Page 1 TH-42LRU70 TH-42LRU7 TH-50LRU70 Installer’s Manual Hospitality LCD HDTV Thank you for purchasing this Panasonic product. English Please read these instructions before operating your set and retain them for future reference. The images shown in this manual are for illustrative purposes only.
Page 2 This product incorporates the following software: (1) the software developed independently by or for Panasonic Corporation, (2) the software owned by third party and licensed to Panasonic Corporation, (3) open sourced software The software categorized as (3) are distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY, without even...
Page 3: Table Of Contents
HDMI, the HDMI Logo, and High- Contents Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. Energy Star is a joint program of the US Environmental Protection Agency and the U.S. Department of Energy.
Page 4: Safety Precautions
Safety Precautions The lightning flash with arrowhead CAUTION within a triangle is intended to tell the user that parts inside the product are a risk of electric shock to persons. RISK OF ELECTRIC SHOCK The exclamation point within a DO NOT OPEN triangle is intended to tell the user that important operating and WARNING: To reduce the risk of electric shock, do not remove cover or back.
Page 5 19) An outside antenna system should not be located in the vicinity of overhead power lines, other electric light, power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
Page 6 The Consumer Electronics Association (CEA), of which Panasonic is a member, is committed to making home entertainment enjoyable and safe. To prevent personal injury or death, be sure to follow these following safety guidelines: THE CONSUMER ELECTRONICS INDUSTRY CARES •...
Page 7: Accessories/Optional Accessory
Incorrect wall-hanging bracket or incorrect fitting may cause equipment to fall, resulting in injury and product damage. Panasonic disclaims liability for any damage or injury arising from incorrect wall-hanging bracket, incorrect fitting or otherwise failure to follow the above instructions.
Page 8 (for 32”/42”/50”) (for 32”/42”/50”) ■ Assembling the pedestal (For TH-32LRU70/TH-32LRU7) (1) Install securely with assembly screws . (Total 4 screws) (2) The rotation angle can be set at 0°, 30°, 60° or 90°. Install screws to each angle control position.
Page 9 (Total 4 screws) Tighten screws firmly. One of the screws can be replaced with a security screw if necessary. Please visit the Panasonic website about screw location template. http://panasonic.net 0.24 ” (6 mm) Put the template where the TV is installed. Install...
Page 10 The TV may fall over and become damaged, or cause personal injury. Do not use the pedestal if it becomes warped or physically damaged. If you use the pedestal when it is physically damaged, personal injury may result. Contact your nearest Panasonic dealer immediately.
Page 11: Connections
Connections Connection panel ■ ■ Side panel Back panel HDMI terminals COMPONENT terminals RF connection COMPOSITE terminals AUDIO OUT terminal DATA/MTI terminal SERIAL terminal Ethernet terminal PC terminal USB terminal *1: No embedded b-LAN (TH-32LRU7/TH-42LRU7) *2: For more details on the external equipment’s connections, please refer to the operating manuals for the equipment.
Page 12 Connections (Continued) Connecting Antenna Back of the TV VHF/UHF Antenna Cable TV Power Cord Connect after all other Make sure the power cord plug is fully inserted into connections have been made. place to prevent removal of the power cord. •...
Page 13 Example of connections To use HDMI terminals Side panel Back panel AV Equipment HDMI AV OUT HDMI cable e.g. Blu-ray Disc player Connecting to the HDMI terminals will enable you to enjoy high-definition digital images and high-quality sound. The HDMI connection is required for a 1080p signal. To use COMPONENT terminals green green...
Page 14 Connections (Continued) Example of connections To use AUDIO OUT terminals DIGITAL AUDIO OUT terminal Optical digital audio cable OPTICAL IN Audio equipment AUDIO OUT terminal AUDIO IN Audio cable Connect a cable which matches the audio in terminal on the unit. To use DATA/MTI terminal External TA MTI OUT...
