Summary of Contents for Commell CMB-B72
- Page 1 CMB-B72 Barebone system Intel High Performance Platform Installation Guide Edition 1.01 2017/01/20...
- Page 2 CMB-B72 User’s Manual Copyright Copyright 2016, all rights reserved. This document is copyrighted and all rights are reserved. The information in this document is subject to change without prior notice to make improvements to the products. This document contains proprietary information and protected by copyright. No part of this document may be reproduced, copied, or translated in any form or any means without prior written permission of the manufacturer.
- Page 3 CMB-B72 User’s Manual Packing List: Desk/Wall mount x 1 (pair) CMB-B72 Chassis x 1 (Including Motherboard and Backplane) 1 x PS/2 Keyboard & Mouse Cable CD Driver x 1 (OALPS2/MKN)/ (1040551) Optional: 1 x Onboard DVI-D cable (For Secondary DVI) (BADPDVI_A &...
-
Page 4: Table Of Contents
CMB-B72 User’s Manual Index Chapter 1 <Introduction>..............4 1.1 <Product Overview> ............4 1.2 <Product Specification> ............5 Chapter 2 <Product Specification> ........... 6 2.1 <Motherboard Placement> ..........6 2.1.1 <Internal connectors list> .......... 7 2.1.2 <External connectors list> ......... 7 2.2 <Jumper Location and Reference>... -
Page 5: Chapter 1
CMB-B72 User’s Manual Chapter 1 <Introduction> 1.1 <Product Overview> CMB-B72 PICMG 1.3 half-size series fanless barebone system based on Intel® 6th generation "Skylake-H" Core™ i7/i5/i3 processor with three expansion slots, is designed to meet the expansion capability(provides three expansion slots with two different combinations of PCI and PCIe slots: a. -
Page 6: Product Specification
CMB-B72 User’s Manual 1.2 <Product Specification> System Intel® Skylake Core™ i7/ i5/ i3 H-series Processor FCBGA1440 Processor package Chipset Intel® QM170 2 x DDR4 SO-DIMM 2133 MHz up to 32GB, Memory Support Non-ECC, unbuffered memory only Watchdog Timer Generates a system reset with internal timer for... -
Page 7: Chapter 2
CMB-B72 User’s Manual Chapter 2 <Product Specification> 2.1 <Motherboard Placement> DDR4_B SATA3-3 SATA3-1 JFRNT CN_USB2-2 CN_USB2-1 CN_CRT MINICARD2 CN_DVI1 CN_DVI2 DDR4_A MINICARD1 PS/2 I219-LM I210-AT Display Port (RJ45-1) (RJ45-2) -
Page 8: Internal Connectors List
CMB-B72 User’s Manual 2.1.1 <Internal connectors list> Connector Function DDR4_A/B 260-pin DDR4 SO-DIMM slot SATA3-1/3 7-pin Serial ATA3 connector CN_USB 2-1 / 2-2 5 x 2-pin USB2.0 pin header CN_CRT 16-pin VGA connector CN_DVI1/2 10 x 2-pin DVI connector JFRNT... -
Page 9: Jumper Location And Reference
CMB-B72 User’s Manual 2.2 <Jumper Location and Reference> JCSEL1 JCSEL2 JP1 JP2 JVUSB JMSATA JRTC 2.2.1 <Jumper list> Jumper Function Power mode select JRTC CMOS Normal/Clear Setting JMSATA MiniCard 2 mSATA Setting COM1 Voltage Setting (For Pin 9) COM2 Voltage Setting (For Pin 9) -
Page 10: Clear Cmos And Power On Type Selection
CMB-B72 User’s Manual 2.2.2 <Clear CMOS and Power on type selection> The board’s data of CMOS can be setting in BIOS. If the board refuses to boot due to inappropriate CMOS settings, here is how to process to clear (reset) the CMOS to its default values. -
Page 11: Ethernet Interface
CMB-B72 User’s Manual 2.3.2 <Ethernet interface> The board provides I219-LM PHY Gigabit Ethernet and I210-AT Gigabit Ethernet on rear I/O. Intel I219-LM and I210 supports operation at 10/100/1000 Mb/s data rates, with IEEE802.3 compliance and Wake-On-LAN supported. I219-LM I210-AT 2.3.3 <Display interface>... - Page 12 CMB-B72 User’s Manual CN_CRT: VGA 16-pin connector (Pitch 2.00 mm) Signal Signal IOGND1 IOGND1 IOGND1 IOGND1 IOGND1 5VCDA 5HSYNC 5VSYNC 5VCLK CN_DVI: DVIonboard 20-pin connector Signal Signal Ground TMDSTX0N TMDSTX0P Ground TMDSTX1N TMDSTX1P Ground TMDSTX2N TMDSTX2P Ground Ground TMDSTXCP Ground...
-
Page 13: Serial Port Interface
CMB-B72 User’s Manual 2.3.4 <Serial Port interface> JCSEL1 JCSEL2 Use JCSEL1 and JCSEL2 to select communication mode JCSEL1, JCSEL2: For configure COM2 communication mode Function JCSEL1 JCSEL2 RS232 (Default) RS485 RS422 -12-... - Page 14 CMB-B72 User’s Manual JP1, JP2: COM1, COM2 pin-9 setting Jumper settings Function RI (Default) Effective patterns of connection: 1-2 / 3-4 / 5-6 Other may cause damage Please inform us above jumper mode before order if necessary to change. 1 2 3 4 5...
