Summary of Contents for Horing LIH VIVID32
- Page 1 Fire Alarm Control Panel HORING LIH INDUSTRIAL CO., LTD.
-
Page 2: Table Of Contents
CONTENTS 1.System Characteristics 2.Control Board Description 2.1 LED Indicators 2.2 Keypad Switches 2.3 Access Level 3.Wiring Diagram 3.1 Zone Input/Output 3.2 Zone Wiring 3.3 Alarm Bell Wiring 3.4 24V DC Output Wiring 3.5 Dialler Relay Output Wiring 3.6 Fire/Fault Relay Output Contacts 3.7 AC Power Connection 3.8 Dip-switch instruction 4.Operating Instructions... -
Page 3: System Characteristics
1. System Characteristics VIVID32 System Characteristics 1. In accordance with EN54 Parts 2 and 4. 2. Available from 1 to 32 zones and modular setting enable. 3. Individual zone disable function. 4. Key switch protection for panel control switches. When the key switch is turned off, the BUZZER, switches will be disabled. -
Page 4: Control Board Description
2. Fault Indicator “BACK” Switch 3. CPU Fault Indicator “ENTER” Switch 4. Power Normal Indicator Buzzer Mute Switch 5. Disable Indicator Alarm Bell Silence Switch Information Display Evacuate Switch Keyboard Enable Switch Reset Switch “UP” Switch Zone Indicators (optional) VIVID32 OPERATING MANUAL... -
Page 5: Led Indicators
If the switch is pressed for more than 2 seconds, the indicator will flash and the bells will remain disabled despite any new signals. VIVID32 OPERATING MANUAL... -
Page 6: Access Level
” form) on the side of the panel door. It requires a Phillips screwdriver to turn on to access to LEVEL 4 to change the hardware settings of the main board, such as DIP switch settings and JUMP settings. VIVID32 OPERATING MANUAL... -
Page 7: Wiring Diagram
Sounder 24Vdc Output Dialler Output Fire Relay Output Fault Relay Output SND1 DIALLER FIRE FAULT 24V DC 24V DC 24V DC 24V DC 4.7k To Dialing To Relay To Relay Relay Output Output Output Device Device Device VIVID32 OPERATING MANUAL... -
Page 8: Zone Wiring
Fire alarm control panel is equipped with two sets of Area Bells contacts. When connecting one set of bell contacts, please be sure to connect the end of resistor to avoid bell malfunction. Please install the 4.7K ohm resistor across the unused bell contacts as well. VIVID32 OPERATING MANUAL... -
Page 9: Dc Output Wiring
The contact is connected with NO. and COM. When there is a fire alram, the signal will go through the telephone line. 3.6 Fire/Fault Relay Output Contacts: To Relay Output Device To Relay Output Device In picture A shows N.O. connection. In picture B shows N.C. connection. VIVID32 OPERATING MANUAL... -
Page 10: Ac Power Connection
Set the switch to ON for 3rd PCB. Set the switch to OFF for 1st & 2nd PCB. 32 Zones (PCB*4) Set the switch to ON for 4th PCB. Set the switch to OFF for 1st & 2nd & 3rd PCB. VIVID32 OPERATING MANUAL... -
Page 11: Operating Instructions
Enter” switch to enter the item 1- ► 1.All Status Disp. All Status Disp. 2.Memory Data Disp. ► 1.Alarm Status Disp. Press the“ Enter” switch to enter the item 1- 2.Fault Status Disp. Alarm Status Disp. to see more details. VIVID32 OPERATING MANUAL... - Page 12 The upper right-hand corner is a number of the disabled loops.Press the“ Up” or “ Down” Zone Disable : 0001 switch in the lower to switch the disabled loops. 01 ZONE Disable Press the “ Back” switch to return to Alarm Status Disp. selection list. VIVID32 OPERATING MANUAL...
-
Page 13: Memory Data Disp
► 3.Main Switch Press the“ Enter” switch to enter the Main Switch selection list. Press the“ Up” or “ Down” switch to select the item. ► 1.Relay Output > 2.Dialler Press the“ Enter”switch to enter the selection item. VIVID32 OPERATING MANUAL... -
Page 14: Zone Disable
Up” or “ Down” switch to select the zone number. Disable Enable Press the“ Enter ”switch to disable or enable Disable Enable the zones. > Press the“ Back” switch to return to the Main Display selection list. VIVID32 OPERATING MANUAL... -
Page 15: Memory Data Delete
6. Set Up - Set Control Panel Other Function: Press the“ Down”switch to move to item 6- 5. Memory Data Delete Set up. 6. Set Up > Press the“ Enter ”switch to enter the Set Up selection list. VIVID32 OPERATING MANUAL... - Page 16 Enter”switch to complete the setup 2015/01/21 16:40.56 of date and time setup. Use the“ Back”switch to move to a previous digit. After setup is completed, the display returns 2015/01/21 16:40.56 Complete to the Set Up selection list. VIVID32 OPERATING MANUAL...
- Page 17 Input Set Code:0000 switch to complete the code setting. Use the“ Back” switch to return to the 4th digit (code 4). After setting up, the display returns to the Set Up Input Set Code:0000 Confirm selection list. VIVID32 OPERATING MANUAL...
- Page 18 Enter” switch to see the details. Press the“ Enter”or“ Back ”switch to back Zone Number:32Zones to the Set Up selection list. ROM Ver. 091813-1 *Note: Display zone data can be changed via panel internal setting. Zone disable will also be changed. VIVID32 OPERATING MANUAL...
-
Page 19: Maintenance Instructions
And also check to see whether any detectors/manual call points are detective or exist any broken glass shields or not. Eusure that no faults in the whole wiring system. Make sure if any ground fault is in the AC input contacts. VIVID32 OPERATING MANUAL... -
Page 20: Trouble Shooting
Use a multi-meter to check that the resistance across the L(Z+) and LC(Z-) contacts is about 4.7K ohms. f. Disconnect the wires connected to the contacts L and LC. Make sure that the voltage across the two wire is 0 volt. VIVID32 OPERATING MANUAL... - Page 21 Disable indicator will light up. If you would like to make the Zone Faulty indicator go off, you should install the end of line resistor across the L(Z+) and LC(Z-) contacts of the Zone. After repairing the wiring, please reconnect the external wiring. VIVID32 OPERATING MANUAL...
-
Page 22: General Specifications
- Connecting Cable Cable’s Semi-Diameter 1.5mm Maximum Supply Current - Ambient Temperature Operating Temperature -7℃ ~ +45℃ Storage Temperature -10℃~ +70℃ - Standard Fire Alarm Control Panel EN54-2 Power Source EN54-4 Instruction Policy (Design, Install, Plan , Usage..) EN54-14 VIVID32 OPERATING MANUAL... - Page 23 Note...
- Page 24 HORING LIH INDUSTRIAL CO., LTD. V I V I D 3 2 O p e r a t i n g M a n u a l www.horinglih.com...