Page 15: Identifying Controls
Identifying Controls TV controls/indicators Front of the TV Back of the TV Selects Menu and Submenu entries Changes the input mode/ Press and hold down for MENU function (For setup mode only) Selects channels in sequence Volume up/down POWER button C.A.T.S.
Page 16: Watching
Watching TV Connections (p. 11-14) Turn the TV On with the POWER button (TV) (Remote) Input select: press (p. 17) Select a channel number (Remote) down CH buttons are also available on the side of the TV. Note Reselect “Cable” or “Antenna” in “ANTENNA/Cable signal” of “ANTENNA/Cable setup”...
Page 17: Watching Content From External Devices
Watching content from external devices If you have applicable equipment connected to the TV, you can watch videos and DVDs on the TV screen. Input Select You can select the external equipment to access. With the connected equipment turned On Display the Input select menu Select the input mode Select the input of your choice, then...
Page 18: Displaying Pc Screen On Tv
Displaying PC Screen on TV The screen of the PC connected to the unit can be displayed on the TV. You can also listen to PC sound with the audio cable connected. To connect PC (p. 14) Display the Input select menu Select “PC”...
Page 19: Using Media Player
Using Media Player You can view still images saved on a USB flash memory device. Insert the USB Flash Memory to the TV Ensure alignment is straight and complete when inserting or removing. Media player only supports USB Mass storage class devices. Display the view selection in the thumbnail view Select the data to be viewed Error display (titles that could not be loaded, etc.)
Page 20 Using Media Player (Continued) Options menu Note This operation is disabled when “Mode” in Hotel Mode menu is set to “On”. Display “Options menu” and select item Slideshow settings (see below) select Thumbnails size To change the number of photos on a thumbnail screen at a time (7 ×...
Page 21: Hotel Mode Setup
Power ctrl Off: Starts up in last screen. On: Starts up in screen On. Remote Switches Operation guide according to remote control. (Panasonic/Others) Sets CC setting status. (Off/On) CC reset Off: Saves the last settings. On: Resets all CC settings to defaults.
Page 22: How To Use Menu Functions
How to Use Menu Functions Various menus allow you to make settings for the picture, sound, and other functions so that you can enjoy watching TV best suited for you. Guest menu (p. 32) Display the menu Shows the functions that can be adjusted. Some functions will be disabled depending on the type of input signal.
Page 23: Menu List
Menu list Menu Item Adjustments/Configurations (alternatives) Selects from preset picture modes for optimal viewing. Mode is saved separately for each input. Picture mode (Vivid/Standard/Home theater/Cinema/Custom) Adjusts backlight’s luminance (light intensity). (0-100) Back light Adjusts the color, brightness, etc. for each picture mode to suit your taste. •...
Page 24 Menu Item Adjustments/Configurations (alternatives) Selects your favorite sound mode. (Standard/Music/Speech/User) • The selected mode affects all input signals. Standard: Provides the suitable sound quality for all types of scenes. Music: Improves sound quality for watching music videos, etc. Speech: Improves sound quality for watching news, drama, etc. •...
Page 25 Menu Item Adjustments/Configurations (alternatives) ANTENNA/Cable Selects signal source connected directly to the ANTENNA/Cable In terminal. (Cable/Antenna) • signal When using a Cable or Satellite box, it is recommended to connect the box to an AV IN terminal and skip this setting. Press OK to start scanning automatically.
Page 26: Viera Link Tm Tm
VIERA Link “HDAVI Control ” Simultaneously control all Panasonic “HDAVI Control” equipped components using one button on the TV remote. Enjoy additional HDMI Inter-Operability with compatible Panasonic products. This TV supports “HDAVI Control 5” function. Connections to equipment (DVD recorder, HD Camcorder, Home theater system, Amplifier, etc.) with HDMI cables enables VIERA Link controls.
Page 27 VIERA Link™ Connections (with VIERA Link function) ■ Connecting DVD Recorder Side panel Back panel HDMI cable DVD recorder with VIERA Link function ■ Connecting Home theater system/AV amp HDMI terminal (HDMI 1 is recommended.) Side panel Back panel HDMI cable Home theater systems with VIERA Link function DIGITAL AUDIO OUT terminal...