-
Page 15: Usb Interface
CMB-B72 User’s Manual 2.3.5 <USB interface> JVUSB CN_USB2-1 CN_USB2-2 CN_USB3-1 CN_USB3-2 CN_USB 2-1/2-2: USB2.0 10-pin header (Pitch 2.54 mm) Signal 5VSB 5VSB Front USB2.0 DATA0- DATA1- DATA0+ DATA1+ CN_USB2-2 CN_USB2-1 for optional cable -14-... - Page 16 CMB-B72 User’s Manual JVUSB: 6-pin Power select jumper (for setting USB3.0 VCC) Description 1-3 & 2-4 5V_SB 3-5 & 4-6 Default: 1-3 & 2-4 Effective patterns of connection: 1-3 & 2-4 or 3-5 & 4-6 CN_USB3-1/3-2: USB3.0 20-pin header (Pitch 2.00 mm)
-
Page 17: Expansion Slot
CMB-B72 User’s Manual 2.3.7 <Expansion slot> MINI_CARD2 MINI_CARD1 JMSATA MINI_CARD2 support mSATA by JMSATA JMSATA: Setting MINI_CARD2 to support PCIe/mSATA Jumper settings Function Support mSATA Normal operation (Default) Please inform us the MINI_CARD2 jumper mode before order if necessary. -16-... -
Page 18: Front Panel Switch And Indicator
CMB-B72 User’s Manual 2.3.8 <Front panel switch and indicator> JFRNT JFRNT: Front panel switch and indicator 14-pin header (Pitch 2.54mm) Signal Signal HDD_LED+ Power_LED+ HDD_LED- Power_LED- Power_ON+ Power_ON- Power LED HDD LED -17-... -
Page 19: Power Supply
CMB-B72 User’s Manual 2.4 <Power supply> 2.4.1<DC-DC4 Power Convert Module> Power input support 9~30V(120W) wide voltage input. DC_2H2: Terminal Block 2-pin power connector Signal Signal Power in 1. Power output CN_12V -18-... - Page 20 CMB-B72 User’s Manual CN_12V: 4-pin 12V connector Signal Signal ATX: main power 24-pin connector Signal Signal 3.3V 3.3V 3.3V -12V -PSON Power_OK 5VSB 3.3V User’s manual For more information refer to the -19-...
-
Page 21: Expansion Slot
CMB-B72 User’s Manual 2.5 <Expansion slot> 2.5.1<PCIMG1.3 Half-size Backplane> 1. Specification General Specification Form Factor PICMG1.3 Half size Backplane 1 x PCIe x16 slot,1 x PCIe x1 slot,1 x PCI slot(CBPE-2x1P) Extended Interface 1 x PCIe x16 slot,,2 x PCI slot(CBPE-1x2P) - Page 22 CMB-B72 User’s Manual 2. Power input CN_12V Connector: ATX Connector Type: Main power 24-pin connector Signal Signal 3.3V 3.3V 3.3V -12V -PSON Power_OK 5VSB 3.3V -21-...
- Page 23 CMB-B72 User’s Manual Connector: CN_12V Connector Type: 12V 4-pin connector Signal Signal “CN_12V” for increase the input current. For more information refer to the CBPE-1x2P CBPE-2x1P User’s manual -22-...
-
Page 24: I/O Panel
CMB-B72 User’s Manual 2.6 <I/O Panel> 2.6.1 <Front> Power LED HDD LED -23-... -
Page 25: Rear
CMB-B72 User’s Manual 2.6.2 <Rear> PS/2 I219-LM I210-AT DisplayPort DC_IN COM1 COM2 COM3 COM4 USB3.0 Expansion slots DVI-D For optional cable -24-... -
Page 26: Chapter 3< Hardware Installation
CMB-B72 User’s Manual Chapter 3< Hardware Installation> 3.1<Chassis Setup Procedure> 3.1.1<Memory Setup> (Two DDR4 SO-DIMM slot up to 32GB) (a.) Screw off the chassis by the indication as the picture below. -25-... - Page 27 CMB-B72 User’s Manual (b.) Take off the left side cover and find the DDR4_A/B location. DDR4_B DDR4_A (c.) Insert the DDR4 SO-DIMM module into the socket at 45 degree. -26-...
-
Page 28: 2
CMB-B72 User’s Manual (d.) Press down the module with a click sound. (e.) Put the cover back and screw on the chassis. 3.1.2<HDD Setup> (a.) Screw off the right side cover. -27-... - Page 29 CMB-B72 User’s Manual (b.) Put on the HDD into HDD holder then turn the HDD screws to tighten. 2.5" HDD -28-...
-
Page 30: 2
CMB-B72 User’s Manual (c.) Plug SATA & SATA power cable into HDD. (d.) Put the cover back and screw on the chassis. 3.1.2<Expansion Slot Setup> (a.) Screw off the left side cover. (b.) Align the keyway of the card with the slot key, and then install the card securely in the slot. - Page 31 CMB-B72 User’s Manual (c.) Lock the bracket. (d.) Put the cover back and screw on the chassis. -30-...
-
Page 32: Appendix A
CMB-B72 User’s Manual Appendix A <Install Desk/Wall mount> (a.) Screw on the rack mount as the picture below. -31-... - Page 33 Taiwan Commate computer Inc. 19F., NO.94, Sec. 1, Xintai 5 Rd., Xizhi Dist., New Taipei Address City 22102, Taiwan. +886-2-26963909 +886-2-26963911 Website www.commell.com.tw info@commell.com.tw (General information) E-mail tech@commell.com.tw (Technical Support) Commell is a brand name of Taiwan Commate computer Inc. -32-...
