the current weight is 0 kg. Lb: ON when current unit weight is lb. ... -
Page 7: Button Keys
2. Button Keys Turn On/Off the indicator. If use container in weighing, current weight is memorized as tare weight. The button functions as ZERO button (return the display to center zero) automatically if the weight on display is too small. BACK PANEL... -
Page 8: Set Mode
SET MODE 1. How to Enter Press and hold TARE key until SET menu appears. 2. Available Keys Move to next menu. This button is hidden (located above TARE/ZERO button). Change set value. Save set value and turn off the scale. 3. -
Page 9: Troubleshooting
TROUBLESHOOTING When the weight on platter is 9 divisions over the capacity, the scale displays EEEEE. Please remove excessive weight on platter. If display shows Lo , meaning the battery power is low. Please recharge or replace the battery. ... - Page 10 quattro...
