Summary of Contents for Zotac VR GO

  • Page 2 ZOTAC. Products and corporate names mentioned in this manual may not be registered trademarks or copyrights of their respective companies, and are used for identification purposes only.

  • Page 3: Table Of Contents

    Safety information ----------------------------------------------------------------------------------------------4 Setting up your system -------------------------------------------------------------------------------------4 Care during use ----------------------------------------------------------------------------------------------4 Welcome -----------------------------------------------------------------------------------------------------------5 Package contents -------------------------------------------------------------------------------------------5 Getting to know your ZOTAC VR GO ---------------------------------------------------------------------6 Top view --------------------------------------------------------------------------------------------------------6 Left view -------------------------------------------------------------------------------------------------------6 Right view -----------------------------------------------------------------------------------------------------7 Installing Hardware inside ZOTAC VR GO --------------------------------------------------------------8...

  • Page 4: Product Specifications

    ZOTAC VR GO Product specifications q Microprocessor support v Intel Core i7-6700T, quad core 2.8GHz (8M Cache, up to 3.6 GHz) q Onboard Graphics support v NVIDIA GeForce GTX 1070 w/ 8GB GDDR5, 256-bit v Three HDMI 2.0 ports, two DP 1.3 outputs (supports 4K @ 60 Hz) (max 4 displays)

  • Page 5: Safety Information

    ZOTAC VR GO Safety information Your ZOTAC VR GO is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instructions. Setting up your system Read and follow all instructions in the documentation before operating your system.

  • Page 6: Welcome

    ZOTAC VR GO Welcome Congratulations on your purchase of the ZOTAC VR GO. The following illustration displays the package contents of your new ZOTAC VR GO. If any of the below items is damaged or missed, contact your retailer. Package contents •...

  • Page 7: Getting To Know Your Zotac Vr Go

    ZOTAC VR GO Getting to know your ZOTAC VR GO Top view 1. Power output (DC12V) The power output is used to connect the supplied power to the VR display unit. 2. HDMI port The HDMI (High Definition Multimedia Interface) port supports a UHD device such as an LCD TV or monitor to allow viewing on a larger external display.

  • Page 8: Right View

    ZOTAC VR GO Right view Battery lock 1. Power input (DC19.5V) The supplied power adapter converts AC power to DC power for use with this jack. Power supplied through this jack supplies power to the PC only. It does not charge the batteries. To prevent damage to the PC, always use the supplied power adapter.

  • Page 9: Installing Hardware Inside Zotac Vr Go

    Before installing hardware, please follow the instructions below to remove the cover of your ZOTAC VR GO. Refer to page 20 to detach the backpack. 1. Lay the ZOTAC VR GO on a flat surface with the back cover facing upwards. 2. Locate the screws and remove.

  • Page 10: Installing A Hard Drive/Ssd (Optional)

    ZOTAC VR GO Installing a hard drive/SSD (optional) 1. Locate the 2.5-inch SATA hard drive/SSD slot and the drive bracket. Remove the thumb screw and bracket. 2. Install the hard drive/SSD to the drive bracket.
  • Page 11 ZOTAC VR GO 3. Insert the bracket into the SATA slot. 4. Reinstall the thumb screw.

  • Page 12: Installing Battery

    ZOTAC VR GO Installing Battery 1. To ensure correct battery installation, locate the batteries and place them to the side of the system. Make sure the battery status indicators are visible face up and on the side facing the system. See below illustration.
  • Page 13 ZOTAC VR GO 3. Ensure that the battery is installed in place, and release the battery lock to “Lock” position. Note: Only change one battery at a time to maintain power to the system when the system is powered on.

  • Page 14: Battery Charging

    ZOTAC VR GO Battery Charging The VR GO does not support charging the batteries directly. Please follow the instructions below to charge the batteries. 1. Insert the batteries into the battery charging dock. 2. Connect the AC adapter to the battery charging dock.
  • Page 15 ZOTAC VR GO 3. All battery LEDs will be OFF when fully charged. 4. Press the battery status button to check battery status.

  • Page 16: Setting Up Your Zotac Vr Go

    ZOTAC VR GO Setting up your ZOTAC VR GO You need to connect peripherals before using your ZOTAC VR GO.
  • Page 17 Connect the supplied AC adapter to the DC IN jack on the system rear panel and then press the power switch on the front panel to turn on the system.  When your ZOTAC VR GO is not in use, unplug the power adapter or switch off the AC outlet to save power.

  • Page 18: Attaching Backpack

    ZOTAC VR GO Attaching backpack 1. Lay the ZOTAC VR GO on a flat surface with the backcover facing upwards. 2. Lay the backpack on the back of ZOTAC VR GO. Push the backpack and ensure it is installed in place.
  • Page 19 ZOTAC VR GO 3. Open the Velcro cover on the backpack. 4. Turn the knob to “Lock” position. 5. Close and attach the Velcro cover on the backpack.

  • Page 20: Recommended Layout

    ZOTAC VR GO Recommended layout Note: VR devices are not included.

  • Page 21: Detaching Backpack

    ZOTAC VR GO Detaching backpack 1. Lay the ZOTAC VR GO on a flat surface with the backpack facing upwards. 2. Open the Velcro cover on the backpack. 3. Turn the knob to “Unlock” position. ...
  • Page 22 ZOTAC VR GO 4. Slide the backpack strap downwards. 5. Lift up the backpack strap to remove.

  • Page 23: Getting Started With Windows 10 Home 64-Bit

    ZOTAC VR GO Getting started with Windows 10 home 64-bit Please follow the steps below to begin using your VR GO with Windows 10 home 64-bit. 1. Power on the system. 2. Connect to the Internet via Ethernet or Wi-Fi.
  • Page 24 ZOTAC VR GO 4. Read and accept the license terms. 5. We recommend using the express settings.
  • Page 25 ZOTAC VR GO 6. Create a Microsoft new account if you don’t have one. Otherwise, select “Sign in”. 7. Setup your account.
  • Page 26 ZOTAC VR GO 8. Wait for the initial system setup to complete .

  • Page 27: Using Your Zotac Vr Go

    ZOTAC VR GO Using your ZOTAC VR GO Configuring a wireless connection Please follow the instructions below to connect to a wireless network: Double-click the wireless network icon (pic) in the notification area. Select the wireless network you want to connect to from the list and click Connect.

  • Page 28: Using A Dynamic Ip (Pppoe Connection)

    Configuring audio output Follow the steps below to enable audio output when connecting the ZOTAC VR GO to a TV or receiver via DP/HDMI adapter. Access the Sound settings via the system Control Panel. Under Playback devices, click the display device that corresponds with your audio compatible display.

  • Page 29: Travel Jacket

    ZOTAC VR GO Travel Jacket *Do not use while VR GO is in operation. 291-MB341-00...