Page 28: Hdavi Control
VIERA Link “HDAVI Control ” (Continued) VIERA Link settings and Available features To use all VIERA Link functions: After everything is connected, in VIERA Link settings menu, set “VIERA Link” to “On”. Some features are disabled depending on the “HDAVI Control” version of the equipment. Please check the list.
Page 29 • The TV remains on even if the VIERA Link compatible equipment is turned off. Automatic lip-sync function Minimizes lip-sync delays between the picture and audio when you connect to a Panasonic theater system or Amplifier. TV provided setting information The following information about the TV settings can be transmitted to each piece of equipment (Recorder/Home theater/Player) that has “HDAVI Control 3 or later”...
Page 30: Editing And Setting Channels
Editing and Setting Channels The current channel settings can be changed according to your needs and reception conditions. Display the menu Auto program automatically Select “ANTENNA/Cable setup” in “Setup” next select Select the function next select Manual program manually Press to exit from a menu screen Press to return to the previous...
Page 31 Automatically searches and adds available channels to the memory. Select “Auto program” Start scanning the channels (Available channels are automatically set.) Auto program next Progress Number of analog channels select Number of digital channels After the scanning is completed, select “Apply”. (see below All previously saved channels are erased.
Page 32: Guest Menu
Guest Menu Display the menu Shows the functions that can be adjusted. Some functions will be disabled depending on the type of input signal. Select the item select Menu Menus language Screen format Audio mode Sleep Parental control Closed Caption Input select Media player Adjust or select...
Page 33: Signage Mode
Signage Mode You can set “Signage Mode” to display the digital signage contents on the USB storage. Display “Hotel Mode” menu • Hotel Mode Setup (p. 21) Press MENU, G, Y and 0 remote button. (“Mode” must be “On” ) select Menu Save...
Page 34: Loading Welcome Image
Loading Welcome Image You can set a specific image that is displayed as a Opening Image when the TV is turned on. Prepare Welcome Image (JPEG) in the USB storage • Opening image at root directory of the USB storage File name: Welcome.jpg •...
Page 35 Audio is not output while displaying the Welcome Image. When the image file is not installed, default image (Panasonic Logo) is displayed. To check the Welcome Image The Welcome Image is displayed for designated seconds by turning on the main power of the TV, or turning the power ON using the remote control.
Page 36: Local Authentication Mode
Local Authentication Mode At the Free-To-Guest by Stand Alone mode, descramble of Pro:Idiom is conducted without using built-in TA. Contact Panasonic sales company for Hotel ID and channel map information Setup Local Authentication Insert the USB storage to first TV set Display the Local Authentication screen automatically •...
Page 37: Channel Remap
Channel Remap Contact Panasonic sales company for channel map information • Hotel ID is not needed for this function. Setup Channel Remap Insert the USB storage to first TV set Display the Channel Remapping screen automatically • Insert/Remove the USB storage (p. 19)
Page 38: Clone The Tv Setting
Clone the TV Setting When installing a number of units in hotel or any facility, the data in master TV can be copied to USB storage and then copy to other TVs. Prepare blank USB storage • Create pwd file as startup file at root directory of an empty USB storage using your Insert a empty USB storage to your PC.
Page 39: Ratings List For Lock
Ratings List for Lock “V-chip” technology enables you to lock channels or shows according to standard ratings set by the entertainment industry. U.S. MOVIE RATINGS (MPAA) NO RATING (NOT RATED) AND NA (NOT APPLICABLE) PROGRAMS. Movie which has not been rated or where rating does not apply.
Page 40: Technical Information
Technical Information Closed Caption (CC) For viewing the CC of digital broadcasting, set the aspect to Full (If viewing with H-FILL, JUST, ZOOM or 4:3; characters might be cut off). The CC can be displayed on the TV if the receiver (such as a set-top box or satellite receiver) has the CC set On using the Component or HDMI connection to the TV.
