- Page 1 SE-5-EP/SE-8-EP 5 Port & 8 Port PoE Powered Gigabit Ethernet Switch User Manual – Version 1.0...
- Page 2 CE Mark Warning This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022 class A for ITE, the essential protection requirement of Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. FCC Certifications This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 3 AV cabinet where only one CAT5e cable is located. The SE-5-EP / SE-8-EP has the option to be powered by a traditional a/c adapter or by a PoE Ethernet Cable. Use of a PoE Ethernet cable gives the user the opportunity to install the switch in remote places where power outlets are inaccessible.
- Page 4 DEFINITION AND GUIDE: LED definitions: Status Operation Power Steady Blue Power is on Power is off Link/ACT Steady Blue Port connected Blinking Blue The port is transmitting/receiving data Cable selection guide: Network Speed Cable Type Max. Length 328 feet (100 10Mbps Cat.
- Page 5 Buffer Memory 832K bits Jumbo Frame 9K bytes Mechanical SE-5-EP Dimensions- 149 x 84 x 26mm(w/o (L x W x H mm) bracket), 156 x 31 x 87 (w/bracket) Weight- 10.5 oz. SE-8-EP Dimensions- 193 x 84 x 26mm (w/o bracket) 210 x 31 x 87mm (w/bracket) Weight- 12.5 oz.
- Page 6 TECHNICAL SUPPORT: Please visit our website for up-to-date support information: Website: www.pakedge.com Email: support@pakedge.com CONTACT INFORMATION: 3847 Breakwater Avenue Hayward, CA 94545-3606 U.S.A © Pakedge Device & Software Inc. 2015 – All Rights Reserved...
