Intended Use The USB 2.0 fax modem is designed to connect a computer to the Internet via a stan- dard telephone connection and enable the transmission and receipt of fax messages. It also supports telephone answering machine functions (TAM) and other telephone services.
Connecting the Fax Modem 1. Plug the USB connector on the fax modem in a free USB port on the computer. 2. Connect the fax modem to a telephone connection socket using the telephone cable supplied. The telephone cable is equipped with an RJ11 connector for connection to the telephone connection socket.
Page 4
After the driver has been installed for the fax modem, Completing the ..Wizard" ap- pears. 5. Click on the [Finish] button to finalise the installation. Installing the Fax Software in Windows XP Windows XP is provided with a fax software which can be used to transmit and re- ceive fax messages.
Technical Data S 2 LEDs: Ready / Data transmission S Connections: USB 2.0, RJ−11 S Power supply: Via USB, < 50 mA in operation, < 0.5 mA in standby S Data transmission rate: Download up to 56 kbit/s, Upload up to 48 kbit/s S Plug−&−play compatible S Dimensions and weight: 77 x 21 x 21 mm, 35 g S Supports operating systems: Linux, Windows 98SE / ME / 2K / XP / XP−64 / Vista /...
Page 6
CE Mark This device fulfils the requirements of all the applicable EU directives. Compliance with the relevant EU directives is confirmed by the CE mark applied to the device. The full Declaration of Conformity can be viewed at the following web site: CM3−Computer oHG Schinderstr.