Page 41 Data format information Photo: Still images recorded with digital still cameras compatible with JPEG files of DCF* and EXIF** standards Data format: Baseline JPEG (Sub-sampling: 4:4:4, 4:2:2 or 4:2:0) Image resolution: 8 × 8 to 30,719 × 17,279 pixels * DCF (Design rule for camera file system): A Japan Electronics and Information Technology Industries Association’s standard ** EXIF (Exchangeable Image File Format) Note The picture may not appear correctly on this TV depending on the recording equipment used.
Page 42 Technical Information (Continued) HDMI connection HDMI (high-definition multimedia interface) allows you to enjoy high-definition digital images and high-quality sound by connecting the TV unit and the devices. HDMI-compatible equipment (*1) with an HDMI or DVI output terminal, such as a set-top box or a DVD player, can be connected to the HDMI connector using an HDMI compliant (fully wired) cable.
Page 43 “HDAVI Control ” HDMI connections to some Panasonic equipment allows you to interface automatically. This function may not work normally depending on the equipment condition. The equipment can be operated by other remote controls with this function on even if TV is in Standby mode.
Page 44 Technical Information (Continued) DATA/MTI (RJ11) terminal connection A standard 6 pin RJ-11C connector is used to provide a connection between the MTI equipment and the TV set. Both the MTI terminal and TV are equipped with FCC-66 style (RJ-11C) jacks. Each of these jacks shall accept a 6 contact plug Molex P/N 90075-0007 or equivalent. External TA Multiple Television Interface (MTI) Pin layout for RJ-11C terminal...
Page 45 SERIAL CTRL (RS232C)/ETHERNET command list Functions of gray part are not available during online mode. Some functions are not available in local authentication mode. Control Command Inquiry Command Call back Command Parameter POWER ON* QPW:* “0”(OFF)/“1”(ON) POWER OFF VOL level AVL:** VOL UP QAV:***...
Page 46: Troubleshooting
Troubleshooting Before requesting service or assistance, please follow these simple guides to resolve the problem. If the problem still persists, please contact your local Panasonic dealer or Panasonic Service Center for assistance. White spots or shadow images (noise) Pictures from external...
Page 47 If there is a problem with your TV, please refer to the table below to determine the symptoms, then carry out the suggested check. If this does not solve the problem, please contact your local Panasonic dealer, quoting the model number and serial number (both found on the rear of the TV).
Page 48: Care And Cleaning
Care and Cleaning First, unplug the Power cord plug from the wall outlet. Display panel The front of the display panel has been specially treated. Wipe the panel surface gently using only a cleaning cloth or a soft, lint-free cloth. If the surface is particularly dirty, soak a soft, lint-free cloth in diluted mild liquid dish soap (1 part mild liquid dish soap diluted by 100 times the amount of water) and then wring the cloth to remove excess liquid.
Page 49: Specifications
Specifications TH-32LRU70 / TH-32LRU7 TH-42LRU70 / TH-42LRU7 TH-50LRU70 Power Source AC 110-127 V, 60 Hz Rated Power 70 W 105 W 110 W Consumption Under 1.0 W Under 1.0 W Under 1.0 W Standby condition Panel System LCD panel (LED backlight) 16:9 Aspect Ratio 32”...
Page 50 [TH-32LRU70/TH-32LRU7] [TH-42LRU70/TH-42LRU7] [TH-50LRU70] 3.0 ” 2.8 ” 2.1 ” (76 mm) 44.4 ” (1,126 mm) (71 mm) (54 mm) 38.0 ” (963 mm) 28.9 ” (734 mm) 17.8 ” 17.8 ” 17.8 ” 9.9 ” (250 mm) 9.9 ” (250 mm) 9.9 ”...
Page 52 Warranty Service purposes. Model Number Serial Number  Panasonic Corporation 2014 Panasonic System Communications Company of North America Panasonic Canada Inc. Unit of Panasonic Corporation of North America 5770 Ambler Drive...
